Frame press

Ormamacchine

Condition: good (used), Year of construction: 2011, Internal flange dimensions 2340 x 1340 mm Maximum panel dimensions (20mm thickness) 2340 x 1240 mm Working chamber height 60 mm Total thrust 300 t Maximum specific working pressure 5 kg/cm2 Press cylinders No. 6 diam 140 mm stroke 250 mm Nwedpfx Aetwba Sofcsc Lower moving platen (closing movement from bottom to top) Opening between press platens 230 mm Side load 1400 mm Pvc roller uncoiler Double loading table

Condition: new, Year of construction: 2025, functionality: fully functional, PLATEN LENGTH MM. 3000 PLATEN WIDTH MM. 1300 PRESS STROKE MM. 400 VERTICAL CYLINDERS 6 - DIAM. 70MM. INTERMEDIATE PLATENS CONFIGURATED TOTAL THRUST 90 TON TOTAL POWER KW 21 Nwedpfei E Tz Hex Afcoc HEATING DIATHERMIC OIL

Condition: refurbished (used), HYDRAULIC HOT PLATE PRESS, MODEL LS/L/R 30/13 SP. 150 mm Composition - LOADER - HYDRAULIC PRESS WITH HOT PLATENS, MODEL LS/L/R 30/13 SP. 150 mm - 3000x1300 mm HOT PLATE ROLLERS UNLOADER Press platen dimensions 3000x1300 mm. Nwedon R Dihepfx Afcsc Press plungers No. 6 Ø 70 mm stroke 200 mm. Press platen thrust 70 t.

Condition: refurbished (used), Year of construction: 2002, functionality: fully functional, ELECTRO-HYDRAULIC PANEL PRESS WITH OIL BOILER, MOTORIZED FEED, INFEED & OUTFEED TABLES Brand: ORMA Model: LS 25/13 AF BO Serial No.: 69440202 Year: 2002 (Photos taken before overhaul, functional tests & cleaning) Press specifically designed for manufacturing solid wood laminated panels using special adhesives. SPECIFICATIONS: - Heated platens 2500x1300mm by oil circulation at 120°C Opening height (usable stroke): 200 mm Maximum vertical platen pressure: 80 tons (2.5 kg/cm²) Maximum vertical pressure of front cylinders: 40 tons (25 kg/cm²) - Horizontal pressing stroke: 150 mm Adjustable working thickness: 12 to 50 mm Horizontal pressure: 7.5 tons (7 to 10 kg/cm²) CONFIGURATION: - Heavy-duty steel frame - Motorized infeed table 2.50x1.40m with rack-and-pinion pusher - Hydraulic power units 3x 2 HP - Control panel with 2 foot pedals; adjustment for feed/horizontal & vertical working pressure/working temperature/pressing time Pressure gauges for: platen pressure, pusher stop, and locking presser - Mobile lower platen with aluminum surfaces Nsdpewxdctsfx Afcswc 6 hydraulic cylinders Ø70mm with 4 rack-and-pinion balancing guides - Heated upper/lower circuits (internal coil) 24kW electric boiler with 1.1kW circulation pump - Independent rear locking presser with 3 hydraulic cylinders Ø70mm, double rack guides - Lateral pressers 5 hydraulic cylinders Ø40mm Adjustable feet 70x120mm (height adjustable) - Outfeed roller table length 1.25m - Complete electrical cabinet with all controls - Power supply: 400V, three-phase 50Hz, IN 44A Installed power: 32kW - CE marking Lockable main switch, emergency stop button Emergency stop cable Safety guards Transport dimensions (LxWxH): 3.50x2.40xh.2.00m + 2.40x1.80xh.1.80m (as delivered, packed) Weight: 6200kg + tables

Condition: excellent (used), Year of construction: 1997, I sell the press for veneer and foil ORMA NPC-30 4-40 2500 x 1200. Product size max. 2500 x 1200mm Oil heating. Total power 21,7 KW at maximum. Nodpfxou E E A Tj Afcowc Very good condition. Available immediately.

Condition: good (used), Code: 0276 Brand: ORMAMACCHINE Model: NPC - CE Standard Nwjdpfx Afsx Iu Huococ Hot press for carpentry, furniture, custom-made furnishings, veneering, panels, doors, wooden window frames, composite materials and various - CE Standard Technical data: Working platens dimensions 3000 x 1300 mm Opening between platens 400 mm N° 6 pistons Total thrust 90 ton Platens with coils Platens heating with hot water via boiler complete with circulation pump and expansion tank Motor 2 Hp Overall dimensions mm 4600 x 1600 x 2000 h Weight 3800 kg

Condition: used, workpiece height max. 2.320 x 1.010 mm output 33 kW Njdpfxjw Na Ulo Afcowc Available 2 Stück Orma PM/AFT membrane press for coating single-sided profiled workpieces with automatic loading and unloading system

Condition: used, Frame press ORMA EUROPA Line voltage 380 V - 50 Hz Control voltage, magnetic components, lamp 110 V Main protection 3 x 25 A Nwedpfxewudzbs Afcec

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, machine/vehicle number: -, ORMA NPC/DIGIT 6/95. Press area of 3000x1300 mm, six cylinders.Press opening stroke 650 mm. 3 loads. Pressure 90 ton. 18 kW electro-heater for thermo-oil heating up to 120°C. Parallelism control by sensor. CE-standard. Transport throughout Europe is available at a good price. Nedpjyf Azgefx Afcswc

Condition: used, Empty weight: 75 kg - Documentation available: No - CE certificate present: No - Transport weight [kg]: 75kg Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels Nwsdoybb D Sjpfx Afcjc
