Pallet wrapper

ROBOPAC

Condition: excellent (used), Year of construction: 2005, functionality: fully functional, type of input current: three-phase, total length: 5,000 mm, total height: 2,000 mm, total width: 1,800 mm, input voltage: 380 V, Spiral wrapping machine, 1200 mm diameter, fully functional, very good condition Laedpfx Amsx Hz Ezovog

Condition: used, Year of construction: 1997, functionality: fully functional, Used AUTOMATIC STRAPPING MACHINE FOR PACKAGING LINE WITH MOTORIZED ROLLERS, ROBOPAK BRIDGE 750 TP-601B. Lodezhufbspfx Amvjag

Condition: used, Year of construction: 2023, Overview This Robopac Genesis Futura HS pallet winder was built in 2023. It has under 500 operating hours - technically close to new. The rotating ring carries the pre-stretch carriage around the stationary pallet for high throughput without moving the load (see Capacity below). Delivered as a stand-alone unit with integrated roller conveyor, prepared for line integration over Ethernet TCP/IP. Technical data - Manufacturer: Robopac - Model: Genesis Futura HS - Year of manufacture: 2023 - Machine type: automatic rotating-ring stretch wrapper (pallet winder) - Operating hours: less than 500 h - Capacity: up to 92 pallets/h (13 wraps, H 1,000 mm), 77 pallets/h (17 wraps, H 1,600 mm), 70 pallets/h (19 wraps, H 2,000 mm) - Pallet size: 800 x 1,200 mm - Load height: 1,000 - 2,000 mm (incl. pallet) - Load weight: 100 - 1,200 kg - Conveyor height: approx. 550 mm; speed 15 m/min - Machine height: approx. 4,862 mm; hall height from 7,000 mm - Pre-stretch: SCV-B carriage, electronically adjustable 150 - 400 % - Stretch film: LDPE / LLDPE, 17 - 23 µm, roll width 500 mm, max. diameter 250 mm, core 76 mm, max. weight 20 kg - Control: Siemens SIMATIC S7-1200 PLC, Siemens TP700 7" colour touch panel - Wrapping programs: 15 (expandable to 64), 12 steps/recipe, 4 password-protected access levels - Power supply: 400 V / 50 Hz, TN-S, control voltage 24 VDC - Compressed air: 6 bar, dry, oil-free - Documentation and HMI languages: German / English Equipment - High-speed rotating ring: power transfer to the pre-stretch carriage via sliding contacts, Wi-Fi commands - Integrated roller conveyor with pneumatic pallet lifting station (SMC PL-D) - Automatic film clamping, cutting and wide-band sealing unit - Fixed vertical hold-down (top press unit) stabilises the load during wrapping - Roping device gathers the film web from below - Photocell for automatic pallet-height reading, plus a pre-scan photocell with 3,800 mm reflector mast Ledpfx Aezzz R Djmvsag - Inverter-controlled IE3 motors, SEW geared, IP55, FESTO pneumatic components, SICK photocells - Siemens Scalance S615 VPN / firewall router and Scalance XB005 Ethernet switch, TCP/IP link to up-/downstream machines - Safety: Reer Safegate SMPO 1803 light curtain, fenced enclosure, dynamic fall protection on the ring - Operator panel separate from the main switch cabinet, plus remote control unit with emergency stop - R-Connect remote monitoring hardware: cloud portal for production data and teleservice - TPM package (centralised lubrication points, maintenance intervals on display), integrated HMI troubleshooting - Complete documentation on USB stick and in print: operating / maintenance manual, wiring / pneumatic diagrams, spare parts catalogue, layout Condition Used - almost as new, no visible production wear. Still installed and under power; inspection in operation on request. Sold without warranty. Availability Immediately. Location: Germany. Handed over dismantled and packed (EXW).

Condition: used, Year of construction: 2021, Overview This Robopac Helix 4 EVO pallet winder was built in 2021, with less than 500 operating hours - technically close to new. The arm carries the pre-stretch carriage around the stationary pallet, so the load itself is never turned - the configuration for unstable, fragile or heavy loads at high output (capacity below). Built as a stand-alone unit. Technical data - Manufacturer: Robopac - Model: Helix 4 EVO - Year of manufacture: 2021 - Machine type: automatic rotating-arm stretch wrapper (pallet winder) - Operating hours: less than 500 h - Capacity: 82 pallets/h (11 wraps, 1,000 mm H), 73 (15 wraps, 1,600 mm H), 64 (19 wraps, 2,000 mm H) - Wrapping cycle time: approx. 36.3 s at H 1,600 mm, 15 wraps (conveyor excluded) - Pallet sizes: 800 x 1,200 mm and 800 x 600 mm, centred on the conveyor - Load height: 1,000 - 2,000 mm incl. pallet; mechanical max. 2,550 mm incl. pallet and conveyor - Load weight: 100 - 1,200 kg - Conveyor speed: 15 m/min - Machine height: 4,721 mm; hall height from 7,000 mm - Pre-stretch: PGSA carriage, electronically adjustable 100 - 400 % Ledpszzz Rdefx Amvsag - Stretch film: LDPE / LLDPE, 17 - 23 µm, roll width 500 mm, max. dia. 250 mm, core 76 mm, max. weight 16 kg - Control: Siemens SIMATIC S7-1500 PLC, TP700 7" colour touch panel - Wrapping programs: 15, expandable to 64, 12 control steps per recipe, 4 password-protected access levels - Power supply: 400 V / 50 Hz, TN-S, control voltage 24 VDC - Compressed air: 6 bar, dry and oil-free - Documentation and HMI languages: German / English / Italian Equipment - Rotating arm on a four-column steel structure, geared slewing ring with central lubrication - Patented PGSA pre-stretch carriage with load cell, film tension corrected at the corners, set from the display - Automatic film clamping, cutting and impulse-sealing unit, spring gripper with 300 mm horizontal stroke - Easy Lock tilting roller and roping device for narrowing the film web from below - Pantograph top press unit for load stabilisation during wrapping - Photocell for automatic pallet-height reading - Integrated roller conveyor, pallets loaded and unloaded by forklift - SEW IP55 geared motors for arm rotation and carriage lift, FESTO pneumatic components - Glazed enclosure with Sick M4000 light curtains, 30 mm resolution, 1,800 mm field height - Enlarged illuminated switch cabinet and a separate, independent operator panel - TPM package: centralised lubrication points, gauges with red/green rings, maintenance intervals on the display - Troubleshooting in the HMI with fault location and remedy - R-Connect remote connectivity with cloud portal for production data and teleservice - Documentation printed and on USB: manual, CE declaration, diagrams, spare parts catalogue, layout Condition Used - virtually new, dismantled and professionally packed for transport; photographs show it assembled before dismantling. Sold without warranty. Availability Immediately. Location: Germany. Handed over dismantled and packed (EXW).

Condition: used, Year of construction: 2005, Machine, and good Condition Inspektion in our warehouse Ledpfjzzyxyex Amveag

Condition: new, Year of construction: 2024, functionality: fully functional, Semi-automatic horizontal orbital stretch wrapping machine designed for wrapping long products such as timber, aluminium profiles, plastic extrusions, pipes, textiles and similar materials. Equipped with infeed and outfeed roller conveyors for easy product handling. Modell Robopac Compacta 12 Production year 2024 Installed power 1,5 kW Ljdozkf Skepfx Amvsag Diameter 1200 mm Feeding roller Yes Outfeeding roller Yes Condition New (not used) Conveyors 2 pc. INCLUDED

Condition: used, machine/vehicle number: 008667, Max width workable: 800 mm Max height workable: 800 mm Lodpfx Amezruzdsvsag

Condition: excellent (used), LINE of packaging with cardboard. Capacity: 6–8 boxes per minute. Packaging line for furniture components, featuring manual, continuous filling of the boxes with furniture parts, automatic hot-melt adhesive sealing, and automatic unloading by KUKA robot. The line consists of: a) Infeed roller conveyor b) Stretch wrapping machine (plastic film), ROBOPAC, Model Orbit 12 Lasdpfezxn U Dox Amvsg c) Carton box forming machine, AUTOMATECH ROBOTIK d) Hot-melt adhesive gluing machine, DYNATEC, Model DynaMelt e) Printer, LIMITRONIC, Model V L 780 SE R 1 R3 1 ES f) Vacuum handling system, PROTUBE HANDLING SOLUTIONS g) Robot, KUKA, Model KR C4 NA UL

Condition: used, Year of construction: 2000, Robopac ROBOTAPE 50 M is a band wrapping machine manufactured by Robopac in 2000, with a format of 500 x 500 mm. Currently stored in Germany, it can handle a maximum carton weight of 50 kg and is in good condition without any damages. The delivery terms are FCA. Format: 500 x 500 mm Equipment: Tape winding machine Lajdpfx Amewvut Dsvjg Max. Carton weight kg 50 Good condition without any damage

Year of construction: 2015, condition: excellent (used), functionality: fully functional, - Year of manufacture: 2015 - Weight: 190 kg - Overall length (with roller conveyors): 5,500 mm - Width: 1,200 mm - Height: 2,050 mm Other dimensions: Roller conveyor width: 360 mm The machine is in very good technical condition. The machine can be inspected and tested in Poland at the following address: 33-350 Piwniczna Zdrój A video demonstrating the machine in operation is available. Laodpfx Aoy Rx Smjmvjg Delivery possible.
