Trimming saw

Stoll GmbH - JRIMAC Sägetechnologie JRIMAC Längskreissäge TOP

JRIMAC Longitudinal Saw "TOP" - NEW -

* Cutting length 2200 - 9200 mm
* Cutting width 420 - 2120 mm
* Cutting direction left - right (right - left available on request)
* Cutting height max. 210 mm with high-quality saw blade Ø 620 mm.
* Precise and clean cut due to the robust, self-supporting welded construction of the machine frame.
* Carriage guidance via linear guides, with ball-bearing, maintenance-free rollers.
* Safety bar mounted above the machine table with a 6 mm thick blade guard.
* Dust extraction connection Ø 160mm, ready for connection, located at table height on the upper right and lower left.
* Flexible and efficient working thanks to the 250 mm opening of the blade guard above the table edge.
* Infinitely variable, frequency-controlled, and powerful feed of the carriage.
* The max. feed speed can be adjusted.
* Automatic, infinitely variable saw blade height adjustment.
* Infinitely variable width stop adjustment via multiple operating levers.
* Electronic positioning control.
* "JRIMAC" quick-clamp system for the saw blade allows for a quick saw blade change.
* Cutting activation standard (small, mobile foot pedal).
* Front table supports made of wood, plastic or Pertinax.
* High level of operational safety.
* Use and installation of exclusively high-quality components.
* The electrical control cabinet is easily accessible and mounted on the front of the machine.
* The machine's electrical system is designed for 230/400 volts, 50 Hz.
Ppedpfx Ansgk Nvnepeu
* BG-tested for dust emissions
* EC - type tested according to directive 2006/42/EC
* Forced-guided splitter
* Processing of more than 12 different materials possible
* Reliable spare parts and customer service
