Vertical Turret Lathe - Single Column

SCHIESS MOWEG BERTHIEZ TFM 125

Condition: excellent (used), Year of construction: 1983, Faceplate diameter: 1250 mm Max. swing diameter: 1400 mm Max. swing height: 1160 mm Nlodpjy Ex Epsfx Agrjg Max. ram stroke, vertical / horizontal: 755 / 840 mm Table load capacity: unlimited Faceplate speed range: 5.6 - 300 rpm Vertical slide angular adjustment: 45° Feed rate range: 0.044-8 mm/rev Rapid traverse rate: 2 m/min Drive power: 55 kW Footprint L x W x H: 2660 x 2710 x 3360 mm Total weight: 16,500 kg Accessories / Special features: • 2-axis digital display, manufacturer: ACU-Rite • Faceplate, Ø 1250 mm, with 4 chuck jaws • 5-position turret • Taper turning • Profile turning Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel / Germany

Condition: good (used), Manufacturer: WMW Zeulenroda Type: PYE 160 SS Year of manufacture: 1980 C-frame construction Die height 850 mm Thickness bolster plate 100 mm Throat C side 360 mm Specifications Metric US Standard Capacity 160,000 Table length 1,250 mm Table width 600 mm Ram stroke 500 mm Starting speed 100 mm/min Working speed 10 mm/min Return speed 125 mm/min Power 22.5 kW Nedpfjwp Nv Hsx Agrjlg Dimensions (Estimate) Length: 2,150 mm Width: 1,250 mm Height: 3,600 mm Weight: 7,500 kg Please note: The information on this page has been provided to the best of our knowledge and, where possible, from the manufacturer. The information is given in good faith, but accuracy cannot be guaranteed. Accordingly, they do not represent a warranty or contract terms. We recommend you check all important details.

Condition: used, WEBSTER & BENNETT EV 36” HIGH SPEED VERTICAL BORER MAKE WEBSTER & BENNETT, MADE IN ENGLAND MODEL EV 36” TABLE DIA 915 mm SWING 1168 mm HEIGHT UNDER RAIL 533 - 1016 mm SPEED 13.5 - 300 rpm FEED RATE 0.005-0.250 inch/min MAIN SPEED 40 HP PLUS HIGH SPEED TAABLE EV SERIES MACHINE Nljdpfxexp Na No Agrsg ELEVATING RAIL SAFETY GAURDING SET OF JAWS FULLY FUNCTIONAL GOOD SLIDES

Condition: excellent (used), Year of construction: 2009, turning height: 1,280 mm, total height: 5,600 mm, total width: 3,850 mm, total length: 4,260 mm, rotary table diameter: 1,400 mm, workpiece diameter (max.): 1,600 mm, overall weight: 21,500 kg, CNC Vertical lathe Fremtas - 16FR3 MACH-ID 9467 Make: Fremtas Nodjy Htilspfx Agrjlg Type: 16FR3 Control: FAGOR 8055 TC Year: 2009 Work load 6300 Kg Cross rail adjustment 660 mm Feed rate cross rail 0 - 400 mm/Min Feed rate 0 - 3000 mm/Min Rapid feed 0 - 8000 mm/Min Central lubrication Chip conveyor RAM with Sandvik COROMONT C8 Tooling C8 with double connector Ca 10 units CAPTO Tool system 4 extra heavy duty jaws Max. turning Ø: 1600mm Table Ø: 1400mm Horizontal movement support:1000mm Speeds / ranges: 1 - 200Rpm Power: 75kW Maximum turning height: 1280mm Vertical movement support: 700mm Length: 4260mm Width: 3850mm Height: 5600mm Weight: 21500kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: used, faceplate diameter 3100 mm swing diameter 3600 mm turning height 3600 mm control Fagor 8035 table load 35 t turning speeds 0,32 - 40 U/min max. ram stroke 3000 mm table load 35 t turning speeds 0,32-40 U/min total power requirement 70 kW 2x Ram head 250 x 250 mm Chip conveyor Mist extraction unit Coolant system The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale Nsdpfxeyqt Hdo Agrslg apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: good (used), Year of construction: 1999, functionality: fully functional, turning length: 3,000 mm, turning diameter: 1,000 mm, spindle bore: 197 mm, Upon request, videos of the machine in operation can also be provided. Maximum turning length: 6000 mm Turning diameter: over cross slide: 1000 mm over bed: 1250 mm Spindle bore: 197 mm Spindle speeds: 0 – 665 rpm Faceplate diameter: 1200 mm Workpiece weight: 15000 kg between centers Motor power: 55 kW / 74 hp 3 gear stages: 1.5-55 / 50-180 / 180-665 rpm Accessories: Sauter 4-position tool turret (rotation defective) Tailstock (hydraulics partially defective, pressure loss) Chip conveyor 2 chip guard doors (incl. safety device) 4-way bed machine (flat bed) LED lighting Nlodpfx Agoyr N N Rerog

Condition: used, Technical details: turning diameter over bed: 3800 mm turning diameter over slide rest: 3200 mm turning length: 12000 mm Nsdox Ngzyopfx Agrslg faceplate turning speed range -stepless-: 2 - 200 U/min max. workpiece weight: 90.000 kg bed width: 4000 mm 2 steadies *

Condition: new, Year of construction: 2025, functionality: fully functional, turning height: 1,600 mm, turning diameter: 2,000 mm, CNC Vertical Turning Center Model: VTC-16/20R with Fanuc 31i-B Table Diameter: Ø1,600 mm Max. Swing Diameter: Ø2,000 mm Max. Turning Height: 1,600 mm Table Speed: Max. 250 rpm Table Load Capacity: 8,000 kg Table Indexing Speed: 720°/min Table Indexing Accuracy: 0.001° X-Axis (Ram horizontal): -100 mm to 1,170 mm Nedpfx Agjxp Nb Terelg Z-Axis (Ram vertical): 900 mm Drive Spindle Speed: Max. 2,000 rpm Ram Size: 240 mm x 240 mm Milling Spindle Taper: ISO 50 Tool Shank Size: 40 mm x 40 mm Crossrail (vertical travel): 250 mm x 3 stages (hydraulic) Table Drive Motor: AC 37/45 kW (continuous/30 min. duty) Milling Spindle Drive Power ISO 50: 15/18.5 kW (continuous/30 min. duty) Control System: Fanuc 31i-B Display Unit: 15-inch TFT-LCD Memory Capacity: 1 MB Automatic Tool Changer: 24 positions (for 7 turning tools + 1 cover + 16 milling tools) Standard Tool Holders: New 240 TCR-01 (2 pcs) Splash Guard: Table version (R-Type standard design) External Coolant System: 3 bar (80 l/min) Chip Conveyor: Hinged belt type Table Bearing Cooling Device 4-Jaw Independent Manual Chuck Foundation Anchor Bolts / Base Plates Maintenance Tools and Toolbox Hydraulic Power Unit Work Area Lighting Signal Lamp: 3 colors (green, red, yellow) Operating Manuals (English): 1 CD with Fanuc manuals and 3 books with mechanical/electrical manuals Power Supply: 220 V, 60 Hz, 3-phase Machine Color: Manufacturer standard OPTIONAL ACCESSORIES (#1) Turning Tool Holder: Type 240TCR, 4x included Rigid Tapping: 1x included OPTIONAL ACCESSORIES (#2) Automatic power-off for N.C. - on request Turning tool holder type 240TCR - on request Through-spindle coolant supply: 30 bar (pump pressure) - on request Transformer 415 V, 50 Hz, 3-phase - on request Linear scales X-, Z-axis (Fagor, Spain) - on request Workpiece measuring device - on request Tool measurement TS27R, Renishaw - on request Other information: INSTALLATION, COMMISSIONING, TEST OPERATION, AND TRAINING - not included in the price INSURANCE AND FREIGHT - not included in the price Image shows machine with pallet changer. The offered machine DOES NOT INCLUDE A PALLET CHANGER! Errors in technical data excepted. The scope of accessories is as described in the text of this article only. There is no entitlement to any other accessories, such as those shown for illustration purposes. The general terms and conditions of JS-Werkzeugmaschinen GmbH apply.

Condition: good (used), travel distance X-axis: 12,000 mm, travel distance Y-axis: 7,300 mm, travel distance Z-axis: 3,000 mm, total length: 30,000 mm, table length: 12,000 mm, table width: 4,730 mm, total width: 12,000 mm, total height: 10,475 mm, table load: 250,000 kg, overall weight: 400,000 kg, Make : Waldrich - Siegen - Typ : PF-F-150(1)-530/400 - No. : 11.093/0 - Age : Overhault 2004 ( Euro 2.2 Mil) X Travel : 12.000 - Y Travel : 7.300 - Z Travel : 3.000 - W Travel : 4.000 - Between column : 5.000 - Table width : 4.730 - Table length : 12.000 - Table load : 19 t / mtr. Ca. 250 ton - Table feed : 10.000 mm/min. - W axis : 3.000 mm/min. - T axis : 6.000 mm/min. - Cross adj. milling head : - Vert. adj. cross rail : - Horizontal hydrostatic spindle ram - Milling spindle Ø : 560 - Milling tool taper : iso 60 - C axis feed : 5.000 mm/min. - Milling motor : 90 kW - Spindle speed : 2.500 R/pm - Z axis stroke : 3.000 - Z axis feed : 2.000 mm/min. - Milling Küma Angle head WF2 90 kw- 450 - Milling Küma Uni. UB1D 60 kw - 2400 - Milling Küma Fixed GB1D 90 kw- 2400 - Milling Küma Angle head WF1? - Electric requirement : 3 x 400 V / 50 Hz - Power requirement : 600 kVA / 630 Amp - Capacity 4.000 L coolant true spindle 20/40 Bar Machine is rebuild in 2004 by Schiess Bed – Table assembly group: * Renewal of sliding lining * Grinding of guideway * Renewal of table drive * Direct linear measuring syst. * Hydrostatic Portal and cross rail: * Modification of adjusting spindle trape Zoidal spindle was recplaced with ball screw * Direct linear measuring syst. * New drive motors for relization of higer speed on feed axes of milling support. * New milling support with hydrostatic guideways Electric system: * Complet elctric cabinet switchgear * Complet new wire * Siemens Sinumrik 840 D in 6 axis !! Equipment / parts : * Complet new raumag janich covers Nodpfx Aeytrxkegrelg * Complet new double chip conveyor * Complet with big tooling packet * Complet with big mounting equipment - Under power in Europe - Free directly - Controlled axis X / Y / Z / W / C / B axis - Over all height : 10.475 mm - Over all width : 11.934 mm - Over all length : 30.000 mm - Total weight : ca. 400.000 Kg Rebuild in 2004 for EUR 2.200.000 !This CNC Waldrich Portal milling machines was used in the Energie Field for steam turbien case machining. Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: used, Year of construction: 1973, functionality: unexamined, Vertical Turret Lathe - Double Column | Brand: TITAN | Type: SC 2500 Year of manufacture: 1973; modernization in 2011 to Siemens SINUMERIK 840D sl control system The machine is a ‘TITAN’ model, i.e. from a Romanian manufacturer. However, the design is licensed from SCHIESS in Düsseldorf and is therefore comparable to the well-known SCHIESS machines from that period. The machine was professionally disassembled by technicians from the machine manufacturer SCHIESS, properly preserved and placed in storage by the owner. TECHNICAL SPECIFICATIONS / EQUIPMENT: - Faceplate diameter: 2.500 mm - Swing diameter: 2.600 mm - Max. workpiece weight: 12 tons - Turning height: 1.600 mm - Number of turning supports / RAMs: 2 * Ram dimensions: 250 x 210 mm each - Main drive: 55 kW EQUIPMENT: - CNC control: Siemens SINUMERIK 840D sl - Tool turret (right) - Chip conveyor Dimensions / Weight: - Installation area: 5.600 x 4.800 mm - Hall space inc. operating and service areas: approx. 7.000 x 7.000 mm - Machine height: 6.200 mm - Machine weight: approx. 45 tons Njdpozlb H Tefx Agrjlg There is no guarantee for correctness and completeness of the technical details and accessories. - Subject to prior sale -
