BORING

TOS 100A

Condition: ready for operation (used), Year of construction: 1999, overall weight: 70 kg, number of axes: 5, This 5-axis TOS VARNSDORF W 100 A was manufactured in 1999. It operates on a voltage of 3PE ~ 400 V, with a frequency of 50 Hz and a current of 22 A. The machine's power capacity is 15 kVA, and it weighs 70 kg. Consider the opportunity to buy this TOS VARNSDORF W 100 A horizontal machining centre. Contact us for more information. • Voltage: 3PE ~ 400 V • Frequency: 50 Hz Hfedpfx Agjyblnusdsd • Current: 22 A • Power: 15 kVA • Control voltage: 24 V

Condition: good (used), Year of construction: 2015, Metal cutting Tooling TOS - HUR 50 Hfsdpswvht Rsfx Agdsd MACH-ID 2923 Make: TOS Type: HUR 50 Year: 2015

Condition: ready for operation (used), Year of construction: 2002, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,400 mm, This 3-axis TOS KUŘIM FS 100 S/A3 vertical machining centre was manufactured in 2002. Consider the opportunity to buy this TOS KUŘIM FS 100 S/A3 vertical machining centre. Contact us for more information. Additional equipment • Additional Documentation: User manual available Machine Benefits Technical Machine Benefits • Feed rates: standard: 1 to 5000 mm/min / rapid traverse (y and z axes): 10 m/min/ feed rate: 12 m/min Hfjdpfeyar A Aox Agded • Worktable: size: 1000 x 3000 mm / maximum workpiece weight: 7000 kg / number of t-slots: 7 / distance between t-slots: 140 mm / t-slot width: 22 mm / table height from the base (floor): 900 mm • Spindle: spindle taper: iso 50 / spindle diameter at the front bearing: 85 mm / minimum spindle distance from the worktable: 125 mm / maximum spindle distance from the worktable: 1775 mm / spindle speed: 16 to 3500 rpm (stepless)

Condition: used, Year of construction: 1992, spindle diameter 100 mm x-travel 1500 mm y-travel 1250 mm z-travel 1800 mm turning speeds 7,1-1120 U/min table surface area 1200x1200 mm w-axis 800 mm Radial face slide 600 mm radial face slide travel 200 mm digital readout Heidenhain The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More Hfsdpsyqwazefx Agdod than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: new, table length 2000 mm table width 1000 mm table height 920 - 1000 mm weight of the machine ca. 0,45 t Welding table / hole table: Hole diameter: 28mm The table is made of 15mm thick S355 steel The surface is stained and oiled. Tolerance: +/- 1 mm at the top and +/- 1 degree at the sides. Hjdpfx Agjvn Uycjdsfd Side panels 150 x 10mm Height adjustable from approx. 920 - 1000mm Ribbed bottom for reinforcement. including floor storage Accessories optional!! Accessories shown are optional!!

Condition: used, Year of construction: 1992, spindle diameter 100 mm x-travel 1500 mm y-travel 1250 mm z-travel 1800 mm turning speeds 7,1-1120 U/min table surface area 1200x1200 mm w-axis 800 mm Radial face slide 600 mm radial face slide travel 200 mm digital readout Heidenhain The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Hfedpoyqvmysfx Agdod Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: reconditioned (used), Year of construction: 1994, functionality: fully functional, travel distance X-axis: 4,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 900 mm, rapid traverse X-axis: 10 m/min, rapid traverse Y-axis: 10 m/min, rapid traverse Z-axis: 10 m/min, torque: 1,200 Nm, controller manufacturer: Heidenhain iTNC 426, workpiece weight (max.): 9,000 kg, total height: 3,320 mm, total length: 9,660 mm, total width: 4,918 mm, spindle speed (min.): 11 rpm, spindle speed (max.): 2,500 rpm, The machine is currently disassembled and is undergoing refurbishment with the following scope of work: - Complete disassembly and cleaning - Inspection of all components - New Tribotec lubrication unit - Overhaul of the dedicated console balancing circuit - Milling head “O” – complete overhaul including replacement of gears - Replacement of the gearbox bearings - Replacement of belts - Repair of ball screws and their bearings - Resealing of the machine’s hydraulic circuits and replacement of solenoid valves - Addition of automatic gear lubrication in the milling head - Resealing of all hydraulic cylinders and modernization of seals - Overhaul of the hydraulic power unit - Overhaul of Indramat feed motors and the spindle motor - Repair and adjustment of Indramat drives - Overhaul of the electrical cabinet including control elements - Replacement and modernization of limit switches throughout the machine - Repair or replacement of Heidenhain system cables and TNC 426 - Overhaul of the control panel - Overhaul of the Heidenhain TNC 426 control system, including keyboard and display unit - The machine will be fully functional and delivered with geometric accuracy documented by protocol - New machine paint in RAL 5005 and RAL 9010 color scheme. Technical Data Maximum spindle torque: 1,200 Nm Maximum feed force in X, Y, Z axes: 20,000 N Maximum workpiece weight: 9,000 kg Total table area: 1,000 x 4,000 mm Number of T-slots/table pitch: 7/140 mm Slot width: 24H7 mm Table height from base: 900 mm Longitudinal travel (X): 4,000 mm Cross travel (Y): 1,000 mm Vertical travel (Z): 900 mm Minimum distance from horizontal spindle axis to table clamping surface: 150 mm Maximum distance from horizontal spindle axis to table clamping surface: 1,500 mm Minimum distance from vertical spindle nose to table clamping surface: 130 mm Maximum distance from vertical spindle nose to table clamping surface: 1,030 mm Distance from horizontal spindle nose to inner table edge: 80 mm Distance from vertical spindle axis to inner table edge: 100 mm Spindle taper: ISO 50 Retraction force of clamping mechanism: 16,100 N Horizontal spindle swiveling – bilateral: 180° Vertical spindle swiveling – bilateral: 180° Spindle head positioning: adjustable in 2.5° increments Usable power of main drive motor: 22 kW Spindle speed range: 11 to 2,500 rpm Number of spindle speed steps: stepless Feed rate range: 1 to 5,000 mm/min Rapid traverse in Y, Z axes: 10 m/min Hsdexnkkaepfx Agdefd Rapid traverse in X axis: 10 m/min Machine available for delivery at the end of 2025.

Condition: excellent (used), Year of construction: 1982, Table size: 1250x1250 Spindle diameter: 100mm Cross: 1600mm Hfsdpfx Agjyghnheded

Condition: used, Year of construction: 1998, functionality: fully functional, travel distance X-axis: 4,000 mm, travel distance Y-axis: 1,400 mm, travel distance Z-axis: 1,000 mm, rapid traverse X-axis: 10 m/min, rapid traverse Y-axis: 10 m/min, rapid traverse Z-axis: 15 m/min, feed rate X-axis: 5 m/min, feed rate Y-axis: 5 m/min, feed rate Z-axis: 5 m/min, torque: 1,200 Nm, controller manufacturer: SIEMENS SINUMERIK 840D, workpiece weight (max.): 18,000 kg, total height: 4,950 mm, total length: 10,270 mm, total width: 5,640 mm, table width: 1,000 mm, table height: 800 mm, table length: 6,000 mm, table load: 18,000 kg, rotational speed (min.): 16 rpm, rotational speed (max.): 3,200 rpm, overall weight: 21,000 kg, spindle speed (max.): 3,200 rpm, spindle motor power: 22,000 W, type of input current: three-phase, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, FFQ 100W-A6(A8) CNC – TOS KUŘIM Machining Center, Table Length 6m (8m) Control System: Siemens 840 C Availability: According to selected refurbishment Warranty: According to selected refurbishment Can be supplied as used, after medium repair, or after general overhaul, including modernization. FFQ 100W-A6(A8) CNC – Technical Specifications: Basic Machine Data: Manufacturer: TOS Kuřim Overall Length: 10,270 mm Overall Width: 5,640 mm Overall Height: 4,950 mm Total Weight: 21,000 kg Total Connected Load: 40 kVA Working Range: Longitudinal Travel X-axis: 4,000 mm (6,000 mm) Cross Travel Z-axis: 1,000 mm Vertical Travel Y-axis: 1,400 mm Horizontal Spindle Head with Extendable Quill: Tool Taper per ČSN 22 0433 ISO 50 Max. Power: 22 kW Speed Range: 16 – 3,200 rpm Number of Speed Steps: Infinitely variable Max. Torque: 1,200 Nm Hfjdpfx Agsxp Iz Sedjd Quill Diameter: 170 mm Quill Extension: 400 mm Quill Working Feed Range: 1 - 2,000 mm/min Quill Rapid Traverse: 4,000 mm/min Max. Quill Feed Force: 10,000 N Spindle Head (IPS head): Tool Taper per ČSN 22 0433 ISO 50 Max. Power: 22 kW Speed Range: 16 – 3,200 rpm Number of Speed Steps: Infinitely variable Max. Torque: 1,200 Nm Machining H-V, spindle automatically adjustable to vertical or horizontal position Feed Range X – Y / Z: Number of Steps / Range: Infinitely variable / 1 – 5,000 mm/min Rapid Traverse Y – Z / X: 10,000 / 15,000 mm/min Table: Table Area: 1,000 x 6,000 mm (8,000 mm) Max. Load: 3,000 kg/m2 Tool Magazine: Number of Positions: 40 pcs Control System: SIEMENS 840 C Details upon request.

Condition: excellent (used), Year of construction: 1998, CN Heidenhain TNC 430 PA Maximum spindle torque: 900 Nm Maximum feed force in the X, Y, Z axes: 25,000 N Maximum workpiece weight: 2,500 kg (at 1 m table length) Table dimensions: 1,000 × 14,000 mm Number of T-slots in the table: 7 T-slot width × spacing: 22H7 × 140 mm Longitudinal travel (X): 12,000 mm Cross travel (Y): 1,000 mm Vertical travel (Z): 1,500 mm Horizontal spindle: Minimum distance between the horizontal spindle axis and table surface: 275 mm Maximum distance between the horizontal spindle axis and table surface: 1,775 mm Vertical spindle: Minimum distance between the vertical spindle face and the table: 50 mm Maximum distance between the vertical spindle face and the table: 1,550 mm Spindle taper: ISO 50 Spindle diameter: 85 mm Tool clamping force in the spindle: 16,500 N Hodpfxjxdwkfj Agdsfd Main machine dimensions: Length: 17,850 mm Width: 5,640 mm Width with enclosure: 6,720 mm Height: 4,350 mm Floor space required: 73 m² Total machine weight: approx. 34,000 kg Electrical cabinet weight: approx. 820 kg Mains voltage: 50 V (3 × 400) Total machine power: 100 kVA Fuses to be provided by the customer outside the machine for 400 V Hydraulic unit weight without oil: 150 kg
