STORTI Package Cutter

Storti

Condition: excellent (used), CATALOG NUMBER 7213 TECHNICAL DATA - Max cutting height: 180 mm - Track width: 400 mm - Shaft width: 370 mm - Shaft diameter: 60 mm - Max blade diameter: 300 mm - Blade bore diameter: 80 mm - Min element length: 630 mm - Max element width: 600 mm From above: - Pneumatic hold-down - Pawls - 2 metal hold-down rollers - Pawls - Saw shaft - Smooth hold-down roller - Pawls - Smooth hold-down roller From below: - 2 metal feed rollers, toothed - Pawls - Track - Saw shaft - Track - Infinitely variable feed speed adjustment via inverter - Main motors: 2 x 55 kW - Feed motor: 4 kW - Hydraulic lifting of the upper body - Hydraulic saw shaft adjustment - Pump motor: 0.37 kW - Central lubrication - Extraction port diameter: 1 x 300 mm, 1 x 380 mm - Dimensions (L x W x H): 3200 x 2350 x 2000 mm - Weight: approx. 5500 kg Hjdpfx Afsx R Dxxjcei ADVANTAGES – Italian made – Twin-shaft – Used multi-blade saw, in very good condition Net price: 238,900 PLN Net price: 56,880 EUR Net price calculated at exchange rate 4.2 PLN/EUR (in case of significant exchange rate fluctuations, the price may change)

Year of construction: 2003, condition: reconditioned (used), longitudinal saw for cutting boards 4 meters main engine 400V, 7.5kW - blade feed motor 400V, 2.2 kW - extending the pneumatic saw - working pressure 6bar - cutting length 4020 mm - cutting height approx. 170mm - machine length 5.5 m Hedpfshbp T Ssx Afcsi - machine width 1.6 m

Condition: excellent (used), Storti RM 500 edger - Italian production - year of production 1993 - electric spacing of discs TECHNICAL PARAMETERS: - cutting width max 435 mm - cutting height max 170 mm - engine power 2 x 22kW - max element width 600 mm - minimum material length 800 mm - max disc diameter 600 mm - spindle diameter 40 mm - two upper pulling rollers - one upper pressure roller - roller motor power 2 x 1.1 kW - roller pressure with automatic jump - seven bottom pulling toothed rollers - electric disc adjustment - two lasers - feed speed 25 and 50 m/min - feeding table 2950 mm - receiving table 3000 mm - drive rollers D100 mm Hodpfx Afek Talpjcji - power of the roller feed motor 2 x 1.5 kW Transport dimensions 500x240x180 cm weight 3500 kg

Condition: like new (used), Storti wood cutting line - Italian production - edger with a central disc with a pneumatic jump RM 400 S - crosscut saw TP2 - multisaw Multibi R16 - minimum material length 700 mm - maximum element width 500 mm - maximum element height 140 mm - line feed speed 30 m/min - total power 110 kW - space requirement 26 x 5.5 m TECHNICAL PARAMETERS: 1 Strorti RM400 S edger - cutting width max 330 mm - cutting height max 140 mm - element width max 500 mm - maximum element length 5000 mm - engine power 3 x 11 kW - seven steel toothed bottom pulling rollers - two upper toothed pulling rollers - pneumatic material pressure - the jump of the central disc is pneumatic - feed table 5000 mm roll width 500 mm diameter 80 mm - receiving table with edging 5200 mm roll width 500 mm roll diameter 140 mm 2 Storti TP2 crosscut saw - width of the finished element max 1600 mm - width of the finished element min 700 mm - cutting height min / max - 20/140 mm - disc diameter 600 mm - spindle diameter 30 mm - engine power 2 x 7.5 kW - feed roller table 2570 mm width of rollers 500 mm diameter 100 mm - diameter of connections 2 x 160 mm 3 Multisaw Storti Multibi R 16 - material width max 150 mm - material height max 140 mm - engine power 2 x 22 kW - disc diameter max 300 mm - spindle diameter 50 mm - spindle height 160 mm - hydraulically adjustable feed - hydraulic side material pressure - two upper pneumatic clamps - connector diameters 2 x 220 1 x 160 mm - receiving conveyor 2000 mm - cross conveyor table 3200 x 1100 mm Hsdpfx Aomv Ehzefcji

Condition: excellent (used), Year of construction: 2005, For sale: machine for optimizing pallet blocks from beam timber, saw blade diameter 500 mm, power 10 kW, weight 840 kg, machine in very good condition, not worn, year of manufacture 2005. Hsdpeygc Txofx Afcoi

Condition: repair required (used), Year of construction: 1999, functionality: not functional, Prismatrice Storti 4x35hp roller input Exit command house Hedpfslxqk Rsx Afcoi machinery to restore

Condition: used, Year of construction: 2004, functionality: fully functional, machine/vehicle number: 131/04, total width: 2,400 mm, total height: 3,100 mm, total length: 3,200 mm, type of input current: three-phase, overall weight: 3,000 kg, working width: 1,500 mm, working height: 180 mm, power: 50 kW (67.98 HP), Storti wood working machine GSI/150-AL (2004). Semi-automated line which requires two operatives to feed the double length table. Machine allows for UK Standard (1200 x 1000mm), Euro pallet (1200 x 800mm) and 2way entry pallets production. Hodpfxsydm H Dj Afcsi

Condition: excellent (used), Year of construction: 2015, Machine is ready for sale. It's used only 1,5 years. I can send a short video about the machine if required.All techcnical documents are also saved. Hodjlu Hbpspfx Afcsi

Condition: excellent (used), STORTI Pallet Production Line Hedpsuz Ibdsfx Afcoi - Fully automatic - corner milling - stacker - sign burning

Condition: used, Year of construction: 1999, functionality: fully functional, cutting length (max.): 1,800 mm, Equipment: CE marking, documentation/manual, PACKED WOOD SECTIONING MACHINE STORTI MOD. TGS P12 - Minimum pack length 1000 mm - Maximum pack length 5000 mm - Minimum pack width 300 mm - Maximum pack width 1200 mm - Minimum pack height 500 mm - Maximum pack height 1200 mm - Conveyor belt width 1250 mm - Feed speed 9.5 m/min - Drive motor 0.35 kW - Cutting bar length 1800 mm - Cutting bar feed speed 66 mm/min - Chain motor 14.5 kW - Number of programs 9 - CE rules Hodpfx Afex Srtmecsi - Year 1999
