Double-Column Presse

SMG DS 800 S

Year of construction: 1979, condition: used, pressure 160 t distance between columns 850 mm stroke 400 mm Dedslp Uz Rspfx Ah Secb ram surface 800x700 mm 300 mm pressure of ejector 20 t table surface area 800x700 mm total power requirement kW weight of the machine ca. 12 t dimensions of the machine ca. 1800x1800x4200 m

Condition: good (used), Year of construction: 1998, HIGH Speed version faster in approach/work/return Hydraulic table ekjector Hydraulic feed table Home position rotation left   0 - 90 Gr Home position rotation right 0 - 90 Gr  Extended die height 2400 mm BIG Table 1600 x 1300 mm Siemens SIMATIC opperation panel Distance between column:1360mm Hight under roof: 1700mm Table Length: 1600mm Ram stroke: 1500mm Approche speed: 200mm/min. Working speed: 50mm/min. Return speed: 180mm/min. Dcedpfsu U Nb Aox Ah Ssb Rotation upper table: 0 - 180° Table adjustment: 1700mm Length: 4900mm Width: 2800mm Height: 5600mm Weight: 18800kg HIGH Speed version faster in approach/work/return Hydraulic table ekjector Hydraulic feed table Home position rotation left   0 - 90 Gr Home position rotation right 0 - 90 Gr  Extended die height 2400 mm BIG Table 1600 x 1300 mm Siemens SIMATIC opperation panel

Year of construction: 1978, condition: used, pressure 25 t Djdslp U A Iopfx Ah Sjcb stroke 100 mm table surface area 440x320 mm ram surface 360x220 mm hole in the table 160x100 mm table height 900 mm tool hole in ram Ø 40 mm dayligth 280 mm weight of the machine ca. 1,5 t dimensions of the machine ca. BxTxH 1500x1500x2100 mm

Condition: used, Year of construction: 1984, Pressure total: 600 ton Dsdpeuqdizefx Ah Socb Ram stroke: 762 mm Slide adjustment: 406 mm Shut height (stroke down, adjustment up): 1322 mm Free frontal opening L-R: 3700 mm Table surface area : 3350 x 2134 mm Slide area: 3350 x 2134 mm Die cushion capacity in table: 180 ton Die cushion stroke: 305 mm Ejector in ram: 60 ton Ejector stroke in ram: 230 mm Number of strokes: 16 s.p.m. Required power: 90 kW Weight of machine approx.: 185 ton Standard configuration Cushion in table pneumatic Extended machine accessories die loading charts for tool changeABB Handling robots for loading and unloading presses

Condition: used, Year of construction: 1996, pressure 63 t distance between columns 965 mm stroke 4 - 60 mm no. of strokes 30 - 800 Hub/min dayligth (stroke and adjustment up) 380 mm column travel -side 355 mm table surface area 960 x 640 mm hole in the table 850 x 140 mm table height over floor 1150 mm ram surface 960 x 460 mm power requirement 32,5 kW weight of the machine ca. 13,00 t required space 3,3 x 1,7 x 2,9 m ram adjustment 80 mm Djdpfx Ahevut Rgs Socb permitted for automatic mode according to the CE Regulations with infinitely variable drive, pneumatic clutch, semi-automatic stroke adjustment, motoric ram adjustment, mechanical pincer feed type GF 160 can be offered without or with putting into operation in given condition

Year of construction: 1990, condition: as good as new (ex-display), Eckolt hydraulic press in mind condition Dcedpfx Asd Siacoh Seb executed with plate holder see pdf for technical specs

Condition: new, pressure 80 t stroke 400 mm table surface area 920 x 540 mm Motor output 2,2 kW liter capacity 9,0 l dayligth 800 mm tank capacity 31 l daylight between the columns 920 x 300 mm weight of the machine ca. 0,725 t dimensions of the machine ca. 1,45 x 0,85 x 2,45 m Hand and Motor operated. Dcsdsvu E T Hspfx Ah Sob Side-sliding cylinder.
