Vertical lathe

Tokarka Famar CNC Drehautomat ERGO 500

Condition: refurbished (used), Year of construction: 2015, Offered is a vertical turning center EMAG VSC 400 DD. The machine will be mechanically overhauled and rebuilt by EMAG before delivery. Depending on requirements, the machine can be equipped with other peripherals such as coolant systems, external automation and so on. The turning machine for automated machining of chucked components fits perfectly for the machining of series workpieces with the following dimensions: Workpiece diameter: 340 mm Workpiece height: 160 mm Iaedpfstngg Uex Ahuol Optional the machine can be equipped with an additional millling or grinding unit. CONTROL Siemens 840Dsl TECHNICAL DATA chuck diameter: max 400 mm swing diameter: max. 420 mm X-stroke: 850 mm Y-stroke: 315 mm Z-stroke: 315 mm TOOL CARRIER EMAG wheel turret, 12x VDI 50 with driven tools Delivery time and additional equipment of the machine on request.

Condition: used, Year of construction: 2007, turning diameter 600 mm swing diameter 680 mm turning height 600 mm z-axis 500 mm x-axis 560 mm drive of main spindle 65/80 kW main spindle speeds: 2800 workpiece tool changer 12 Plätze feeds z-axis 0,01-30.000 mm/min feeds x-axis 0,01-45.000 mm/min chuck Rota NCR 630 mm voltage 400 V frequency 50 Hz control Siemens 840 D pl Iodpsv Rrq Dsfx Ahusal total power requirement 140 A weight of the machine ca. 18 t dimensions of the machine ca. 6,5 x 3,8 x 4,20 m

Condition: used, Year of construction: 1993, turning diameter ca. 500 mm swing diameter ca. 600 mm travel -x axis ca. 400 mm Iodstyp Suspfx Ahujal travel -z axis ca. 600 mm spindle turning speed range 2000 U/min spindle drive 63 kW control SIEMENS control SINUMERIK System 3 tool turret 1 x 12 Pos total power requirement kW weight of the machine ca. 9,3 t dimensions of the machine ca. m - R-version, turret right hand side of 3-jaw chuck - Accessories: hydr. 3-jaw chuck 400 mmø, various toolholders for turret, chip conveyor, coolant

Condition: used, Year of construction: 2009, functionality: fully functional, Offered is a turning and milling machine EMAG VLC 800 MT with tool changer. The machine has a turret with 12 tool positions (VDI 50) and a milling spindle with tool changer for up to 96 tools. The tool magazine can be loaded during processing, which reduces setup time and allows the use of sister tools. The proven EMAG turret is available for turning operations on the machine. On the multifunctional VLC 800 MT production center, workpieces up to 800 mm in diameter can be completely processed in a single clamping. The following components will be sold with the machine: - Pick-up station - Extraction unit (IFM) - Coolant system with belt filter - Chip conveyor CONTROL Siemens 840D Iedpfx Ajw Au U Ushuoal MACHINE CONNECTION Mains voltage: 400V AC 50 Hz Connected load: 92kW Rated current: 143A Max. backup fuse: 160A The machine is sold on an “as seen” basis, without any warranty claims. The machine will be available from November 2025, machine is in production until Oktober. The machine can be completely overhauled on request. Please do not hesitate to contact us fot further information.
