Underfloor lathe for railway wheel

Rafamet UGA 170

Condition: excellent (used), Year of construction: 1991, functionality: fully functional, travel distance X-axis: 500 mm, travel distance Y-axis: 350 mm, travel distance Z-axis: 120 mm, travel distance W-axis: 450 mm, For sale: Hauser coordinate grinding machine, model S35-400 The machine is in excellent condition and underwent a partial overhaul in 2024 for €15,000. The machine is equipped with 6 high-quality grinding motors, a face motor, and turbines. TECHNICAL DATA Bcodpfswtqthsx Afcow Distance between column and spindle: 365 mm Clearance between table and spindle: 485 mm Main spindle diameter: 100 mm X-axis: 500 mm Y-axis: 350 mm Z-axis: 120 mm W-axis: 450 mm U-axis: 5.5 mm Maximum taper grinding: 16° Table size: 600 x 380 mm T-slots: 6 units, 10 mm width, 50 mm spacing Table load capacity: 300 kg Speeds and Tool Holders Speed 22S: 4,500 - 22,500 rpm 45S/45ST: E19 Speed 45S/45ST: 9,000 - 45,000 rpm 80S: F6 Speed 80S: 40,000 - 80,000 rpm T10/T16: Ø 3 mm Speed T10/T16: 100,000 / 160,000 rpm Slot grinding attachment: 2,900 - 34,500 rpm Planetary movement: 5 - 250 rpm C-axis: 0 - 5 rpm X/Y feed: 0 - 1,200 mm/min W-axis feed: 900 mm/min Z-axis feed: 0.5 - 12,000 mm/min MACHINE DETAILS Digital measuring accuracy: 0.001 mm Base deviation: 0.003 mm Power: 7.5 kW Compressed air requirement: 20 m³ System pressure: 5 bar Footprint: 3.5 x 4.4 m Machine height: 3.5 m Connection value: 8.3 kVA Weight: 3.1 t EQUIPMENT - Slot grinding attachment - Rotary table, 300 mm diameter - Swivel table, 200 mm diameter - Coolant system - Extraction unit - Very high-quality accessories included Transportation and loading can be arranged across Europe at extra cost upon request. Prices plus VAT. Viewing by appointment is possible. Contact us—our team is happy to assist you. Trade-in or exchange possible! MACHINE PROCUREMENT / SALES PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MORE. Are you looking for a high-quality yet affordable metalworking machine for your production? Or do you want to sell yours? For more information or contact options, visit our website.

Condition: used, SCHULER TYPE 315-400 PRESSURE: 315t LENGTH OF STROKE: 30-160mm Bcsdpsrgp N Hefx Afcjw STROKES PER MIN: 36

Condition: excellent (used), Year of construction: 2004, functionality: fully functional, Description WE OFFER AN NICE WORKING CONDITION INDEX ABC 42 - TWO MACHINES WE HAVE AWAILIBLE TWIN SPINDLE TWIN TURRET INCLUDIN COMPLETE TOOLINGS AND SPARE PARTS MACHINE IS CONECTED ON POWER AND CAN BE INSPECTED UNDER POWER FOR CUSTOMER WE CAN ORGANIZE TRANSPORT AS WELL Machine Category CNC Turning- and Milling Center Make INDEX Type ABC 42 (*934) Year 2004 Control C200-4 / 840C Siemens Country of origin Germany Other information CNC - Turning- and MillingCenter INDEX - ABC 42 - two turrets Bjdpfxjvk E Nmj Afcscw - live tool stations - subspindle on upper turret - 1x back drilling device - with percussion unit - many accessories Technical Details Backside processing: C-Axis 0,001 ° change-time tool to tool 0,2 sec clamping diameter max. 42 mm clamping length max. 38 mm control C200-4 / 840C Siemens dimensions of the machine ca. 7,0 x 3,0 x 2,5 m Driven Tool Positions: 8 Feed force X: 8,3 / Z: 5,5 kN Fixed tools max. 5 pos Main spindle: max. Torque 7,5 Nm number of toolpositions 6 pos. power capacity - driven tools 3,3 kW power capacity - main spindel 13 / 21 kW rapid traverse X: 16 / Z: 24 m/min shaft cross cut 25 x 48 DIN 69880 spindle bore 15,5 mm spindle diameter in front bearing 85 mm spindle hollow 36 mm spindle passage 36 (42) mm Spindle speed - driven tools 6.000 min -1 Spindle speed range subspindle max. 4.500 min/-1 Subspindel: total power requirement ca. 30 kW travel -x axis 81 mm travel -z axis 80 mm turning length max. 280 mm turning speed range - main spindle max. 6.300 min/-1 Turret 1: Turret 2: weight of the machine ca. 3,0 t Accessories bar feeder Index LM 3200 Chip conveyor Coolantsystem Documents driven tool stations hydraulic system parts catcher Subspindle Turret 2x

Condition: good (used), Blohm HFS 512 X-2000, Y-600, Z-600 Bcsdpoyik Rbsfx Afcsw Magnet 1200 x 500 mm Power 11 kW 6500 kg

Condition: used, Year of construction: 1974, operating hours: 10,000 h, functionality: fully functional, machine/vehicle number: 8002/6410, drilling depth: 1,000 mm, drill diameter: 30 mm, type of input current: three-phase, spindle motor power: 21 W, table length: 1,000 mm, input voltage: 550 V, mount diameter: 160 mm, number of spindles: 1, drilling capacity: 1,000 mm, quill diameter: 30 mm, Equipment: rotational speed infinitely variable, Deep hole drilling machine for up to 1000 mm and 30 mm diameter, used for drilling aluminium, regularly serviced, includes a significant quantity of drills. Machine is fully operational and in continuous use. Siemens control, Simatic PANEL, documentation available. Bcodpfxex Ehg Tj Afcsw
