Drilling and milling machine

Serrmac TCS E TC

Condition: new, Fastech 3-roll round bending machine FRS 1250 x 140 Technical specifications: Special equipment included in the price: hardened rolls motorized back roll adjustment motorized bottom roll adjustment 2 x digital display sheet width 1250 mm sheet thickness 5,5 mm max. sheet thickness 5,0 mm bending roll length 1250 mm roll diameter 140 mm smallest bending diameter 210mm weight 1365 kg dimension L-W-H 2020 x 900 x 1200 mm Motor:2,2 KW Equipment: Iodohzq Dxspfx Ahujtb upper and lower roller electr. driven upper roller can be swung out conical bending device asymmetric roller arrangement self-braking main motor sep. control and operation panel safety line values apply to St-37 / 240 N/mm² CE mark

Condition: excellent (used), CNC milling machine, ISO 40 spindle, rpm 60-3600, HP5, Strokes: x1200mm, Y550mm, Z600mm, Quill stroke 400mm. Table mm1470x350 mm CNC Heidenhain TNC 310 Iodpfjwcdwxjx Ahuotb

Condition: new, Bernardo geared drill GB 35 THS Technical specifications Drilling capacity in steel 35 mm Drilling capacity in cast 40 mm Thread cutting max. M24 Drill Chuck 1-13 mm / B-16 Dome MK 4 Spindle speed (12) 43-2355 U/min Feed range 0.1 / 0.2 / 0.3 / 0.4 mm / Rev Throat depth 340 mm Distance from spindle / table max 580 mm Distance from spindle / base plate 1185 mm Quill stroke 200 mm Column diameter 160 mm Table size / T - slot size 540 x 440 mm / 14 mm Work surface of bottom plate 430 x 440 mm Engine power 1,3 / 1,8 kW Itsdpjd Du Twsfx Ahueb Machine dimensions (W x D x H) 660 x 900 x 2240 mm Weight approx. 553 kg Scope of delivery • Drill Chuck 1-13 mm / B-16 • Drill Chuck Arbor MK 4 / B-16 • Reducing bushing MK 4 / 3, MK 4 / 2 / MK 3 / 1 • Motorized table hub • Electromagnetic spindle feed • Initial filling with Shell Tellus 46 • Automatic tool ejector • Thread cutting device • Digital speed display • LED machine luminaires • Coolant system • Digital drill depth indicator • Height-adjustable guard
