Stamping & punching press thin metalsheet

Tecnoma punching & bending installation hooks

Condition: like new (used), Year of construction: 2023, Mandrel Bending Machine S4501 ---- For the production of pipe geometries with bending radii from 1.5xD → Maximum bending capacity: pipe 42.4 x 3.25 mm (steel max. Re 240 N/mm²) → Maximum bending capacity: pipe 30 x 30 x 3 mm → Maximum bending capacity: pipe 42.4 x 2 mm (stainless steel max. Rp0.2 260 N/mm²) → Total connected load 3 kW → Pipe insertion length approx. 1.5 m Robust and durable steel construction. Maintenance-free servo drive for the bending, feed, and twisting axes. The control system's touchscreen display enables simple and intuitive programming and operation of the system. After the pipe is inserted, it is secured in the carriage by the chuck. This enables precise positioning of the pipe and thus the creation of dimensionally accurate geometries. The standard also includes a check of the pipe geometry before the bending process: If the bending process is started in the wrong position, the machine will not issue a release. This eliminates the risk of incorrect operation. Optional additional features provide greater convenience and increase output, thus increasing the efficiency of the system. Data exchange from the optional TBS-3D pipe calculation program (PC version) takes place via USB stick or network. Existing pipe geometries can be imported using the software. Standard equipment: → 1.5 kW servo drive for the bending axis → Adjustable speed → Left-hand bending direction Bcsdpfotr U Hljx Agpou → Bending angle resolution 0.1° → Max. bending radius 120 mm → Bending shaft diameter 50 mm → Feed servo drive → Rotation servo drive → Three-jaw chuck for locking the tube in the carriage → Pneumatic tool retraction Hydraulics: → Hydraulic tube clamping with adjustable clamping pressure → Programmable early mandrel retraction PLC control: → 10" color touchscreen → ETH 10/100, X2X Link, 2xUSB → Foot switch operation → Data transfer via LAN or USB network → Material database Unique graphical programming: Simple geometries can be calculated directly on the machine. The control system calculates the feed values and bending angles directly after entering the length and angle. Power consumption: 400V 16A Dimensions: L: 2.3 m x W: 1m x H: 1.4m Weight: approx. 1200 kg

Condition: like new (used), Year of construction: 2004, functionality: fully functional, machine/vehicle number: 051888, Used automatic disc cut-off saw Brand: Pedrazzoli Model: SB 350/45 AP Registration number: 051888 Year: 2004 Head block rotation mechanism for angled cuts up to 45° to the left with locking lever. Pneumatic and anti-burr removable vice. Pneumatic cylinder for head movement, with brake for speed regulation. Transmission with double extensible pulley for variable speed from 15 to 90 m/s. Tilting head on adjustable self-lubricating bushings. 600 mm pitch feeder controlled by pneumatic cylinder. Repeat up to a maximum of 9 steps, to obtain a total stroke of 5400 mm. Maximum feeder clamp opening 160 mm. Programmable piece counter. Minimum final cut waste of 160 mm. Feeder speed regulating valve. Ammeter. Reverse gear. Emergency button and switch with padlock on the control panel. Blade lubrication-cooling system with electric pump. Coolant tank with removable pump for tank cleaning. Integral guarding designed for quick blade change. Blade disc Ø 350 mm. Cutting capacity: Round tubes 0°: 102mm 45° right: 102mm Square tubes 0°: 85mm 45° right: 90mm Rectangular tubes 0°: 158 x 85mm 45° right: 120 x 85mm Features: Three-phase 380V Dimensions: 1300 x 1350 x 1600 mm Work station height: 950 mm Bsdpforfw Iksx Agpjcu Weight: 420 kg

Year of construction: 2000, condition: excellent (used), maker: diverse (Europäische Union) Bcodpsmqkubefx Agpeu year: 2000 tube Ø: 40 – 150 mm wall thickness: 1 – 4 (5) mm reference material (tensile strength): 1.000 N/mm² tube length shop entry: 4 – 10 m tube length shop exit: 4 – 8 m bundle weight: max. 3.000 kg bundle Ø: max. 600 mm working direction: left → right The shop consists of: • tube bundle destacker I with separation MAIR • tube straightender (10 rolls) BRONX type 10Cr.6-BWS • tube bundle destacker II with separation MAIR • wet separator HANDTE • tube bundle destacker III with separation MAIR • tube testing eddy current/ultrasonic ATM/KRAUTKRÄMER/FÖRSTER • multiple-head saw MAIR type MC150/7/10 • tube bevelling machine MAIR • brushing machine MAIR • destacker/stacker MAIR • tube bundle destacker MAIR • tube banding machine MAIR/ORGAPACK • emulsion treatment SCHOENAUER • control Siemens S7 • hydraulics
