Eccentric press

Smeral Trnava LEN-40 C

Condition: used, Single-column – Eccentric press WEINGARTEN Type EV 63 Machine No. 738 / 61 Year of manufacture 1962 Pressing force 63 tons Stroke 260 mm Table area 630 x 530 mm Table opening Ø 210 mm Slide area 315 x 260 mm Adjustable slide stroke 8-100 mm Slide adjustment 63 mm Tool holder bore Ø 40 mm, with clamping piece Installation height max 450 mm Stroke rate 115 strokes / min Compressed air requirement min. 4.5 bar Motor power 4 kW Power connection 380 Volt, 50 Hz Iisdpok S Htxjfx Aphsh Table height above floor approx. 750 to 900 mm - Electrical stroke release via foot switch or two-hand control - Overload protection by shear plate - Clutch-brake combination by WEINGARTEN friction-thread clutch with top dead center through-drive protection - Front crankshaft support bearing - Press table adjustable in height via 2 threaded spindles - Manual centralized lubrication - Control cabinet positioned beside the press - UVV (German trade association for accident prevention) for manual feeding operations Space requirement L x W x H 1750 x 1600 x 2430 mm Weight 4.5 tons Good condition

Condition: excellent (used), pressure 50 t throat 245 mm stroke 14 / 90 mm ram adjustment 75 mm table height adjustment 150 mm strokes per minute 42/85 table surface area 700 x 490 mm ram surface 400 x 230 mm tool hole in ram 40 mm Iiedjtrhf Aepfx Aphsh hole in the table 240 x 140 mm daylight, max. stroke above - ram adjustment above 360 mm total power requirement 4 kW weight of the machine ca. 3,41 t dimensions of the machine ca. 0,8 x 1,75 x 2,1 m Machine was partially overhauled in our house as follows: - disassembly, cleaning and inspection - table milled over - new paintwork of the machine - shaft crack test carried out - disassemble Ortlinghaus clutch and additional brake, clean, check, replaceseals - additional air storage tanks - new control cabinet with safety control and touchscreen display - new wiring of the machine - new Vogel central lubrication system with piping - new Herion press safety valve + maintenance unit - new Balluff cam swith - new 2-hand control panel - new footswitch - Current UVV test with braking time measurement - Machine safe for hand inlay work

Condition: good (used), pressing force: 50 t, stroke length: 320 mm, Capacity 50 Ton Throat 225 mm Adjustable stroke 8 - 100 mm Number of strokes 320 p/min Ram size 300 x 280 mm Iodpfott A T Tox Aphjih Table size 500 x 800 mm Machine LxWxH: 160 x 120 x 260 cm Machine weight: 6 Ton

Year of construction: 1970, condition: used, pressure 63 t throat 440 mm Iiodpfx Apolp U Eqehsh stroke 8-100 mm no. of strokes 65 Hub/min ram - range of adjustment 63 mm table surface area 720x750 mm ram surface 440x280 mm hole in the table Ø 240 mm table height 830 mm tool hole in ram Ø 40 mm weight of the machine ca. ca. 5,0 t

Condition: used, Technical details: pressure: 63 t throat: 315 mm ram adjustment: 60 mm adjustment of stroke: 70 mm ram stroke: 10 - 105 mm no. of strokes: 71 - 140 Hub/min strokes per minute: Einzelhub: 45 / 50 Hub/min. passage between the side columns: 355 mm dayligth: 335 mm table:: BxT: 800 x 630 mm passage opening in table: 400 x 130 mm clamping plate: BxT: 616 x 85 mm clamping surface ram: BxT: 450 x 280 mm mortise hole in ram: Ø 50 x 83mm mm Iiedpfx Aevt Nvpjphjh total power requirement: 7,5 kW weight of the machine ca.: 5,9 t dimensions electric cabinet LxWxH: 0,86 x 0,30 x 1.3 m dimension machine xH: Presse: 1,42 x 1,8 x 2,6 m Press with roll feed/strip system and straightener High-performance press with roll feed/strip system and straightening machine Application: suitable for series production Equipped with servo roll feed MINI: refurbished until 01/2021 -manufacturer P/A GmbH, type SRF 220 -for strip width 220mm -feed rate 150m/min. -operation with hand tool straightening system: -manufacturer Wanzke, type KS 150 -insertion width max. 200mm -2 pieces driven inserting rolls -4 pieces driven straightening rolls (top), adjustable vertical approx. 30mm -5 pieces driven straightening rolls (bottom), fixed, not adjustable Coil = special design: -mechanical/manual -external take-up max. Ø 1.500mm -internal take-up max. Ø 300mm -width max. 200mm Roller deposit: -roller system with 9 pieces of roller bars with 53 rollers (Ø 25x25mm). *

Condition: good (used), Year of construction: 1990, functionality: fully functional, power: 7.5 kW (10.20 HP), pressing force: 63 t, table width: 800 mm, table length: 630 mm, total length: 17,900 mm, total width: 14,250 mm, total height: 25,500 mm, overall weight: 5,850 kg, height adjustment type: mechanical, stroke adjustment: 105 mm, Eccentric press LEN 63C. Year prod. 1989(SMERAL TRNAVA Czech Republic). Technical data: - pressing force: 63 tons - number of strokes in automatic: 65/130 min - number of jumps manual operation: 45/50 min - slider stroke adjustment: 10-105 mm - slide stroke: 70 mm - table surface: 800 x 630 mm - slider surface: 450 x 280 mm - overhang: 315 mm - table - slider clearance: 335 mm - clearance between columns: 355 mm - number of gears: 2 - motor speed: 730/1440 min - motor power: 4/7,5 kW Ijdpfxjtzxdzo Aphoih - press dimensions: 1425 x 1790 x 2550 mm - weight: 5850 kg The technical condition of the machine is good. It is possible to make a visual inspection and check the machine in operation.
