Panel saw

SCHEER FM16 3100

Panel Dividing System SCHEER FM 16 – DNC 3100 x 3100
As New – Machine No. 33542

The SCHEER FM 16 is a high-performance, electronically controlled panel dividing saw featuring advanced drive technology and an intuitive control interface. The machine has been fully overhauled and newly painted – its condition is virtually as new. Ideal for precise, automated cutting of wood-based panels in continuous industrial operation.

Main Technical Data:
• Cutting length: 3100 mm
• Cutting depth / Blade projection: 80 mm
• Saw motor: 7.0 kW
• Scoring motor: 1.1 kW (can be switched off)
• Feed speed: 2 – 40 m/min (steplessly adjustable)
• Return: Rapid traverse, automatic lowering
• Operator interface: SCHEERWIN, graphical, document-oriented (64-bit) on Windows 10
• Drive system: Küenle frequency inverter with Stöber synchronous servo drives incl. absolute encoder – for highest positioning accuracy and dynamic control

Features & Highlights:
• FM 16-3100 longitudinal cutting saw with hardened guides and automatic forward/reverse travel
Ndedpfeunwk Tsx Ah Djd
• HP 5021 material feed table with 6 clamping carriages, servo drive & measuring resolution of 0.05 mm
• WP angular pressure system, 2400 mm adjustment range, fully automatic
• SP 5000 remnant cutting device for offcuts down to min. 5 mm
• HP 5024 miter fence table (1800 x 800 mm), steel angle with Pertinax overlay
• HP 5025 workpiece support table (1800 x 800 mm), also with Pertinax overlay
• Air cushion system in the front tables, including radial fan

Saw blades included:
• KSB 4005 for main saw (ø 305 mm, Z = 60)
• KSB 4006 for scorer (ø 200 mm)

Condition & Service:
• Condition: Overhauled & as new
• Functionality: Fully operational
• Warranty: 12 months

Reliability in Continuous Operation:
This machine is in use worldwide – even under extreme conditions. Whether in the dry climates of Africa or the humid environments of Southeast Asia (e.g., Thailand), the SCHEER FM 16 operates reliably in 3-shift systems – 365 days a year – and stands out for its superior precision, stability, and durability.

Warranty:
We are so confident in the quality and robustness of our machines that we offer a 7-year warranty on the machine frame and guideways.
(Excludes electrical supplier components and wear parts.)

Flexibility & Customization:
We offer various models and equipment options – to fit every budget. We also realize custom tailored solutions based on your individual requirements.

📞 Contact us for an individual offer or to arrange a viewing appointment.

Machine available from stock. Delivery, commissioning and training optionally available.
