Driven tool holder

Traub TNL

Condition: ready for operation (used), Year of construction: 2007, operating hours: 19,441 h, functionality: fully functional, machine/vehicle number: 6000816, turning length: 50 mm, spindle speed (max.): 12,000 rpm, bar passage: 12 mm, controller model: Mitsubishi TX-8i, counter spindle speed (max.): 12,000 rpm, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Turning length: 50 mm Main spindle Technology: Belt-driven spindle Speed: 12,000 rpm Power: 4 kW Torque: 7 Nm Bar capacity: 12 mm Travel in Z1: 50 mm Workpiece clamping: Collet chuck Counter spindle Technology: Belt-driven spindle Speed: 12,000 rpm Power: 4 kW Torque: 7 Nm Travel in X3/Z4: 222/139 mm Rapid traverse in X3/Z4: 15 m/min Workpiece clamping: Collet chuck Tool Carrier I (X/Y) Technology: Turret with 6 stations (fully driven) Tool holder: Ø25 mm Driven tool speed: 8,000 rpm, 1.5 kW, 2.4 Nm Travel in X1/Y1: 35/37.5 mm Rapid traverse in X1/Y1: 15 m/min Tool Carrier II (X/Z) Technology: Turret with 6 stations (fully driven) Tool holder: Ø25 mm Driven tool speed: 8,000 rpm, 1.5 kW, 2.4 Nm Travel in X2/Z2: 35/50 mm Rapid traverse in X2/Z2: 15 m/min Front Attachment Number of stations: 4 Tool holder: Ø28 mm Station pitch: 32 mm Driven tool speed: 12,000 rpm, 4 kW, 7 Nm Number of driven stations: 4 Travel in X3/Z3: 222/139 mm Rapid traverse in X3/Z3: 15 m/min Rear Attachment Number of stations: 4 Tool holder: Ø28 mm Station pitch: 32 mm Driven tool speed: 8,000 rpm, 1.5 kW, 2.4 Nm Number of driven stations: 4 Fodpfx Ajx Hxv Djgmjpb Travel in X4: 39 mm Rapid traverse in X4: 15 m/min MACHINE DETAILS Control system: Mitsubishi TX-8i Dimensions & Weight Spindle center height above floor: 1,050 mm Dimensions (L x W x H): 1,450 x 1,098 x 1,700 mm Dimensions (L x W x H) with standard coolant tank: 2,355 x 1,098 x 1,700 mm Weight with control cabinet (max. configuration): 2,000 kg Weight without control cabinet (max. configuration): 1,600 kg Weight with control cabinet (min. configuration): 1,200 kg Weight without control cabinet (min. configuration): 850 kg Operating Hours Power-on hours (control): 19,441 h Automatic mode 1: 7,607 h Automatic mode 2: 6,720 h Production time: 38,989 h Total counter: 50,536 h EQUIPMENT Chip conveyor Coolant pump Bar feeder FMB minimag 3200 Workpiece discharge device (tube) Mechanical interface prepared Various fixed holders Rinse gun

Condition: used, Year of construction: 2013, operating hours: 43,000 h, functionality: fully functional, spindle motor power: 3,700 W, spindle speed (max.): 10,000 rpm, overall weight: 5,000 kg, total width: 1,500 mm, total length: 4,000 mm, total height: 2,400 mm, rapid traverse X-axis: 20 m/min, rapid traverse Y-axis: 20 m/min, rapid traverse Z-axis: 40 m/min, power: 24 kW (32.63 HP), travel distance Z-axis: 205 mm, Equipment: documentation/manual, We are offering one of our machines for sale, as it is being decommissioned due to a scheduled upgrade of our machinery fleet. The machine is a TRAUB TNL 18P sliding headstock lathe, manufactured in 2013, in good technical condition. The reason for the sale is the acquisition of new technology as part of our machinery renewal program. The current operating hours are 43,000. Fpjdjxdk Ukepfx Agmjb The offer also includes an FMB Minimag 20/3200 bar feeder, which ensures smooth and efficient material feed into the machine. As part of the delivery, we can also supply internal equipment, including guide bushings and collets for the main spindle, sub-spindle, and bar feeder, suitable for material diameters up to 12 mm. If you are interested, please feel free to contact me.

Condition: excellent (used), Year of construction: 2014, operating hours: 53,000 h, functionality: fully functional, For sale is a high-precision INDEX TRAUB TNL 32-7 in absolutely top condition. This is a former demonstration model from TRAUB, featuring full equipment. The machine was purchased at the end of 2016 and has been handled with exceptional care ever since. This machine is being sold with an extensive tooling package. The included tool holders alone (including many live double and triple holders) have a replacement value of approximately €25,000 to €30,000. This makes the machine the ideal solution for operations wishing to immediately carry out highly complex machining without lengthy additional investments. • Flexibility: The machine can be used in both Swiss-type (sliding head) and fixed headstock modes—a key advantage for varying production needs. Fpjdox Sr I Rspfx Agmsb • Condition & Operation: The machine has been operated exclusively with oil (no emulsion!), and approximately 95% of the workpieces processed have been stainless steel. This has kept the mechanics in excellent condition. • Accessory package: The machine comes with a very comprehensive set of tool holders, including many live (driven) holders (also double and triple holders). Numerous collets for both main and sub spindle are included, as well as several channels for the bar feeder. • Documentation: The original order confirmation, documenting all details of the full equipment, is available on request. IMPORTANT SALES NOTE (PACKAGE DEAL): Currently, I am selling a total of three high-quality lathes. In addition to this TNL 32-7, two TRAUB TNK 36 machines are also available, which you can also find here on Machineseeker. If all three machines are purchased as a package, I will offer an unbeatable total price! For full package buyers, I will additionally include substantial extras that are not part of the standard supply, such as additional chip trolleys (multiple trolleys included), various tools, and workbenches—everything needed for a quick production start. - Location: 79115 Freiburg (DE) - Availability: The machine is powered up for demonstration and available immediately. - Scope of delivery: Includes tool holders, collets, and complete documentation. • Year of manufacture: 2014 (commissioned end of 2016) • Condition: Very well maintained, operated with oil • Control: TRAUB TX8i-s • Working area: Bar capacity Ø 32 mm • Spindles: Main and sub spindle (both up to 8,000 rpm & C-axis) • Tool carriers: • Upper: 10 stations (Dual Drive) • Lower: 9 stations (separate sub-spindle drive) • Rear: 8 stations (prepared for internal coolant supply) • High-pressure package: ECO-Fluid System with frequency-controlled pump (20 to 80 bar)—perfect for oil operation and demanding materials. • Precision package: Additional glass scales on the X-axes. • Cooling & filtration: Paper band filter (50 µm) and air-cooled immersion chiller (4.5 kW). • Safety: Automatic CO₂ extinguishing system (Kraft & Bauer)—essential for safe oil operation—and coolant mist extraction. • Software: Extensive packages for polyform, helical, polygon turning, and gear milling. • Automation & peripherals • Bar loading magazine: FMB Turbo 3-36 (up to 3,200 mm bar length) incl. shifting device. • Parts handling: Integrated parts gripper and conveyor for gentle part removal. Price: On request (attractive package deal available)

Condition: good (used), Year of construction: 2013, functionality: fully functional, Description: The machine is in good technical condition; testing is possible by prior arrangement. The offer also includes an FMB Minimag 20/3200 bar feeder, ensuring smooth and efficient material feeding into the machine. As part of the delivery, we can also provide internal equipment – guide bushes and collets for the main spindle, sub spindle, and bar feeder – suitable for material diameters of 3–12 mm. Max. bar capacity (mm): 20 (0.8) Z1 stroke max. (mm): 205 (8.1), 80 (3.1) Max. spindle speed (rpm): 10,000 / 10,000 Power at 100% / 40% (kW [hp]): 2.2 / 3.7 (3.0 / 5.0) Torque at 100% / 40% (Nm [ft-lb]): 14 / 23.5 (10.3 / 17.3) C-axis resolution (degrees): 0.001 Rapid traverse Z1 (m [in]/min): 40 (1,574) Upper turret: Tool mounts (number): 8 Live tools (number): 8 Power at 100% / 40% (kW [hp]): 1 / 2 (1.3 / 2.7) Tool mounting diameter (mm [in]): 45 (1.8) Fjdpex An T Uofx Agmjpb Turning tool cross-section (mm [in]): 16 x 16 / 12 x 12 (0.6 x 0.6 / 0.5 x 0.5) X1 travel (mm [in]): 120 (4.7) Rapid traverse X1 (m [in]/min): 20 (787) Chip-to-chip time:

Condition: excellent (used), Year of construction: 2013, operating hours: 40,000 h, functionality: fully functional, spindle motor power: 6,700 W, turning length: 305 mm, turning diameter over cross slide: 32 mm, spindle speed (max.): 8,000 rpm, spindle speed (min.): 1 rpm, turning diameter: 32 mm, spindle bore: 32 mm, overall weight: 7,350 kg, type of input current: three-phase, bar passage: 32 mm, feed length X-axis: 140 mm, feed length Y-axis: 65 mm, feed length Z-axis: 305 mm, Equipment: rotational speed infinitely variable, CNC Sliding Headstock Automatic Lathe Manufacturer: Traub Model: TNL 32 T-9 Control System: TX8i-s Year of Manufacture: 2013 Location: Sweden, still in production Availability: From January / February 2026 Operating Hours: approx. 40,000 h Technical Data Spindle through-hole (mm): 32 Max. spindle speed (rpm): 8,000 Power (100% / 25% duty cycle) (kW): 6.7 / 10.7 Torque (100% / 40% duty cycle) (Nm): 21 / 32 C-axis resolution (degrees): 0.001 Z axis travel (mm): 305 / 127 (sliding headstock / fixed headstock) Rapid traverse Z (m/min): 20 Subspindle Spindle through-hole (mm): 30 Max. spindle speed (rpm): 6,400 Power (100% / 25% duty cycle) (kW): 3.7 / 5.5 Torque (100% / 40% duty cycle) (Nm): 29.4 / 43.7 C-axis resolution (degrees): 0.001 X travel, rapid traverse (mm / m/min): 140 / 20 Z travel, rapid traverse (mm / m/min): 300 / 20 Tool Carrier 1 Configurable as turret Number of stations: 10 Max. speed (rpm): 12,000 Max. power (kW): 3.4 X travel, rapid traverse (mm / m/min): 140 / 20 Y travel, rapid traverse (mm / m/min): -40/+25 / 20 Z travel, rapid traverse (mm / m/min): 300 / 20 Tool Carrier 2 Configurable as turret Number of stations: 10 Max. speed (rpm): 12,000 Max. power (kW): 3.4 X travel, rapid traverse (mm / m/min): 140 / 20 Y travel, rapid traverse (mm / m/min): -25/+40 / 20 Z travel, rapid traverse (mm / m/min): 320 / 20 Dimensions, Weight, Electrical Connection Weight: 7,350 kg (depending on configuration) Connected load (kW): 28 Additional Equipment - Chip conveyor - External tank with paper band filtration system - Bar feeder: FMB Turbo 3-36, 4.2 m bar length Fpodpsx Rwkuofx Agmjb - Guide bushes, collets, magazine liners (?) - Tool holders, driven and static - Documentation - High-pressure coolant system - Fire extinguishing system + Kraft & Bauer fire extinguishing system control The operator panel and hard drive were replaced in spring 2025 (approx. €24,000 incl. service costs). New drive belts for the main spindle and driven tools were recently changed. Service carried out as scheduled. Between 2019 and 2020, several extremely costly refurbishments of spindles and drive units were carried out, including new bearings and a new motor. At 27,000 operating hours. All information has been provided to the best of our knowledge and belief, but we reserve the right to make errors. Subject to prior sale. All prices are net, plus statutory VAT, ex works.

Condition: excellent (used), Year of construction: 2012, ONLY 8,300 spindle hours! Control: TX 8 i-p MAIN SPINDLE Max. bar capacity: 32 mm Max. workpiece length - Swiss-type operation: 245 mm - Short turning operation: 125 mm Max. spindle speed: 6,400 rpm C-axis SUB SPINDLE Max. bar capacity: 32 mm Max. clamping depth of workpiece: 250 mm Max. spindle speed: 6,000 rpm C-axis UPPER TOOL TURRET Number of stations: 10 All driven Max. speed: 12,000 rpm LOWER TOOL TURRET Number of stations: 9 All driven Max. speed: 12,000 rpm BACK WORKING UNIT Number of stations: 8 Driven stations: 3 (T12, 13 and 14) Speed T12 & T14: 12,000 rpm Speed T13: 4,000 rpm Parts conveyor Chip conveyor Coolant pump 20 bar IFS oil mist filter Fodoxrf Etopfx Agmspb Bar loader FMB turbo 3-36

Condition: used, Year of construction: 2011, controller manufacturer: Mitsubishi, controller model: TX-8i, _____ Description: Year of manuf. : 2011 Control : Mitsubishi TX-8i Turning length : 50 mm Mainspindle: Technology:Belt-driven spindle Speed:12.000 rpm Power:4 kW Torque:7 Nm Barcapacity:15 mm Movement in Z1:50 mm Workpiececlamping:Collet chuck Subspindle: Technology:Belt-driven spindle Speed:12.000 rpm Power:4 kW Torque:7 Nm Movement in X4/Z4:222/139 mm Rapid travers in X3/Z4:15 m/min Workpiececlamping:Collet chuck Toolcarrier I (X/Y): Technology:Turret with 6 stations (Complete drive) Taper:ø25 mm Tooldrive:8.000 rpm, 1,5 kW, 2,4 Nm Movement in X1/Y1:35/37,5 mm Rapid travers in X1/Y1:15 m/min Toolcarrier II (X/Z): Fjdpfxsx E Inmo Agmepb Technology:Turret with 6 stations (Complete drive) Taper:ø25 mm Tooldrive:8.000 rpm, 1,5 kW, 2,4 Nm Movement in X2/Z2:35/50 mm Rapid travers in X2/Z2:15 m/min Front attachment: Number of stations:4 Taper:ø28 mm Distance between stations:32 mm Tooldrive:12.000 rpm, 4 kW, 7 Nm Number of driven stations:4 Movement in X3/Z3:222/139 mm Rapid travers in X3/Z3:15 m/min Rear attachment: Number of stations:4 Taper:ø28 mm Distance between stations:32 mm Tooldrive:8.000 rpm, 1,5 kW, 2,4 Nm Number of driven stations:4 Movement in X4:39 mm Rapid travers in X4:15 m/min Equipment/Accessory: Chipmanagement:Chip conveyor Coolingmanagement:Coolant pump Rawmaterialfeed:Bar loader, FMB minimag 20/3200 Finishedpartremoval:Workpiecehandling (Tube) Oilmistseparation:Interface mechanical prepared Toolholder:Misc. static and driven toolholder

Condition: ready for operation (used), Year of construction: 2014, Main Drive Number of axis 9 Spindle Speed 8000 RPM This 9-axis TRAUB TNL 32 swiss type turning machine was manufactured in 2014. It features a TX8i-s control with a 64-bit RISC CNC/PLC processor, color TFT display, and electronic handwheel. The main spindle supports a 32 mm bore, and the machine includes a sub-spindle with a C-axis. It offers a dual-driven upper tool turret and a lower turret with nine tool holders. Consider the opportunity to buy this TRAUB TNL 32 swiss type turning machine. Contact us for more information. Fjdpfjx D Drcox Agmepb Application Types Turning

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, spindle speed (max.): 12,000 rpm, turning diameter: 32 mm, overall weight: 7,000 kg, rapid traverse Z-axis: 20 m/min, power: 10.7 kW (14.55 HP), Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, C-axis Upper tool turret with X/Y/Z/H axis and 10 tool holders Lower tool turret with X/Y/Z/H axis and 9 tool holders Rear device with 8-fold total drive for 3 tools Hinged belt conveyor Resy paper band filter Fsdpfsx Diglex Agmepb Traub tool monitoring FMB LSK 38 – bar feeder

Condition: like new (used), Year of construction: 2022, operating hours: 13,116 h, Max. bar capacity mm: 20 Max. Z-axis travel (sliding headstock/fixed headstock) mm: 205 / 80 Max. spindle speed rpm: 10,000 Drive power 100%/40% duty cycle kW: 3.0 / 5.5 Torque 100%/40% duty cycle Nm: 5.73 / 10.5 / max. 17.2 C-axis resolution degrees: 0.001 Max. rapid traverse Z m/min: 20 Tool stations: 8 Driven tools: 8 Max. tool speed rpm: 12,000 / 8,000 Tool holder diameter mm: 45 Drive power 100%/40% duty cycle kW: 1.0 / 2.0 Turning tool cross-section mm: 16x16 / 20x20 Slide travel X mm: 120 / 165 Slide travel Y mm: ±25.4 Slide travel Z mm: 254 / 567.5 Rapid traverse X/Y/Z m/min: 20 / 20 / 40 B-axis swivel angle degrees: 105 Lower turret: Tool stations: 8 Driven tools: 8 Fjdewuddvepfx Agmepb Max. tool speed rpm: 12,000 Tool holder diameter mm: 45 Drive power 100%/40% duty cycle kW: 1.0 / 2.0 Turning tool cross-section mm: 16x16 / 20x20 Slide travel X mm: 120 Slide travel Y mm: ±25.4 Slide travel Z mm: 155 Rapid traverse X/Y/Z m/min: 20 / 20 / 40 Back working device: Tool stations: 4 Slide travel X/Y/Z mm: 120 / ±25.4 / 155 Tool holder diameter mm: 25 Sub spindle: Max. spindle bore mm: 20 Max. spindle speed rpm: 10,000 Drive power 100%/40% duty cycle kW: 3.0 / 5.5 Torque 100%/40% duty cycle Nm: 5.73 / 10.5 / max. 17.2 Slide travel X mm: 235.5 Slide travel Z mm: 258 C-axis resolution degrees: 0.001 Rapid traverse X/Z m/min: 20 / 40 Coolant system basic unit: Pump pressure bar: 3 / 8 Tank capacity l: 250 Flow rate at 3 / 8 bar l/min: 80 / 120 Filtration degree µm: 200 Machine dimensions Length x width x height mm: see installation plan* Weight kg: 5,000* Connected load kW: 40 (47 kVA)
