Tool holder / tool holder

SANDVIK COROMANT VDI 30 - CAPTO C3

Condition: reconditioned (used), Year of construction: 2008, functionality: fully functional, turning length: 1,250 mm, turning diameter over cross slide: 500 mm, turning diameter: 390 mm, spindle speed (max.): 5,000 rpm, spindle bore: 65 mm, travel distance X-axis: 450 mm, travel distance Y-axis: 200 mm, travel distance Z-axis: 1,300 mm, bar passage: 65 mm, total height: 2,700 mm, total length: 7,000 mm, total width: 3,000 mm, overall weight: 12,000 kg, Equipment: documentation/manual, Manufacturer: DMGMORI Type: CTXbeta1250TC Year of manufacture: 2008 (retrofit in 2022) Control: Siemens 840D Solutionline Number of axes: 5 axes Equipment: - automatic tool changer - swivel head as B-axis - belt filter system with internal cooling and chip conveyor - differential pressure clamping main/counter spindle - workpiece collection device - preparation for bar loader (optionally available) Technical data: Max. turning diameter 500 mm X-axis 450 mm Y-axis 100 mm Z-axis 1300 mm Hnodpsubyv Refx Aaceh B axis 220 ° Spindle bore 65 mm Speed 5000 rpm Spindle power 34 kW Counter spindle speed 6000 rpm Counter spindle passage 52 mm Counter spindle power 20 kW Tool changer 24 B-axis mount HSK 63 B-axis spindle speed 12000 rpm B-axis power 22 kW Installation dimensions approx. L 7000 / W 2300 / H 2300 mm Weight approx. 8,000 kg Chip conveyor: Yes Coolant device: Yes Internal coolant supply: Yes Options: · Full cabin · NC swivel head as B-axis · Coolant device and chip conveyor · Documentation · Geometrically within the new machine tolerances Condition: - Machine fully functional - Geometry within the manufacturer's tolerance for new machines - All wear parts replaced Retrofit 2022: - Linear guides Z1 and Z2/3 replaced - Linear guide Y-axis replaced - Main and counter spindle overhauled - Milling spindle overhauled - B-axis (bearings and clamping) renewed - sliding plates overhauled - hoses and cables overhauled, drag chains revised - cabin doors repainted, viewing windows renewed - maintenance carried out according to manufacturer's specifications

Condition: good (used), Year of construction: 1998, Manufacturer: Henninger Type: ZS-201 Year of manufacture: 1998 Self centerring device Double column slide ways Dressing Unit Tailstock by rack & pinion Eccentric adjustment 0 - 20 mm Large Cone-Stone tooling package Specifications Metric US Standard Hsdpfx Asvt Tuijacjnh Minimum workpiece Ø 20 Ø Min. Maximum workpiece Ø 450 Ø Max. Max. product length 1200 mm Speed 18300 Rpm Max. grinding angle 45 - 120 ° Max. workpiece weight 190 Dimensions (estimate) Length 1250 mm Width 1250 mm Height 1900 mm Weight 365 kg Please note: The information on this page has been compiled to the best of our knowledge and belief by us and, where possible, by the manufacturer. The information is provided in good faith but accuracy cannot be guaranteed. Accordingly, it will not constitute a representation and terms of contract. We recommend that you review all important details.

Condition: excellent (used), Year of construction: 2007, turning length: 1,545 mm, turning diameter over cross slide: 660 mm, spindle bore: 65 mm, travel distance X-axis: 580 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 1,545 mm, Make: MAZAK Type: INTEGREX 200-4 ST Control: MAZATROL MATRIX Year: 2007 Multi-Tasking Machining in a Single Machine Setup Sub spindle for overtaking with full C-Axis The INTEGREX IV series can finish all machining processes. High speed, advanced milling spindle that can tilt up to 240 degrees swiveling. Lower turret with rotary tool spindle so livew tooling Chip conveyor with coolant and 15 Bar iKZ Double chuck KNCS-N 210-53 SMW Autoblock MAZAK Flex -GL150F Gantry Loader Gripping range 200 x 120 length x 15 Kg Hnodpfx Aaex S Hm Ijceh Max. turning Ø: 660mm X-Axis: 580mm Y-Axis: 160mm Z-Axis: 1545mm B Axis: 270° Spindle bore: 65mm Speedrange: 5000Rpm Spindle power: 22kW Subspindle speeds:5000Rpm Subspindle bore: 65mm Subspindle power: 18.5kW ATC / revolver: 40 B-Axis Toolsystem:Capto C6 B-Axis Speedranges:12000Rpm Length: 5200mm Width: 2550mm Height: 2600mm Weight: 14000kg

Condition: good (used), Year of construction: 2011, CNC Milling and Turning Center Machine Type: DMG CTX beta 1250 TC Control: Siemens 840 D solutionsline + ShopTurn Hsdpfsxvaqrsx Aaconh Year of Manufacture: 2011 Available from: February 2026 TECHNICAL SPECIFICATIONS: Maximum turning length: 1,250 mm Turning diameter: 390 mm Bar capacity: 75 mm Main Spindle Speed range: 0 - 5,000 rpm Drive power: 34 / 25 kW C-axis: 0.001° 3-jaw chuck: Röhm KFD-HS 250-91 mm Counter spindle: ISM 52 Speed range: 6,000 rpm Drive power: 27 / 20 kW C-axis: 0.001° 3-jaw chuck: Röhm KFD-HS 200-66 mm CNC spindle swiveling for milling and turning operations B-axis: +/- 110° Speed range: 15 - 12,000 rpm Drive power: 22 kW Torque: 100 Nm Tool holder: HSK 63 Tool stations: 24 Y-axis: 100 +/- mm Machine weight: 8,000 kg Footprint (LxWxH): 5.67 x 2.72 x 2.1 m Features: Chip conveyor High-pressure pumps: 8/20/80 Paper band filter Coolant tank: 980 l Oil mist extraction Tool breakage control: Renishaw

Condition: excellent (used), Year of construction: 2015, Technical data: Capacity Max. swing diameter Ø 600 mm Max. turning diameter and length: Ø 370 x 750 mm Through-hole: Ø 82 mm Spindle Axis height from floor: 1,140 mm Spindle bearing/bore diameter: Ø 140 / Ø 90 mm Spindle nose A2-8 Spindle speed: 4,200 rpm C-axis resolution: 0.001 ° Counter spindle Axis height from floor: 1,140 mm Spindle bearing/bore diameter: Ø 90 / Ø 53 mm Spindle nose F-140 Spindle speed: 6,000 rpm C-axis resolution: 0.001 ° Stroke lengths and rapid traverses Stroke lengths X-axis: 267 mm, Z-axis: 840 mm Y-axis: -50 ~ +70 mm, A-axis: 780 mm Rapid traverse stroke X-axis = 30 m/min Z-axis = 30 m/min Y-axis = 10 m/min A-axis = 30 m/min Power Spindle motor (30 min. / 100% duty) AC 22 / 15 kW Max. torque: 618 Nm (S3 25%) Driven tools Number of tool stations on turret: 15 pcs Max. tool speed 6,000 rpm Drive power (30 min. / 100% duty) 7.5/3.7 kW Maximum torque 48 Nm Tool equipment Driven tool stations: 15 pcs Tool cross-section: 25 x 25 mm For boring operations: Ø 40 mm Dimensions Height: 2,300 mm Depth (without chip conveyor): 2,140 mm Width (without chip conveyor): 3,000 mm Hedpjwp Uhhsfx Aacsnh Net weight: 6,200 kg

Condition: good (used), Year of construction: 2009, 750mm Swing, 540mm max. machining diameter, 1020mm max turning length, 5000rpm main spindle, 5000rpm Sub spindle, 65mm bar capacity, 12 station lower turret, 12000rpm milling 18.5kW, Hnedpfxew Npz Io Aaceh 22kW spindle motors, FANUC 3iTB control, 3 Jaw Power Chucks, tool setter, Swarf Conveyor, Coolant

Year of construction: 2014, condition: ready for operation (used), General Data Machine weight 15500 kg Main Drive Number of axis 7 Spindle Speed 4000 RPM Spindle motor power 22 kW Control Unit Brand FANUC Model Series 31i-MODEL B5 Movement X-Axis Movement 630 mm Z-Axis Movement 1585 mm Y-Axis Movement 115 mm This 7-axis DOOSAN Puma MX2600ST was manufactured in 2014, featuring a robust horizontal turning machine design. It includes a B-axis of +/-120 degrees, extensive X, Y, Z travels, and a bar capacity of 76mm. The machine is equipped with a FANUC 31i-Model B5 control, a 40 station tool changer, and a 22kW spindle motor. If you are looking to get high-quality turning capabilities consider the DOOSAN Puma MX2600ST machine we have for sale. Contact us for more information. Hnsdpfxex D E Ras Aacsh Application Types Turning

Condition: like new (used), Multicut 500i 5-axis turning center in very good condition. (X-, Z¹-, Z²-, C-, B-, Y-axis). The machine was installed in September 2014 and regularly maintained. It is a very powerful and highly precise machine. Spindle on: approx. 13,700 hours, spindle hours: 4,500 Main technical data: CNC Siemens 840D Swing diameter over bed: 1,030 mm Maximum turning diameter: 690 mm Turning length: 1,693 mm Y-axis: 370 mm Spindle bore: 106 mm Bar capacity through draw tube: 94 mm Spindle speed: 3,500 rpm Spindle motor S1/S6 40% duty cycle: 59/74 kW Milling spindle: 12,000 rpm Milling spindle power S6 40% duty cycle: 22 kW Milling spindle mount: CAPTO C6 B-axis: -120º, +105º ATC magazine with 81 slots Linear scales in X, Z, Y Tailstock MK6, stroke 180 mm Machine dimensions (L x W x H): 5.4 x 3.86 x 3.76 m Machine weight: 22,800 kg Accessories: Forkart chuck type 3FNC with reversible hard jaws • Chip conveyor • Internal cooling through tool 60 bar Hnodpfew Uch Ssx Aaceh • Cooling gun • Automatic tool measurement • Automatic door opening • Servo-controlled hydraulic steady rest type SMW SR 5.1 (85 to 350 mm diameter), automatic up/down movement

Condition: like new (used), Year of construction: 2023, Mazatrol Smooth Ai 5-axis simultaneous machining Max. turning diameter 670 mm Max. turning length 1,519 mm Travel distances X-axis: 695 mm Y-axis: 300 mm Z-axis: 1,585 mm W-axis: 1,569 mm B-axis: -30 to 210° Rapid traverse X/Y/Z/W 50/40/50/30 m/min Main spindle Drive power: 30 kW Max. spindle speed: 4,000 rpm C-axis Max. bar capacity: 80 mm Sub spindle Drive power: 26 kW Max. spindle speed: 4,000 rpm C-axis Milling spindle Max. spindle speed: 12,000 rpm B-axis Capto C6 Tool magazine / ATC 38 tool stations Through-spindle coolant, preparation up to 70 bar 5-axis simultaneous machining package Hedpfxsww N Ixj Aacjnh G00 slope constant Tool ID system ID chip Synchronized thread cutting Cylindrical interpolation Interface for bar feeder Automatic parts catcher Parts catcher Kitagawa B210X 3-jaw chuck for main spindle Kitagawa B210X 3-jaw chuck for sub spindle Cromar Series iV chip conveyor Drum filter High-pressure pump 15 bar Bar feeder EMT Super 80
