IN STOCK Press Brake 125x3200 OT-41

Otinus PBO-3212-CNC OT-41

Condition: new, Year of construction: 2026, The CORMAK HBS260 metal bandsaw for cutting pipes, profiles and bars is widely used in locksmith and metalworking workshops where precision, quality and cutting speed are essential. The model features a pivoting arm from 0° to 60°. The frame design ensures precise and quiet operation. It has a removable chip tray for easy cleaning! Machine characteristics The CORMAK HBS260 horizontal metal bandsaw with a pivoting arm enables cutting perpendicular to the material axis and at any angle within the range of 0° to 60°. The material can be fed manually or by any mechanical device, while the tool feed operates automatically. The blade guides are fitted with special carbide plates and bearings, which have a significant influence on the blade’s guidance, service life, straightness, accuracy and cutting quality. The carbide guidance system greatly reduces machine and blade wear. The machine is equipped with an efficient coolant pump with a closed coolant circulation system. The saw arm is made from a single cast-iron element, and with the use of a 27 mm wide cutting blade, it enables series cutting of both profiles and solid materials. The vice is mounted on an adjustable base and features a quick-clamping system. The blade guides are fitted with hard metal (carbide) plates and rolling bearing systems. These carbide guides are responsible for the cutting precision and straightness. Ledjudi Uzjpfx Agrort The upper part of the base is shaped as a tray for draining coolant and collecting chips generated during the cutting process. The base is fitted with a cast-iron worktable with a pivoting arm and a control panel mounted on a separate arm. In the cutting process, the main cutting motion is the movement of the cutting blade, while the feed is achieved by lowering the arm. The arm lowering speed (cutting speed) is controlled by a hydraulic cylinder. The feed rate is regulated via the saw’s control panel. Two blade speeds are available: 35 and 70 m/min. When the arm reaches its lower position (after the cut), the drive to the cutting blade is automatically switched off. Safety is ensured by blade guards and micro-switches that stop the motor after the cutting cycle or when any guard is opened. Additional protection automatically switches off the bandsaw in the event of blade breakage. Blade size [mm] 2520 x 27 x 0.9 Blade tension mechanical (manual) Blade speeds [m/min] 35, 70 Arm lowering control stepless – hydraulic cylinder Vice base height [mm] 860 Saw wheel diameter [mm] 300 Saw frame swivel [°] 0–60 Power supply 3-phase 400V Main motor power [kW] 1.1 / 1.5 Coolant pump motor power [kW] 0.05 Dimensions with base [cm] 150 x 80 x 140 Weight [kg] gross/net – 210 / 180 kg Additionally 2 M42 saw blades 5L Emulsol ZW580 magnetic chip collector

Condition: new, Year of construction: 2023, Manipulator with hydraulic height adjustment, faceplate with clamping slots and manual remote control. Height (faceplate horizontal): approx. 670 - 2,400mm Swivel range of face plate: approx. +-360°. face plate dimensions: Ø1.200mm x 40mm, 6x clamping slots Rotational speed of main axis: approx. 2.0 rpm (other Torque main rotary axis: approx. 13.000 Nm Speed of face plate: approx. 0.2-2rpm Torque face plate: approx. 10.000 Nm Lrjdpfx Agenqzt Asrst

Year of construction: 2022, condition: new, Manipulator with two height-adjustable outriggers and a turntable. Load capacity: 1,500 kg Stroke: 800 mm Ljdpfx Agjfnku Hsrert Swivel range: 300° Turntable diameter: 1,000 mm Welding current: 600 A

Condition: like new (used), functionality: fully functional, Year of construction: 2026, operating hours: 8 h, machine/vehicle number: BD89NC2A1S, bending angle (max.): 190 °, overall weight: 2,000 kg, total length: 4,300 mm, total width: 1,300 mm, total height: 1,600 mm, power: 11 kW (14.96 HP), input voltage: 380 V, type of input current: AC, warranty duration: 12 months, Semi-Automatic Single-Head Hydraulic Pipe Bending Machine BD89NC2A Machine Model: BD89NC2A Machine Applications  Transportation Sector For locomotives, automobiles, and bicycles: exhaust manifolds, brake lines, fuel supply conduits, steering mechanisms, air - conditioning ducting systems, seating assemblies, balancing components, bumper structures, window frame assemblies, handlebar components, and frame structures.  Furniture Industry Indoor and outdoor seating and table sets, office furniture including desks and chairs, shelving units, bed frames and associated furniture pieces.  Leisure and Recreation Industry Fitness apparatus, infant strollers, utility carts, and amusement ride installations.  HVAC (Heating, Ventilation, and Air - Conditioning) and Appliance Industry Water heating units, electric heating appliances, gas - fired cooktops, refrigeration units, and air - conditioning equipment.  Heavy Industrial Sphere Piping networks for boilers, heat exchanger, power generation plants, chemical processing facilities, diesel engine manufacturing, and shipbuilding operations.  Diverse Other Industries Household consumer goods, rehabilitation - oriented medical devices, sanitary fixtures, the decoration and interior design sector, the construction industry, agricultural machinery and equipment, and the aviation manufacturing and maintenance industry. Lrodpfx Agsvu R Amjrot The largest applicable carbon steel pipe (bending radius ≥ 2d) Φ89×3.0mm (thickness Max. 3.0) The largest applicable stainless steel pipe (bending radius ≥ 2d) Φ76×2.0mm (thickness Max. 2.0) Maximum core length (*) 3500mm Maximum bending radius (*) 450mm Maximum bend angle 190° The number of bends that can be set for each pipe fitting (*) 25 bends The number of pipe fitting files can be set 280 sets (extensible) Working speed bending speed Max.30°/s Machine tool bending angle ±0.1° Hydraulic motor power 11.0kw

Year of construction: 2022, condition: new, Turntable Lrjdpfxsgn Ecro Agret Load: 1.000kg (1.200kg horizontal) with a center of gravity of 200mm from the faceplate Faceplate diameter: 800mm with 4 T-slots Faceplate speed: 0.05-1.5rtm Torque face plate: 1,800Nm Tilt angle: 0-135 ° Welding current transmission: 800A Operation: Two-pedal foot switch and button on the switch cabinet

Condition: new, Year of construction: 2026, Fully hydraulic lowering and lifting function of the saw frame Hydraulic opening and closing of the clamping device Automatic shut-off after cutting, return of the saw arm to the starting position Torsionally rigid saw frame made of cast steel (with multiple ribs) Hydraulic short-stroke cylinder for the clamping device Precisely ground carbide saw blade guides, adjustable Lsdpfx Aocl Tc Asgrsrt Electric coolant pump Belt tension manually adjustable with display, incl. electric saw blade and cutting pressure monitoring Hydraulic vise (opening and closing) Rotating chip removal brush Oversized, solid round support table, rotating with miter cuts with a predefined cutting channel; miter setting manually adjustable, reading via scale Material stop 500 mm with scale Incl. saw blade with combi-tooth pattern 4/6 Machine color: - Saw frame RAL 7035 - Machine body RAL 7005 Motor - three-phase 400 V, frequency-controlled 1.5 kW Saw blade dimensions 2910 x 27 x 0.9 mm Flywheel diameter 325 mm Cutting speed 20-120 m/min Vise clamping width 320 mm Working height 760 mm Sawing range: at 0° = Round D 250 mm, Square 240 x 240 mm, Rectangle 320 x 190 mm Machine dimensions (W x D x H) 1480 x 1700 x 2000 mm Weight 420 kg Further accessories available upon request. DELIVERY: FREE TO YOUR DOOR (within Germany) NOT THE RIGHT MACHINE? WE ARE A FLOTT SUPPORT PARTNER AND CAN OFFER YOU ALL PRODUCTS FROM THE FLOTT RANGE! ASK FOR A QUOTE!

Year of construction: 1998, condition: good (used), machine/vehicle number: 4422758898019, Offer 22646 Hydr. profile and bar shears with notching device and hole punching machine Technical data: Ledpfx Asmb U Sljgrjrt - Flat steel shear - flat steel - 400 x 16 mm - or: 300 x 18 mm - Section steel shear - L- and T-iron at 90° 130 x 12 mm - square steel / round steel 40 / 40 mm - notcher - with square notcher for sheets up to approx. 13 mm - notch depth approx. 70 mm - notch width approx. 52 mm - Hole punch - punching force approx. 60 t - throat 400 mm - stroke approx. 10 to 50 mm - punches in steel up to Ø 31 in 15 mm - material stop - div. 10 pcs. punch + dies - drive 400 V / 5,5 kW - space requirement W 1100 x H 2000 x D 1700 mm - weight approx. 2100 kg

Condition: new, Year of construction: 2024, DT500EY-650 Siemens 828 D ShopTurn (Fanuc Option) CNC turning/milling center with tailstock, driven tools and true Y-axis, ±70 mm, 35° slant bed and linear roller guides Available for viewing in the showroom Max. swing diameter: 600 mm Max. turning diameter: 320 mm Max. turning length: 650 mm Rapid traverse X/Z/Y: 20/20/12 m/min Turret: 12 stations BMT55, all 12 with live tooling Max. rotational speed: 4000 rpm, 3 kW Spindle Chuck diameter: 203 mm (optional 254 mm) Spindle nose: A2-6 (optional A2-8) Max. bar capacity: 52 mm (options for 65, 75, and 91 mm) Spindle bore diameter: 66 mm Drive power, direct drive: 22/30 kW Max. spindle speed: 4,000 rpm Tailstock diameter: 110 mm / MK3 Tailstock traverse: 850 mm Dimensions (W x D x H): 3.6 x 2.1 x 2.3 m Weight: 5.5 t Lrsdpfsqa Dtfjx Agrst Standard accessories: Coolant system Three-color warning light Work area lighting Central lubrication Programmable tailstock Set of soft jaws Tools and toolbox CE conformity Operating manual Including special accessories: Hinged belt chip conveyor Tool measuring arm Oil skimmer Bar loader interface Video shows DT500

Condition: excellent (used), functionality: fully functional, Year of construction: 2017, laser power: 4,000 W, sheet thickness steel (max.): 20 mm, sheet thickness aluminum (max.): 15 mm, sheet thickness brass (max.): 8 mm, total length: 3,000 mm, working range: 1,500 mm, Equipment: safety light barrier, Bystronic BySprint Fiber 3015, 4000W Lodpfx Agjup Tfcsrert Maximum cutting area: X-axis: 3048 mm, Y-axis: 1524 mm, Z-axis: 70 mmNominal sheet size: 1500 x 3000Materials and maximum thicknesses of materials to be cut: Steel 20 mm, Stainless steel 15 mm, Aluminium 15 mm, Brass and copper 8 mm.Cutting accuracy: 0.1 mmPacking accuracy: 0.05 mmMaximum workpiece weight: 890 kg

Condition: new, Year of construction: 2023, CNC Lathe HS-440HL TECHNICAL SPECIFICATIONS: - Control system: FANUC 0i-TF Plus (5) - Spindle servo motor: FANUC 11/15 kW - X-/Z-axis servo motors: FANUC 1.6 kW - Max. workpiece diameter/turning diameter: 450 mm / 300 mm - Max. turning length: 450 mm - X-/Z-axis travel: 165 mm / 500 mm - Working feed rate: 5 m/min; rapid traverse rate: 30 m/min - Spindle speed: 45-4500 rpm - Spindle bore/bar diameter: 62 mm / 52 mm - Hydraulic chuck, 200 mm diameter - 12-position hydraulic tool turret - Hydraulic tailstock, MK4 / tailstock quill travel: 130 mm - Linear ball screw guides on all axes - Machine dimensions (W x D x H): 3950 x 1552 x 1825 mm Lrodpfx Agsiwtk Njrst - Machine weight: 4500 kg STANDARD EQUIPMENT - Fully enclosed work area with cabin - 12-position hydraulic tool magazine - Drill chucks, 4 pcs - Turning tool holders, 8 sets - Rotating center, MK4 - Chip conveyor (belt type) with container - Automatic lubrication system - Coolant system with tank and pumps - Heat exchanger for electrical cabinet - Transformer - Tool kit for basic machine maintenance - Leveling screws and shims (6 sets) - Warning light / LED work light
