Depaneling machine for PCBs LOW Mini

Systemtechnik Hölzer GmbH LOW Mini - Nutzentrenner

The compact tabletop version LOW MINI has been specifically developed for depaneling small-format production panels, small series of larger format, and cost-conscious manufacturing. PCB materials with breakout tabs can be separated quickly and economically up to a maximum size of 320 mm x 560 mm. The separation process is servo-controlled on all axes, with the milling drive operating from above. The machine’s highlight is its easy and straightforward switch between small (320 x 280 mm) and large (320 x 560 mm) working areas.
Dusdpoxmfdxsfx Ad Nst

• Short cycle times due to shuttle operation
• X/Y axes with linear motor technology
• Panel fixation using pin technique
• Flexible handling
• Suitable for PCBs with breakout tabs
• Milling spindle adjustment with servo-drive technology
• Extraction device
• User-friendly operation
• Excellent price-performance ratio

Manual Depaneling – flexible and cost-effective
The concept of manual depaneling offers significant advantages when it comes to flexibility and cost-effectiveness. Medium production volumes can be separated quickly and with minimal dust using the LOW MINI. Standard equipment includes dual loading with linear motor technology, while single-shuttle operation is available to expand the working area. Ease of maintenance and user-friendly operation, combined with its outstanding price-performance ratio, ensure convenient operation and make investing in this depaneling machine a worthwhile choice.

Axis speed: 160 mm/s
Repeatability: 0.02 mm
Separation accuracy: 0.1 mm
Shank tool diameter: 0.8 – 2.4 mm
