Bandsaw/Cutting-Off Machine THOMAS TRAD

THOMAS TRAD 350

Used Bandsaw / Cutting-Off Machine – THOMAS TRAD 350 with Hydraulic Assisted Descent
Machine in excellent condition – Made in Italy

Perfect for cutting metal profiles and solid materials such as:
• Structural steel
• Heat-treated steel
• Stainless steel
• Aluminum
• Brass

General Features:
• Sturdy steel frame with well-proportioned thickness and dimensions, entirely made by national manufacturers.
• Hydraulic cylinder for assisted descent of the cutting bow with three operating modes:
• Assisted descent with quick approach of the blade to the workpiece
• Manual descent with constant speed
• Manual descent with free speed
• Vise group, rotation device, and cutting bow made from cast iron to ensure maximum strength and rigidity during operation
• Generously sized rotating table for increased stability of the workpiece
• Quick vise approach via dedicated lever
• Hydraulic blade tensioning with pressure gauge and safety pressure switch to stop rotation in case of loose or broken blade
• Blade guide group with tungsten carbide inserts and bearings to improve blade tracking and ensure perpendicular cutting
• High-quality anti-corrosion treatment on blade guide components to ensure long durability and consistently perpendicular cuts
• Integrated blade-cleaning brush

Technical Specifications:
• Maximum cutting capacity: 330 x 250 mm
• Blade motor power (2 speeds): 1.4 / 1.8 kW
• Power supply: 380 V – 50/60 Hz
• Wheel diameter: 330 mm
• Blade size: 2925 x 25 x 0.9 mm
• Vise opening at 90°: max 330 mm
• Vise opening at 45°: max 250 mm
• Bow inclination: 30°
• Working height from the ground: 700 mm
• Machine dimensions (LxWxH): 2010 x 1330 x 2000 mm
• Weight: 430 kg
