Clamping Table

SIEGMUND 28 / SONDERSET / 96 tlg.

Condition: used, SincoTec Model: POWER FLOW BIAXIAL 125/150 kN ±4000 Nm SincoTec POWER FLOW BIAXIAL 125/150 kN – ±4000 Nm Servo-hydraulic Test Stand Description: For sale is a servo-hydraulic biaxial test stand SincoTec POWER FLOW BIAXIAL. The unit has been used in an industrial environment and was fully functional up to decommissioning. All service and maintenance were professionally performed. Comprehensive technical documentation (operating, assembly, and wiring manuals) is available. The test stand is suitable for tensile/compression tests, torsion tests, and combined loading tests on components and assemblies, e.g. for fatigue, durability, and functional testing. Main technical data for the test stand: - Maximum test force (design): up to ±150 kN - Typical operating rating: 125 kN - Max. torque (torsion): ± 4,000 Nm - Max. linear cylinder stroke: ± 75 mm - Max. rotation angle: ± 50° - Measurement accuracy: Class 1 (DIN EN 10002-3) Test stand dimensions: - Total height: approx. 3,430 mm - Width: approx. 1,480 mm - Depth: approx. 1,180 mm - Max. weight of clamping fixture: 250 kg Hydraulic power unit (included) - Drive power: approx. 152 kW - Flow rate: approx. 260 l/min - Operating pressure: up to 280 bar - Hydraulic oil: HLP ISO VG 46 - Tank capacity: approx. 1,500 liters Power unit dimensions: - Length: approx. 2,714 mm - Width: approx. 1,820 mm Fjdpfox H Rtnjx Ad Njpg - Height: approx. 2,085 mm Electrical data: Control cabinet / test stand - 400 V / 50 Hz - Connection: CEE 5-pin - Fusing: 16 A Hydraulic power unit - 400 V / 50 Hz three-phase current - Direct connection - Fusing: approx. 160 A Scope of delivery: - SincoTec POWER FLOW BIAXIAL servo-hydraulic test stand - Hydraulic power unit - Control cabinet with industrial PC - Measurement and control technology - Technical documentation The machine is structurally rated for up to 150 kN. The 125 kN specification refers to the typical operational configuration. Test stand weight: approx. 4.7 t Important note: “The table shown in the photos is not included in the sale.” Condition: used Scope of delivery: (see photo) (Specifications subject to change and errors excepted!) Further questions can be answered by phone.

Condition: used, SincoTec Type: Exciting Mot Resonance test bench POWER SWINGLY 20 kN The resonance test bench POWER SWINGLY BigTable is designed as a two-mass oscillator. It consists of an oscillating head excited by a frequency-controlled asynchronous motor using an unbalance motor, which is arranged in the upper part of the machine and generates the dynamic amplitude. The oscillating head is supported by pre-tensioned helical compression springs on the upper crossbeam and is guided centrally. The medium-load drive is arranged in the lower part of the machine and applies the static preload with the help of a gear motor via a spindle drive. The sample space is located above the clamping table and is limited at the top by the adjustable crossbeam. The test bench is controlled by the EXCITING MOT control system. The complete control electronics for the control system are housed in an industrial PC cabinet. The control cabinet is made of powder-coated sheet steel and meets protection class IP 50 according to EN 60529. Technical data: General data test bench: Total height of test bench 1840 to 2240 mm Height of machine table 1030 mm Width of test bench 800 mm Depth of test bench 1500 mm Height of sample chamber max. 600 mm (without force transducer) Free column passage 550 mm Maximum force amplitude 10000 N Maximum total force ±20000 N Maximum vibration path ±5 mm Test frequency 30 to 110 Hz Accuracy of the measuring sensors min. Class 1 (according to DIN EN 10002-3) Weight of test bench approx. 1880 kg Max. weight of clamping device 150 kg General data Control cabinet: Total height of control cabinet 1900 mm Height of table top 1080 mm Width of control cabinet 650 mm Depth of control cabinet 700 mm Weight of control cabinet 152 kg Color RAI 9006 (white aluminum), table top midnight Conditions for the installation location: Space requirement 2.5 x 2.5 m Required ceiling height 2.8 m Floor load capacity 170 N/cm² Power supply 400 V / 50 Hz (clockwise rotating field) Connection plug CEE socket, 2-pole, 16 A Fpodpfx Aevx Su Sjd Neg Fuse 16 A Connection and ambient conditions Mains conditions: Voltage 400 V rotating current with ΜΡ conductor and protective earth, clockwise rotating field Voltage fluctuations < ± 10% Short-term dips < 20 ms Limits for continuous interference Radio interference level A according to VDE0871 Frequency 50 Ηz ± 1% Protective earth Earthing resistance < 0.3 Ω Model: POWER SWINGLY MOT Condition: used Scope of delivery: (See picture) (Changes and errors in the technical data, information is subject to change!) We will be happy to answer any further questions you may have over the phone.

Condition: used, Type: POWER SWING 20 kN Sincotec Resonance Testing System Power Swing 20 kN Manufacturer Service Performed General Information: For sale is a used resonance testing system Power Swing 20 kN from Sincotec Test Systems GmbH. The test bench was operated in single-shift use, with all maintenance carried out regularly by the manufacturer. Key Features: - Robust design for continuous operation - Precise resonance testing up to 20 kN - Manufacturer maintenance included - Ideal for research, testing, and development applications Technical Data – Test Bench Feature / Value - Overall height of test bench: 1215 mm (without clamping device) - Width of test bench: 2005 mm - Depth of test bench: 1205 mm - Maximum force amplitude: 10 kN - Maximum total force: ±20 kN - Measurement transducer accuracy: min. Class 1 (according to DIN EN 10002-3) Technical Data – Control Cabinet Feature / Value - Overall height of control cabinet: approx. 1800 mm - Table top height: 1080 mm - Width of control cabinet: 650 mm (narrow table top) / 1450 mm (wide table top) Fpsdpoxrffaefx Ad Nog - Depth of control cabinet: 700 mm (narrow table top) / 800 mm (wide table top) - Weight: 152 kg (small table top) 187 kg (large table top); with granite plate: 247 kg Site Requirements Feature / Value - Required space: 4.3 × 3.0 m - Required ceiling height: 2.5 m - Floor load capacity: 234 N/cm² Power Requirements Feature / Value - Voltage: 400 V three-phase AC with neutral and protective earth - Phase rotation: clockwise sequence - Voltage fluctuation: ≤ ±10 % - Short voltage dips: < 20 ms - Limits for continuous interference: interference class A according to VDE 0871 - Frequency: 50 Hz ± 1 % - Protective earth / ground resistance: < 0.3 Ω Connection and Fusing Feature / Value - Power supply: 400 V / 50 Hz (clockwise phase sequence) - Connector: CEE plug, 5-pin, 16 A - Fuse rating: 16 A Test bench weight: approx. 3.6 t Max. weight of clamping device: 250 kg Condition: used Scope of delivery: (see image) (Subject to changes and errors in technical specifications!) Further questions can be answered by phone.
