Folding machine

RAS 67.30

Condition: used, sheet width 3200 mm plate thickness 2,5 mm weight of the machine ca. 3,5 t Tools recentely grounded. Nodpfxer Ngtfs Afcjwc Bending angle preselection via potentiometer

Condition: excellent (used), functionality: fully functional, Year of construction: 2003, control type: CNC control, actuation type: electric, controller model: System 6000, working width: 3,200 mm, type of crowning: CNC-controlled, sheet thickness (max.): 3 mm, sheet thickness steel (max.): 3 mm, back gauge: 3,000 mm, Equipment: CE marking, emergency stop, Used Ras Flexibend 73.30 Cnc Folding Machine For Sale with 3metre back gauge Njdpfxow T Sc Ae Afcjwc Motorized Swivel Bending Machine Make: RAS Model: Flexibend 73.30 Year of Manufacture: 2003 Technical Specifications Manufacturer: RAS Model: 73.30 Year: 2003 Useful bending length: 3200 mm Sheet thickness: 3.0 mm Upper beam opening width: 300 mm CNC adjustable bending beam travel, max.: 80 mm CNC adjustable lower beam travel, max.: 80 mm Speeds: Bending beam, max.: 90 degrees/sec Upper beam, max.: 40 mm/sec Back gauge 10–1550 mm: 2 sec Equipment • Control: Touch & More System 6000 - NEW TOUCH SCREEN FITTED • CNC-controlled back gauge, 3metre J version / J shape back gauge • Motorized lower beam adjustment and bending beam adjustment • Support table A good selection of tooling, segmented and full length

Condition: used, DALLAN Rollforming machine | Omega profiles 60mm & 80 mm With 11 forming stations, fully equipped and currently set up for Omega 60 mm, the line includes additional tooling for Omega 80 mm profiles. This machine is complete, in excellent condition. DALLAN rollforming line with 11 forming stations: · Maximum sheet width: 300 - 350 mm · Controls: Dual console · Shaft diameter: 60 mm · End unit: Integrated cutting station · Current setup: Configured for classic Omega 60 mm, includes tooling for Omega 80 mm · Idle decoiler Nwjdpfsxugf Hjx Afcec · Tooling box (approx. 1,000 kg) for producing other profile types · Dimensions: 10,000 x 1,400 x 1,600 mm (L x W x H) · Weight: 10 tons Maximum sheet width: 300 - 350 mm Controls: Dual console Shaft diameter: 60 mm End unit: Integrated cutting station Current setup: Configured for classic Omega 60 mm, includes tooling for Omega 80 mm

Condition: excellent (used), functionality: fully functional, Year of construction: 2020, PowerBend Professional 3,200 × 3.0 Working length (a) 3,240 mm Sheet thickness 400 N/mm² 3.0 mm Machine length (b) 5,700 mm Machine height with swivelling arm 2,313 mm Machine width with back gauge (c) 1600 mm closed table 3,223 mm U-1600 3,223 mm U or rather J-3200 4,955 mm Weight of basic machine (ca.) 7800 kg Weight incl. rot. clamping beam (ca.) 9200 kg Clamping beam Geometry 48° (180°) Nedpfxjyaw Aue Afcjwc Stroke 500 mm Drive power 2 x 2.2 kW Speed 65 mm/sec Folding beam Drive power 2 x 3.0 kW Speed 100 °/sec Folding beam adjustment, motorized 150 mm Folding center adjustment +80/-20 mm

Condition: excellent (used), functionality: fully functional, Year of construction: 2010, machine/vehicle number: K10027, control type: CNC control, degree of automation: semi-automatic, throat depth: 1,000 mm, bending angle (max.): 140 °, Equipment: CE marking, emergency stop, foot remote control, Jorns Long Folding Machine for folding Sheet Metal I have operated this machine from new. It is a very capable and reliable machine made by Jorns of Switzerland who are known to be at the very top of their game. It is capable of folding 1.2mm in steel and 2mm in aluminium. Nwsdpfx Afex Ilx Iscoc The machine has a 1m insertion depth and four backstops which are adjustable. (there is an option to add more, but we never needed to.) The machine also has a slitter installed for slitting sheets along the full length of the machine to desired width. This is all controlled from the CNC. The machine was manufactured in 2010. It has the Jorns CNC50 control system which can be programmed with 100 different programs. The machine is very easy on power as all folding movements are hydraulicly driven. Overall the machine is in extremely good condition and can be seen operating until Mid January. Machine comes with safety light curtains. Machine will be ready for collection middle/end of January. I would prefer buyer to collect but if delivery is necessary, it could be arranged as an extra charge. Machine is approx 8m long x 2m wide and weighs approx 7 Tonne. New Jorns machine forces sale.

Condition: used, Year of construction: 1993, Max. bending length: 3240 mm Max. sheet thickness: 2 mm steel Manual and automatic bending process possible Bending angle adjustable via potentiometer Lifting height of the upper beam and material thickness can be preselected via dip switch Bent rail and machine in top condition Nsdpfx Aoyhqhtofcswc Weight: approx. 3000 kg
