Vertical Turret Lathe - Single Column

SCHIESS-FRORIEP 27 DE 250 - Retrofit

Condition: used, Year of construction: 2001, functionality: fully functional, machine/vehicle number: 124, Price upon request Used CNC Vertical Lathe Manufacturer MORI SEIKI Model VL 55 Year of manufacture 2001 With MSC 518 CNC control, 12-tool turret, and chip conveyor Turning length = 653 mm Turning diameter = 550 mm X-axis = 350 mm Z-axis = 660 mm Speed up to = 2000 rpm Spindle power = 30 kW Approx. weight = 12.5 t Price upon request Specifications: Used CNC Vertical Lathe Manufacturer MORI SEIKI Model VL 55 YOM 2001 With MSC 518 CNC control, 12-tool turret, and chip conveyor Djdpfowl An Iex Ah Sjul Turning dia. = 550mm Turning length = 653 mm X-Axis = 350mm Z – Axis = 660 mm Speed = 2000 rpm Spindle power = 30 kW Weight approx.. = 12.5 t

Year of construction: 1998, condition: good (used), CHIRON FZ 18L 1998year Sinumerik 810 with 4 Axis Nikken Travels Dedjhpq U Ujpfx Ah Ssul X 2000 mm Y 400 mm Z 425 mm table2280 x 450 mm spindle max 8000 Toolchanger ATC: 20 pos tools SK 40 weight 6,70 T manual books dimensions lenght 3,9m width 2,45m height 2,8m free loaded on truck EXW 01360 LOYETTES

Condition: ready for operation (used), Year of construction: 2018, travel distance X-axis: 470 mm, travel distance Z-axis: 876 mm, spindle motor power: 30,000 W, spindle speed (max.): 1,250 rpm, rapid traverse X-axis: 24,000 m/min, rapid traverse Y-axis: 24,000 m/min, turning diameter: 1,000 mm, total length: 2,375 mm, total height: 3,659 mm, total width: 4,558 mm, type of input current: three-phase, torque: 3,655 Nm, input voltage: 400 V, overall weight: 14,000 kg, Equipment: cooling unit, CNC Vertical lathe MAZAK Mega Turn 900 Dodpfx Asw T Tmpsh Ssul TECHNICAL CHARACTERISTICS: CNC control: MAZATROL SmoothG Max. turning diameter: 920 [mm] Max. cutting diameter: 1000 [mm] Stroke X axis: 470 [mm] Stroke Z axis: 876 [mm] Rapid traverse rate X axis: 24000 [mm/min] Rapid traverse rate Y axis: 24000 [mm/min] Spindle nose: A2-15 Max. spindle speed: 1250 [rpm] Spindle power: 30 [kW] Spindle torque: 3655 [Nm] Min. distance from spindle face to turret face: 154 [mm] Max. workpiece weight: 3000 [Kg] Max. distance from spindle face to turret face: 1030 [mm] Number of tool stations: 12 Turret indexing time: 0.4 [s/pos] Lubrication tank capacity: 516 [l] Total power required: 58.9 [kVA] Supply voltage: 400 [V] Dimensions: 2375 × 4558 × 3659 [mm] Weight: 14000 [Kg] More information available upon request.

Condition: refurbished (used), Year of construction: 1974, functionality: fully functional, machine/vehicle number: 1276, CNC Hot Radial Forging GFM SX-13 New in 1974 / 2022 New control system PLC SIEMENS S7 Machine number: 1276 No. of Hammers: 4 Forging force each hummer: 160 Ton Hammer stroke / min: 700/min Hammer lenght: 240 mm Diameter setting range: 80 mm Maximum forging diameter: Structural steel, round-cross section: Ø 130 mm square cross section: Ø 115 mm Smallest dimensions forged: Ø 25 mm Manipulator A max. displacement: 6820 mm Dujdpfsq U R T Njx Ah Sol Manipulator B max. displacement: 7150 mm Maximum workpiece length: 6000 mm Rapid speed manipulator: 400mm/sec Total connected power: 300 kW 380 V, 50 Hz Machine dimensions: Forging height over floor: 615 mm Total height pf the machinr over floor: 1665 mm Total machine lenght: 32670 mm Total foundation lenght: 33400 mm Tot. machine width (without auxliary equipments): approx 3885 mm Total foundation width: 16000 mm Total weight of the machine: 84.000 Kg

Condition: used, Year of construction: 1998, swing diameter 2000 mm table diameter 1800 mm turning height 1500 mm Control Siemens Sinumerik 840 C table turning speeds 0-280 U/min feed range 0-18000 mm/min workpiece weight max. 12000 kg Dedexap Eyspfx Ah Soul total power requirement 177 kVA Feed drives: - Crossbeam support, vertical and horizontal mm/min - Crossbeam support, rapid traverse 18000 mm/min - Crossbeam adjustment speed 425 mm/min Milling drive: - Milling drive power 30 kW - Number of gear stages 2 stages - Stage jump 3.17 - Speed range of the 1st gear stage 10 - 224 - 950 rpm - Speed range of the 2nd gear stage 32 - 72 - rpm Tool system, cutting force: - Tool system 250.2 - Milling spindle holder according to 69871-A SK 50 - Cutting force on turning tool 50 kN Equipment/accessories: - Tool measuring probe - Various turning tool holders - Various clamping jaws - Various clamping devices - Various SK 50 mountings - Grinding spindle - Powered tools - Tool changer/head changer - Hydraulic unit - Chip conveyor - Technical documentation

Condition: used, Year of construction: 1981, machine/vehicle number: 78.977, Equipment: documentation/manual, Year of manufacture: 1981 / Year of retrofit: 1996/1997 Control: Siemens 840 C Siemens control for X/Y/Z/W/U/B/V axes Spindle diameter: 200 mm Main motor Siemens: 68 kW Dsdpfx Ahsqc Umgs Seul Spindle speeds: I gear: 3 - 202 rpm II gear: 180 - 808 rpm X travel: 12,000 mm Y travel: 4,500 mm Z travel: 2,400 mm (supporting sleeve □ 520 mm/travel 1200 mm + W axis 1200 mm) Mount: SK60 (SK50) Facing slide: yes Milling head: 2 units Prepared for CNC rotary table (4th axis) Without rotary table and clamping field (available separately) Full documentation Net weight: approx. 140 tons Video available!

Condition: used, Technical details: faceplate diameter: 1000 mm swing diameter: 1600 mm Dsdpsvb Dcaofx Ah Seul turning height: 1200 mm main drive: 75 kW faceplate speeds from - to: 7 - 800 U/min milling motor: 25 kW milling head speed: 7 - 3000 U/min milling spindle - taper: ISO 50 cross rail adjustment - vertical: 800 mm ram head dimension: 240 x 240 mm weight of the machine ca.: 40 to dimensions of the machine ca.: 9 x 7,8 x 6,0 m Machine general overhould in 2004 and equiped with Siemens 840 D control - tool changer rack magazine - C-axis, live tooling, - Transmit function electronical Y-axis - angular milling head - complete splash housing - coolant device, chip conveyor *

Condition: used, TECHNICAL DETAILS - Number of axes : 2 - Table dimensions : 2500 [mm] - Table rotation speed : 1.25 - 160 [rpm] Dodpfowbkd Nsx Ah Seul - Max. turning diameter : 2800 [mm] - Maximum workpiece height : 2300 [mm] MACHINE HOURS - Number of working hours : 15557 [h] EQUIPMENT - CNC : FANUC Series 16i-T

Condition: ready for operation (used), controller model: Num 1040, swing diameter over cross slide: 7,500 mm, Robuuste draaibank met 4 geharde lineaire geleidingen Maximaal werkstukgewicht: 60 ton Hydraulisch contrapunt = automatische compensatie Dwarsslede voorzien van twee CNC gestuurde gereedschapshouders Siemens aandrijvingen en motoren Heidenhain-linialen en encoders Super Lathe-principe/licentie van Binns Machinery (VS). De ultieme prestatie voor zware draaibanken, bedoeld voor staalfabrieken, walsgieterijen en smederijen, voor de productie van producten zoals turbinerotoren, grote assen en staafproductie. Meest opvallende verschillen met een normale draaibank: veel breder bed = zeer hoge stijfheid = geen trillingen meer zwaar en omvangrijk vervoer ook voor stijfheidsdoeleinden zware werkstukken kunnen tussen de centers worden geplaatst het totale gewicht van de roldraaibank is erg hoog Duedjwaivbspfx Ah Sjl Swing over bed: 2000 mm Swing over cross-slide: 1700 mm Power on the spindle: 110 kW Number of speeds: 0,7 > 70 rpm

Condition: ready for operation (used), Broadbent Heavy Duty Lathe 1041mm x 10,000mm Duedpfx Ahev I T Ewe Sol Year approx. 1973. Swing over bed 1041mm (41”) Swing bin gap1575mm (62”) Distance between centres 9300mm (30’ 6”) Spindle bore 115m (4 ½”) Spindle speeds (18) 3.3 – 360 rpm Spindle motor 30 HP or 40 HP (To be confirmed) Tailstock 6 MT Imperial Metric screw-cutting with change gears. 36” Faceplate with 4 adjustable jaws, 54” Faceplate, Taper turning attachment, Power feed to top slide, 2 x 18” 3 point steadies, 24”/28” Steady.
