Edge banding machine

SCM me 40

Condition: used, Year of construction: 2022, Incl. 2nd glue pot. Glue thickness for roll edges: 0.4 - 3 mm. Glue thickness for strip edges: 5 mm. Min. - Max. workpiece height: 8 - 50 mm. Feed speed: 9 m/min. Pre-milling unit. Glue unit. Trimming unit. Rounding unit. Flush trimming unit. Radius scraper. Flat scraper. Buffing unit. Spraying unit. Storage location: Customer. Kodpsw Aig Sofx Abzjwu

Condition: excellent (used), SINGLE SIDE EDGE BANDER (Left) Edges (band in rolls) thickness (Min/Max) mm 0,4 / 3 Edges thickness in strips / lippings (min/max) mm 0,4 / 8 (12)* Panels thickness (min/max) mm 8 / 60 Numerical Control "StarTouch" + "Touch 7" Feeding speed m/min 12-18 Top pressure system with rubber belt (C.N.) Spraying unit (Anti-sticking liquid) AAR In-feed fence, adjustable by N.C. "EASY SIZE PLUS" Pre-milling Unit (vertical joint trimmers) 2 x Kw Lamps to heat the workpieces side Glueing Unit (P.U.R. Glue + Quick Melt system) "VC/800" - "VC/6" + "AirFusion AF15" Band Pressure zone (N.C. adjustment) Edge coils supporting unit - 1 Snipping (end-cutting) K/SEL Kwodpfjxlqntox Abzsu Rough Trimming unit RS/K Fine Trimming unit RI / 800 (3 pos.) Multi Function Unit (Profile contour Trimming Unit) “4 EDGE” KIT Spraying Unit (for sliding liquid) Profile edge scraping unit RAS/1000 Glue scraper RCA / 2C Milling grooving unit K-100 (1 x Kw 1,8) 90° Hot Air Heater (to reactivate the color of plastic tape) Panels Return System "SAG" Mod. SPINNER 47 / 63

Condition: new, The model ME 40TR is SCM’s ‘bestseller and in this category offering unrivaled price / performance ratio. Kwsdpfx Abec S Di Rozju We can offer the following new machine SCM me 40tr, CE Volt 400 EU, frequency 50 Hz edge thickness coils 0,4 - 3 mm max. edge thickness strips 5 mm min. – max. work piece thickness 8 - 50 mm feed speed 9 m/ min glue pot unit 0,18 kW, capacity 0,8 kg premiling aggregate 2,2 kW, 9000 U/ min end-cutting unit with "Radius" allows you to make a radius on the corners of the edged panel trimming unit 2 x 0,35 kW, 12.000 U/ min OPTIONAL device for panel preheating edge scraping unit flat scraping unit grooving unit 1,1 kW, 12.000 U/ min, notch width 4 mm brushing unit with 2 independent motors magazine for strip edges kid for quick exchange of glue unit ...

Condition: as good as new (ex-display), functionality: fully functional, Edgebander with most accessories in its technological range, with an excellent quality/price ratio. Kwodpfsqw Ux Tsx Abzeu Work table dimensions 3465 x 710 mm Min. ÷ max. thickness of rolled edges 0,4 ÷ 3 mm Max. thickness of edges in strips 5 mm Min. ÷ max. panel height 8 ÷ 50 mm Min. panel length/width 190/110 mm Feed speed 9 m/min This edgebander increases productivity with the feed track of the panel brought to a speed of 9 m/min and it guarantees high quality standards in processing thanks to the possibility of working with polyurethane glue, perform grooves, all being extremely easy to use. MACHINE COMPOSITION: ME 40TR AUTOMATIC EDGE BANDER 109999 Security execution R00341 me 40tr versione CE 930731 Volt 400 EU 931201 Frequency 50 Hz 580653 EDGE SCRAPING UNIT 580444 BRUSHING UNIT 580654 GLUE SCRAPING UNIT 580656 Spare glue pot for poliurethane glue with fast unloading system 580509 Device for the panel edge heating 580510 Anti-adhesive unit 580548 Spray-mist device for edge finishing 580658 "Nesting" copying device kit for Trimming unit 580659 "Nesting" copying device kit for Edge scraping unit 580666 Internal machine lightening

Condition: used, Year of construction: 2020, functionality: fully functional, type of input current: three-phase, workpiece height (max.): 45 mm, edge thickness (max.): 3 mm, Further technical data: Ball-bearing turntable for edge banding rolls, Ø 740 mm Ksdexdb U Ujpfx Abzjwu Edge thickness: 0.4 – 3 mm Workpiece height: 8 – 45 mm Extendable workpiece support up to 450 mm Manually adjustable workpiece height m-motion and x-motion PLUS control systems (highest setting repeat accuracy, programmable) Robust processing units in new design, solid machine base, precise extraction system Additional equipment: Surface scraper Spraying unit for cleaning agent LED lighting package Tempora 45.03 Spraying unit for release agent Cross-cut saw unit with 45° travel path and radius processing Pneumatic-mechanical infeed lock 75 x-motion PLUS package Tempora 45.03

Condition: used, Year of construction: 2009, Used SCM edgebander model OLIMPIC K1000 Control panel with membrane keyboard Technical data: Min. panel height: 8 mm Max. panel height: 55 mm Min. edge thickness (roll): 0.4 mm Max. edge thickness (roll): 3 mm Max. edge thickness (solid wood): 12 mm Configuration: Strip edge magazine Glue pot capacity 1.5 kg, with independent motor No. 4 pressure rollers with pneumatic feed, first roller with independent motor Edge roll guillotine End trimming unit with 2 independent motors, tiltable 0-15° - each 0.35 KW - 12,000 rpm Kwodpfx Aboxrndxezou Overlapping trimming unit with 2 motors, each 0.65 KW - 12,000 rpm - tools with reversible knives Tiltable corner rounding unit for flat/radius finishing; 2 motors each 0.5 KW - 12,000 rpm, electro-pneumatic positioning - tools with reversible knives Electro-pneumatic exclusion of the unit Glue scraper unit Machine length: 4,310 mm Year of manufacture: 2009 CE marked

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, Brand: SCM Model: OLIMPIC K 500 T/ER-2 - CE Automatic edge banding machine with sanding unit for wooden, veneer, PVC, melamine, ABS edges – suitable for furniture manufacturing, joinery, custom fittings, panels, kitchens, bathroom furniture, and various other applications Technical specifications: Min./max. panel height: 8–60 mm Panel height with corner rounding unit: 10–45 mm Edge thickness: 0.4–8 mm Edge thickness from coil: 0.4–3 mm Minimum panel width: 55 mm Feed speed: 11 m/min Pressure beam with motorized vertical movement Panel support rail Kwedpoxnvr Aofx Abzeu Sound-insulated safety enclosure Fluid inlets Components: Anti-adhesive spraying unit with two nozzles – two tanks for anti-adhesion liquid Pre-milling units with two high-frequency motors – H64 mm diamond tools – diameter 100 mm, bore 30 mm, height 65 mm – copying set Gluing unit VC 560 for edge application on panels up to 60 mm – glue pot capacity: 1.5 kg – exchangeable glue pot End trimming unit with two independent motors, each 0.35 kW at 12,000 rpm – motor tilt from 0° to 15° – 2 saw blades, diameter 115 mm – front copying devices Tilting trimming/bevelling unit for removing top and bottom edge overhang – 2 motors at 0.55 kW – 12,000 rpm – tilt range from 0° to 25° – two-position pneumatic set for quick change between thin or radius edges Corner rounding unit with two motors on prismatic guides – for rounding and trimming thin or thick edges – 2 motors at 0.55 kW – 12,000 rpm Edge scraping unit for optimal finishing of ABS/PVC edges with rotary copying and extraction hood, scrap collection cassette Glue scraping unit – removes glue residues from the lower and upper panel surfaces Buffing unit for cleaning and polishing plastic edges – motor 0.25 kW – brush diameter 150 mm Compressed air: 7 bar Overall dimensions: 5500 x 1150 x 1550 (H) mm Weight: 1,780 kg Recently serviced New diamond pre-millers New copying wheels...

Condition: used, Lange B90 KFE Edge thickness: 0.4 - 3 / 5 mm Control panel: PLC touch panel Pre-milling unit for workpiece edge preparation before the gluing section Automatic edge magazine for roll materials Teflon-coated quick-change glue pot for hot-melt adhesive granulate Workpiece height: 8 - 50 mm Fine-adjustable glue roller Guillotine shears up to 3 mm for pre-cutting roll material Pressure unit End trimming unit Multi-function milling unit for flush trimming, radius milling, and bevel milling Kodpjxl Aw Tjfx Abzowu Corner copying unit for head edges up to 2 mm, activatable from the control panel Radius scraper blade Flat scraper blade Buffing unit Spraying device at infeed and outfeed Year of manufacture: 2018 Machine is OPERATIONAL and in GOOD CONDITION Ex works price NET €15,000.00

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 2650x640x1400 mm Kwodpfxovz E T Hj Abzsu Weight 700 kg Total power requirement 5 kw
