Pendulum saw

Stromab TR 600

Condition: used, Year of construction: 2004, functionality: fully functional, AUTOMATIC CROSS CUTTING MACHINE STROMAB MOD. TR 600 Godpfx Acex Rrp So Aett - 2 meters infeed rollers - 2 meters outfeed rollers - N. 3 stops - CE rules - Year 2004

Condition: good (used), Code: 0271 Brand: STROMAB Model: TR 600 MATRIX 2 PLUS - CE Standard Automatic cut-off saw with electronic pusher MATRIX 2 PLUS ( mm 8000) for the production of pallets, packaging, door and window frames, furniture and garden furniture, carpentry and various - CE Standard Technical data: Blade diameter mm 600 Motor Hp 12,5 Blade speed min 3000 Working table height mm 850 Hydraulic blade unit drive Blade lifting speed regulator Cutting area protection cover Bimanual hand guard control Cutting capacity Width 610 mm - Height 30 mm Width 580 mm - Height 60 mm Width 530 mm - Height 100 mm Width 490 mm - Height 120 mm Width 450 mm - Height 140 mm Width 380 mm - Height 160 mm Outfeed flat table Suction ports n° 3 diameter mm 100 Numerically controlled pusher MATRIX 2 PLUS Technical data: Maximum working length mm 8000 Feeding system featuring precision rack and brushless motor Positioning reading on magnetic stripe Positioning precision +/-0,4 mm Pneumatic rising of the pusher with workpiece measurement sensor Main system: Cutting cycle (pattern) editing by keypad, by remote PC via serial port (RS232) or by Ethernet Working software: A) N° 99 programmable cutting cycles with 15 sizes (lines) per cycle - Example of cutting cycle: Board length, trim cut , 1 size (line).....15° size Gjdpfx Ajx Ikvloc Astt B) N° 1 cutting cycle with 100 programmable sizes to be cutted in sequence Exit surface 4000 x 600 mm Compressed air 7 bar Overall dimensions of assembled machine: mm 13000 x 2000 x 1600 h Overall dimensions for transport : Machine mm 1200 x 1700 x 1600 h - Matrix pusher mm 8800 x 1500 x 1500 h Weight kg 1600

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 0x0x0 mm Weight 1500 kg Total power requirement 10,2 kw Gsdpjv A Htkefx Ac Astt

Condition: used, Year of construction: 1997, functionality: fully functional, cutting width (max.): 610 mm, saw blade diameter: 600 mm, type of input current: three-phase, - Year of manufacture: 1997 - Two pneumatic stops TECHNICAL SPECIFICATIONS: - Saw blade diameter: 600 mm Gjdpfjx Ekmrjx Ac Aett - Max cutting width: 610 mm (with element height 30 mm) - Max cutting height: 160 mm (with element width 380 mm) - Motor power: 7.5 kW - Sawdust extraction outlet: 2 x 100 mm - Two pneumatic stops for cutting to set length - Hydraulic element clamping and blade movement - Stepless cutting speed adjustment - Infeed table: 1000 mm / 470 mm D-90 mm - Outfeed table: 1500 mm / 500 mm D-60 mm - Spindle diameter: 30 mm - Blade rotational speed: 2800 rpm Transport dimensions - 280x165x140 cm - Weight: 600 kg

Condition: excellent (used), Year of construction: 2001, functionality: fully functional, saw blade diameter: 600 mm, STROMAB TR600 Crosscut Saw Specification: • Condition – used, after inspection • Manufacturer – STROMAB • Model – TR600 • Total power – 9.2 kW • Blade diameter – 600 mm • Motor spindle diameter – 30 mm • Motor speed – 3,000 rpm • Hydraulic clamping and blade movement • Adjustable cutting speed • Max. cutting width – 610 mm (at 30 mm height) • Max. cutting height – 160 mm (up to 380 mm width) • Additional table – 1 x 2.0 m Gedpfox Ezmcex Ac Aott • Base weight 570 kg • Year of manufacture: 2001 • Extraction port – 3 x 100 mm • Machine complies with CE standards, equipped with guards, E-stop buttons, and Italian documentation • Overall dimensions (base) – 130 x 145 x 135 cm (L x W x H) Additional information: • Very good original technical and visual condition • The photos shown reflect the actual condition of the item for sale • Possibility to run and test the machine on site

Condition: ready for operation (used), Technical characteristics Power and Motors Gtjdpfx Acor A Ulke Aet Voltage: 400 V Pluging: Three-phased Overall dimensions

Condition: ready for operation (used), Technical characteristics Hydraulic blade feed Blade Ø 600 mm 12 kW motor, 3000 RPM Two-hand control Usable capacities : Width 610 x Height 30 mm Gjdpfst E Efgsx Ac Astt à Width 420 x Height 160 mm Presser protection grid MATRIX 2 Usable length 6000 mm Length optimization, automatic cycles 99 programmable cutting cycles 15 programmable measurements/cycle 3 suction nozzles Ø 100 mm Power and Motors Voltage: 400 V Pluging: Three-phased Motor: 16 CV Overall dimensions
