Flanging MachineSMT
MV20 BL5022
Machine data
- Machine type:
- Flanging Machine
- Manufacturer:
- SMT
- Model:
- MV20 BL5022
- Year of construction:
- 1983
- Condition:
- used
Price & Location
- Seller location:
- Reckholder 1, 9527 Niederhelfenschwil, Switzerland
Technical details
- Overall weight:
- 70,000 kg
- Power:
- 55 kW (74.78 HP)
Details about the offer
- Listing ID:
- A202-24770
- Reference number:
- 42997
- Update:
- 06.10.2025
Description
.. total power consumption: 55 kW
DIMENSIONS / WEIGHTS
.. total weight approx.: 70000 kg
Maximum wall thicknesses:
Material up to approx. 450 N/mm² max. 22mm (steel)
Material up to approx. 750 N/mm² max. 17.5mm (stainless steel)
Maximum diameter :
dished end approx. 5000 mm
Basket arch bottom approx. 3200 mm
Minimum diameter :
dished end approx. 1200 mm
Corner radius :
Range 150 - 500 mm
Largest corner radius 500 mm
Clear width clamping bracket approx. 5800 mm
Max. Sheet thickness clamping approx. 32 mm
Chedsxlh Ecjpfx Abwoc
Electrical power :
Main drive approx. 55KW
Shifting drive approx. 1,5/9 KW
Hydraulic unit approx. 11 KW
additional pressure roller drive approx. 7,5 KW
Accessories :
Push rollers additional drive
2 lateral pressure rollers
Form roller change console
Central lubrication
Clamping device oL 5033
Included :
Tools for flanging :
1 piece standard flanging roller
4 pieces cast iron flanging rollers
R85, R125, R150, R175
7 flanging rollers made of 1.2379
R225, R250, R300, R350, R400, R450, R500
New spare parts :
New clamping plate bearing
New threaded spindle with nut
New form roller shaft
