Spindle lathe

TOS SU 100/6000

Condition: used, Year of construction: 2013, x-travel 1.135 mm y-travel 1.050 mm z-travel 750 mm control iTNC 530 Heidenhain turning speed range - main spindle max. 14.000 min/-1 power capacity - main spindel 19 kW max. Torque 100 Nm tool taper HSK-A 63 table surface area 1.400 x 1.050 mm max. table load 2.500 kg max. workpiece sizes 1.400 x 1.240 mm max. workpiece height 750 mm number of toolpositions 30 pos. tool taper HSK-A 63 max. tool diameter 80 mm max. tool-dia with free toolbox 160 mm max. tool length 365 / 395 mm max. tool weight 8,0 kg change-time chip to chip 6,1 sec feed speeds max. 40.000 mm/min rapid traverse 40 m/min Accelaration 6 m/s² Feed force ( X / Y / Z ) 14 / 20 / 14 kN total power requirement 44 kVA weight of the machine ca. 14,4 t dimensions of the machine ca. 6,0 x 5,0 x 3,3 m CNC - MachiningCenter Vertical Kedpfx Amsyztyaj Nelr DMG MORI SEIKI - DMU 105 monoBLOCK - Spindle hours: approx. 9,518 h - Production package: (Chip conveyor, 600 l coolant system, paper belt filter, internal coolant supply 40 bar / 23 l/min through spindle center) - Air Clear: Air curtain for viewing window

Condition: like new (used), Year of construction: 2024, functionality: fully functional, grinding length: 1,650 mm, grinding diameter: 400 mm, We offer a new BUB40 x 1500 NC machine equipped with a MITSHUBISHI NC controller. The machine is still under lease with ING Lease. It has been thoroughly refurbished based on the TOS HOSTIVAR BUB 40 model by FAS GŁOWNO. Technical data: • Maximum workpiece diameter: 400mm • Maximum workpiece length: 1500mm • Centre height: 200mm • Distance between centres: 1500mm • Minimum grindable workpiece diameter with a 380 mm grinding wheel: 20mm • Tailstock quill stroke: 40mm • Maximum tailstock clamping force: 4000N • Spindle headstock centre taper: ISO 296-1991/Morse 5 • Tailstock centre taper: ISO 296-1991/Morse 5 • Maximum workpiece weight between centres: 500kg • Maximum workpiece weight in chuck (including chuck): 100kg • Machine width (with enclosure): 6650mm • Machine depth (with enclosure, without control panel): 2400mm • Machine height (with enclosure): 1850mm Kedpfx Aswzkywom Nslr • Machine weight: 7000kg • Total power requirement: 38kVA Grinding spindle: • Standard grinding wheel dimensions: 500 x 80 x 203.2mm • Grinding spindle drive motor power: 11kW • Grinding spindle rated speeds (for 430 mm / for >430 mm and 500 mm wheels): 2000 / 1744 rpm • Grinding headstock traverse servo motor power: 2kW • Grinding headstock traverse servo motor torque: 9.5Nm • Maximum continuous X-axis traverse speed: 2m/min • Minimum X-axis grinding wheel increment: 0.001mm • Maximum continuous X-axis traverse speed: 6m/min • Minimum X-axis grinding wheel increment: 0.001mm • Maximum grinding wheel increment in INC mode: 0.1 mm • Table traverse servo motor power: 3.5 kW • Table traverse servo motor torque: 16.7 Nm Workpiece spindle: • Workpiece spindle speed range: 1 – 150 rpm • Workpiece spindle servo motor power: 3.5kW • Workpiece spindle servo motor torque: 16.7Nm More information available upon request via email or phone.

Condition: used, TECHNICAL DETAILS - Number of axes : 3 MILLING SPINDLE - Tool holder type : BT40 - Spindle power : 15 [kW] - Spindle speeds : 8100 [rpm] - Gearbox - Speed ranges : 2 - Number of spindle hours : 4000 [h] LINEAR AXES - Travels on X/Y/Z axes : 1270/508/635 [mm] - Rapid traverses rates (X/Y/Z) : 35.6/35.6/35.6 [m/min] - Cutting feed rates (X/Y/Z) : 21 [m/min] - Distance table / spindle nose (min./max.) : 742 [mm] TOOL CHANGER - Auto. Tool Changer type : Bras chargeur - Tool magazine capacity : 40 TABLE - Table dimensions : 1321/495 [mm] - Maximum weight upon table : 794 [kg] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 30 [kW] WEIGHT & DIMENSIONS - Machine floor space : 3870/2510 [mm] - Machine height : 2690 [mm] - Machine weight : 6260 [kg] MACHINE HOURS - Number of hours under power : 16247 [h] - Number of working hours : 6025 [h] Klodpoyn R Igefx Am Nsr EQUIPMENT - CNC : HAAS - Interface : Ethernet / RS232 / USB / PCMCIA - Interactive programming - Electronic handwheel - Rigid tapping - Prepared for a 4th-5th axis divider - Coolant tank : 208 [l] - Chips conveyor - Tool probe - Electric transformer

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, Description Kledpfsvlayvjx Am Ner Trumpf TRUBEND 5085 - WORKING INSIDE PRODUCTION DAILY ORDERS WORKING HORS: PRESENT ON PHOTO OF SCREEN Year 2011 Compression force: 85 tonnes Table length: 2,200 mm Free travel speed: 220 mm/s Accessories: Increased lift height from 230 mm to 615 mm. 5-axis bending. Hydraulic tool clamping at the bottom. Hydraulic tool clamping at top. Automatic bombing. Bendguard guard ACB angle measurement FOR CLIENT WE ORGANIZE AS WELL DISMANTLING AND TRANSPORT Specifications Manufacturer TRUMPF Model TRUBEND 5085 Year 2011 Condition Used (EXCELLENT)

Condition: good (used), Year of construction: 1999, TOS SU 150 Variant CNC Lathe TOS SU 1500 Variant with Heidenhain Control, year of manufacture 1999, in excellent original condition The machine comes from the special production department of a renowned German mechanical engineering company. CE compliant! Kledpfox Dy I Tsx Am Ner Technical Details: Year of manufacture: 2004 Working Range Swing diameter over bed: 1500 mm Swing diameter over support: 1190 mm Swing diameter over extended slide with T-slots: 1100 mm Swing diameter over right-angle hardened guide with T-slots: 1020 mm Distance between centers: 2000 mm Max. workpiece weight (without/with support): 6000/8000 kg Spindle size: 11 DIN 55027; bayonet Spindle bore: 128 mm Speed range: 4 - 630 rpm Main drive power: 37 kW Max. spindle torque: 12,000 Nm Tailstock Quill diameter: 165 mm Internal taper: 100 (1:20) mm Reduction sleeve: 100 (MK6) Total power consumption: 67 kVA Weight: 9,400 kg The universal spindle lathe SU 1500 Variant is a numerically controlled machine designed for roughing and finishing of shaft and flange parts, as well as for threading, drilling, taper turning, and machining of various rotationally symmetrical surfaces. The machine is built with a rigid horizontal bed, the guideways are hardened and ground, and the counter surfaces on the longitudinal slides are coated with Turcite B sliding material. The SU 1500 Variant lathe is a machine with automatic cycle control, equipped with a Heidenhain control system. The feed drive for the longitudinal axis (Z-axis) is provided by a servo drive directly to the ball screw. The cross-feed drive (X-axis) is also provided by a servo drive directly to the ball screw. Both feeds are measured by rotary encoders mounted on the servo motors. The machine can be operated either manually or in controlled (automatic) mode. About the machine: Offered here is a CNC lathe TOS SU 1500 Variant with Heidenhain control, year of manufacture 1999. This lathe is in very good original condition. Coming from a shop where it was only used occasionally for special builds. The control system is very user-friendly. The ways are regularly lubricated by the central lubrication system. The TOS SU 1500 Variant has been mechanically and electrically inspected by us. Take the opportunity to view and test the TOS SU 1500 Variant under power at our premises. You will find further lathes from reputable manufacturers on our website.

Condition: excellent (used), Year of construction: 2020, Unique opportunity to purchase this high quality CHIRON 5-axis machining center for profiles. Built and first use in 2020. The spindle was replaced in June 2022 and currently has 4500 operation hours. Machine is in very good condition and it can be inspected under power upon appointment. Availability: on request Including: Chip conveyor (scraper type) Profile bar feeder for bar lengths up to 6 m, for guiding profiles up to Ø 212 mm Coolant system TPF 350 / FKA 900 Coolant through the spindle Fixed 3D probe Type TS 27 R – RENISHAW Renishaw RLP40Q probe system Cnc control SIEMENS 840D X-axis 730 mm Y-axis 400 mm Z-axis 425 mm Maximum spindle speed 15,000 rpm Kodeyt I Uhjpfx Am Nelr Maximum torque 140 Nm Drilling capacity Ø 42 mm Thread tapping M30 Tool magazine capacity 20 tools Tool taper DIN 69893 HSK A63 Maximum tool diameter 65 mm Milling capacity 500 cm³/min in E355 steel Full technincal specifications in the attached document. Optional: ARMIN automatic robot cell (2024)
