Turning Automatic Lathe - Longitudinal

STAR MICRONICS ST 38

Condition: good (used), Year of construction: 2014, functionality: fully functional, Table surface: 850 x 400 mm Magnetic table: 800 x 400 x 105 mm Max. table travel (X x Y): 950 x 440 mm Max. workpiece weight: 700 kg (230 kg on the magnetic table) T-slots on the table: 3 pcs x 17 mm Distance between table and spindle center: 47,5 – 547,5 mm Grinding wheel dimensions: D355 x 38 x d127 mm Spindle speed: 1500 / 1800 rpm (50Hz / 60Hz) Spindle drive power: 3.7 kW / 4.0 kW Longitudinal travel: 3 – 25 m/min (hydraulic and stepless) Cross travel: 1 – 1000 mm/min Vertical feed rate: 1 – 1000 mm/min Minimum increment / feed amount: 0,0001 mm – 0,0002 mm Machine weight: 4000 kg Dimensions (L x W x H): 3310 x 2228 x 2710 mm Accessories / Equipment - Semi-automatic operation - Magnetic table 800 x 400 mm Gbjdpoy T Nuwofx Ahtsr - Coolant system with magnetic separator - Paper band filter - Machine feet - Digital display system for the infeed / increment - Built-in wheel dresser in the spindle head The machine is being sold due to company liquidation. It is in good condition and still under power in Hungary.

Condition: ready for operation (used), Year of construction: 1995, functionality: fully functional, machine/vehicle number: 4304, rotary table diameter: 600 mm, grinding height: 450 mm, overall weight: 14,500 kg, Machine is equipped with 3 spindles, surface grinding, external grinding, bore grinding Turret head B-axis with 1° division Belt filter system included Gsdpfxevt A Rts Ahtobr

Condition: used, TECHNICAL DETAILS - Number of axes : 5 - Distance between tips : 400 [mm] - Effective diameter : 180 [mm] LINEAR AXES - X1 and X2 x Z travel : 220 [mm] - Z travel : 850 [mm] - X x Z resolution : 0.0001 [mm] TURRET : - Number of fixed positions : 12 - Tool holders : VDI30 WHEEL CARRIER - Right-hand external grinding : * Grinding wheel dimensions (Ø x width x bore) : 400 x 50 x 127 [mm] * Drive power : 6.8 [kW] WORKPIECE CARRIER - Max. speed : 7500 [rpm] - Speeds (synchronous operation) : 1 - 5000 [rpm] - Taper type : CM4 - Drive power : 10.5 [kW] - C axis : 0.001 [°] SYNCHRONIZED COUNTER SPINDLE - Max. speed : 7500 [rpm] - Rotational speeds (synchronous operation) : 1 - 5000 [rpm] - C axis : 0.001 [°] - Inner cone : MK4 - Micrometric adjustment : +/- 40 [microns] - Drive power : 10.5 [kW] POWER SUPPLY - Power rating : 45 [KVA] DIMENSIONS - Floor dimensions : 2800 x 3960 [mm] - Machine weight : 7600 [kg] MACHINE HOURS - Powered hours : 57000 [h] EQUIPMENT - NC FANUC 310i-modelA Godjvxw A Uopfx Ahtjbr - Software Studer WIN - RS232 / USB interface - Remote electronic handwheel - Turret with Renishaw LP2 length self-calibration device - Marposs feelers for diameters (multirange) + Z4 axes for positioning - Semi-automatic wheel balancing MPM.3 BMT100 M.24 - 480 L coolant tank * with paper filter * with magnetic filter - Chip conveyor - Fog extraction - Cooling unit for grinding wheel motor cooling - Electronic contact detection Dittel AE6000 - Fixed dressing device on workhead - Electrical cabinet air conditioning - Balancing shaft - Interface for automatic loading system

Condition: used, TECHNICAL DETAILS - Spindle speeds : 5 - 300 [rpm] - C axis indexing precision : 0.001 [°] - Vertical travel of the main spindle : 130 [mm] - Vertical travel of the main spindle (manual mode) : 140 [mm] - Rotational speed of the grinding spindle with motor : 4500 - 80.000 [rpm] - Rotational speed of the grinding spindle with turbine : 100.000 - 160.000 [rpm] - Cylindrical grinding without/with intermediate plate max. : 230 / 360 [mm] - Maximum grinding length Z (with block) : 125 [mm] - Maximum acute angle in conical grinding : 16 [°] - Maximum grinding depth in conical grinding with angle : 44 [mm] LINEAR AXES - Travels on X/Y/Z axes : 700 / 500 / 500 [mm] - Rapid traverses rates (X/Y) : 4000 [mm/min] - Cutting feed rates (X/Y) : 0 - 2000 [mm/min] TABLE - Table dimensions : 770 x 630 [mm] Gbjdpfx Ahex Av Adster - Maximum weight upon table : 500 [kg] - Distance table / spindle nose (min./max.) : 0 - 600 [mm] POWER SUPPLY - Supply voltage : 400 [V] WEIGHT & DIMENSIONS - Machine floor space : 2650 x 2577 [mm] - Machine height : 2677 [mm] - Machine weight : 5600 [kg] MACHINE HOURS - Number of working hours : 44995 [h] EQUIPMENT - CNC : Fanuc - Coolant tank * with high-pressure pump * with paper filtering unit - Oil mist extractor - Fire extinguisher * * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer.

Condition: used, TECHNICAL DETAILS - Number of axes : 10 - Number of spindles : 2 MAIN SPINDLE - Spindle power : 24 [kW] - Spindle speeds : 5000 [rpm] - Max. bar diameter : 65 [mm] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Spindle power : 24 [kW] - Spindle speeds : 5000 [rpm] - Max. bar diameter : 65 [mm] - C axis indexing precision : 0.001 [°] - Travel : 390 / 600 [mm] TURNING-MILLING SPINDLE - X stroke : 350 [mm] - Y stroke : ± 80 [mm] - B Axis stroke : 270 [°] - B axis indexing precision : 0.001 [°] - Tool type : HSK-T40 - Spindle speeds : 18000 [rpm] - Spindle power : 11 [kW] - Fixed tools on milling electrospindle : 6 x VDI25 LOWER TURNING-MILLING SPINDLE - Y stroke : ± 80 [mm] - B Axis stroke : 270 [°] - B axis indexing precision : 0.001 [°] - Tool type : HSK-T40 - Spindle speeds : 18000 [rpm] - Spindle power : 11 [kW] - Fixed tools on milling electrospindle : 6 x VDI25 TOOL CHANGER - Auto. Tool Changer type : Bras chargeur - Tool magazine capacity : 80 - Tool exchange time : 4.5 [sec] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 68 [kW] WEIGHT & DIMENSIONS - Machine height : 2500 [mm] - Machine weight : 11000 [kg] MACHINE HOURS - Spindle hours : 19781 [h] - Number of turning-milling spindle hours : 9713 [h] Gbsdpfx Aev Ig Avohtsr EQUIPMENT - CNC : Siemens Sinumerik 840D SL - Coolant tank * with high-pressure pump * with paper filtering unit * Coolant through spindle - Chips conveyor - Spindle cooling unit - Parts catcher

Condition: ready for operation (used), Year of construction: 1989, total width: 4,000 mm, overall weight: 5,000 kg, workpiece diameter (max.): 140 mm, product length (max.): 2,000 mm, number of axes: 2, This Schaudt Mikrosa SASL 125 was manufactured in 1989. A centerless external grinding machine, it features NC-controlled operations and hydrodynamic axis bearing. Both wheels can be dressed via a controlled axis. Refurbished by UHLMAN Werkzeugmaschinen-Service in 2021/22, it has been regularly maintained. Consider the opportunity to buy this Schaudt Mikrosa SASL 125 centerless grinding machine. Contact us for more information. Working range: • Maximum workpiece diameter • that can be ground • with a grinding wheel Ø 500 mm: 140 mm • Maximum workpiece diameter • that can be ground • with a grinding wheel Ø 630 mm: 80 mm • Minimum workpiece diameter that can be ground: 3.5 mm • Maximum workpiece length for through-feed grinding: 200 mm Godpox Enapsfx Ahtjbr • Maximum workpiece length in plunge grinding 245 mm • Maximum grindable profile depth on the workpiece 25 mm Grinding wheel: • Maximum outer diameter 500 or 630 mm • Minimum outer diameter 380 mm • Maximum grinding wheel width 250 mm • Grinding wheel bore 305 mm • Guide wheel: • Maximum guide wheel outer diameter 315 mm • Maximum guide wheel width 250 mm • Bore diameter 127 mm Power requirements: • Power consumption approx. 33 kW Additional equipment • Optional: Additional equipment available Machine Benefits Technical Machine Benefits • Hydrodynamic axis bearing • Regular maintenance during series production • Retroffited by Uhlman Werkzeugmaschinen-Service in 2021/22

Condition: used, O F F E R We can offer you ex stock, subject to prior sale and errors: TSCHUDIN (CH) Centerless cylindrical grinding machine Model TC-300 Year of manufacture 2001 Grinding range – Ø 0.5 – 25 mm (30) Max. workpiece length for plunge grinding 125 mm (140) Max. workpiece length for through-feed grinding 300 mm Grinding wheel dimensions: Ø x width Ø 300 x 125 mm (140) Regulating wheel dimensions: Ø x width Ø 225 x 125 mm (140) Grinding wheel peripheral speed 35 m/sec Grinding wheel infeed 3 mm Regulating wheel speeds, steplessly adjustable 0 – 444 rpm Regulating wheel inclination Degrees Grinding wheel drive approx. 7.5 kW Total connected load approx. 13 kW – 380 V – 50 Hz Weight 2,500 kg Accessories / Special equipment: • The machine operates with a fixed workpiece position, allowing both the grinding spindle and the regulating spindle units to be adjustable. This simplifies machine setup as well as automatic workpiece loading and unloading. • SIEMENS PLC control for automatic operation with SIEMENS touchscreen. Complete electrics and PLC control renewed in 2016! • Electromechanical profile dressing device for the regulating wheel • Regulating and grinding wheel speeds are steplessly adjustable. • Adjustable plunge guide bridge with mounted plunge workpiece rest Gsdpfxewftt Uj Ahtjbr • Electromechanically controlled workpiece pusher & automatic pneumatic workpiece ejector • Additional outfeed cylinder for automatic tilting of workpieces after plunge grinding (adjustable 4–30 mm) • Machine is prepared for use with a HELP-TEC bar loader MSHL08/400P, which is currently not present. • Complete enclosure of working area with monitoring technology • Separate control cabinet, operating and electrical manuals for the retrofit Condition: Very good! Fitted with new electronics in 2016! Click here for a video of the machine: Delivery: ex stock, immediately available, FCA Metzingen Payment: strictly net – after receipt of invoice Always a large selection of grinding machines in stock – please inquire for your requirements!

Condition: ready for operation (used), Year of construction: 1997, operating hours: 20,045 h, functionality: fully functional, travel distance X-axis: 500 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 450 mm, spindle speed (max.): 60,000 rpm, spindle speed (min.): 9,000 rpm, table load: 300 kg, overall weight: 4,500 kg, travel distance W-axis: 450 mm, Equipment: documentation/manual, For sale: used Hauser S35-400 coordinate grinding machine, year of manufacture 1997, in well-maintained condition with various accessories as shown in the photos. Travel paths: X-axis: 500 mm Y-axis: 300 mm W-axis: 450 mm Z-axis feed rate, stepless: 0.5–14,000 mm/min Table size: 600 x 380 mm Maximum table load: 300 kg Control: GE Fanuc Series 16-M Dimensions (L/W/H): 4.25 m x 4 m x 3.25 m Gbjdpfx Aheyywb Sjtor Total weight: 4,500 kg Machine is immediately available! Price includes loading onto truck!

Condition: good (used), Year of construction: 2006, turning length: 1,000 mm, spindle speed (max.): 5,000 rpm, rotational speed (min.): 12,000 rpm, We offer you: Manufacturer: MORI SEIKI Model: NT 4200/1000S Year of manufacture: 2006 Control: MITSUBISHI M-720BM (MAPPS 2) Technical Data: Turning length: 1,000 mm Bar capacity: max. 65 mm Main spindle: Max. speed: 5,000 rpm Drive power: 22/15 kW Spindle bore: Ø 73 mm Counter spindle: Max. speed: 5,000 rpm Drive power: 22/15 kW Spindle bore: Ø 73 mm Milling spindle: Speed range: 0 – 12,000 rpm Tool interface: Capto C6 Number of tool positions: 100 Hollow chuck: Ø 67 mm Operating hours: approx. 27,000 h Spindle hours: approx. 16,100 h Technical features and equipment: Gbodpoxxraqefx Ahter - Y-axis - Fully indexable B-axis - Chip conveyor, discharge to the right - Standard coolant system - Interface for high-pressure coolant system, 70 bar - Tool spindle with through-coolant - Coolant spray gun - Air blast through counter spindle - Manual tool presetting on the main spindle - 3-color signal light - Double foot switch - Simultaneous 5-axis machining - Automatic power shut-off - Tool offset for 5-axis machining - Programmable data input - Dynamic diameter/radius exchange - Stroke check before movement Operating hours: 26,875 h (as of 22.08.25) Spindle hours: 16,093 h (as of 22.08.25) Accessories, illustrated tools, and clamping devices are only included if explicitly specified in the additional information. Subject to change and error in technical details and specifications. Prior sale reserved!

Condition: excellent (used), Year of construction: 2017, For sale is a Jenoptik test table of the type T8000 Wavemove for housings The device was used for housing surface testing as the type describes and is in good to very good condition Gsdpfomfty Hsx Ahtobr Year of manufacture: 2017 Weight: 2,500 kg The offer includes the components shown as well as computers and software Loading & or shipping possible for an additional charge Prices plus VAT Viewing possible by appointment. Contact us, our team will be happy to help you. Trade-in or exchange possible! Machine purchase / sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MUCH MORE. Do you need a high-quality but inexpensive metalworking machine for your production? Or do you want to sell yours? For more information or contact options, visit us on our website
