Fiber Laser Cutting Machine

TRUMPF TruLaser 3030 Fiber

Condition: used, functionality: fully functional, Year of construction: 2015, Machine - Enclosed machine frame - Automatic pallet changer in longitudinal direction - Torque drive in combination with linear direct drives - Enclosed beam guidance using fiber optic cable (LLK) - Machine cooling unit (water-air) - Integrated control cabinets with interior lighting - Power supply to TruDisk via the machine - Longitudinal conveyor belt - Work area lighting - Positioning laser diode - Oil spray device - PierceLine - FocusLine - NitroLine - PlasmaLine - Automatic nozzle cleaning - Transport and assembly device TRUMPF Laser - Solid-state laser TruDisk with 1 fiber optic output - Laser cooling unit (water-air) - Excitation via pump diodes - Laser power control Cutting Unit - Universal cutting unit with fully adaptive lens system - Single cutting head strategy - Protective glass against lens contamination - Protective glass condition monitoring - ControlLine: height control and sheet metal edge detection Control - Advanced workshop programming (TruTops via network access) - Fast repeat production - 17" touch color screen - Integrated technology data - Automatic shut-off - Programmable selection of cutting gas/pressure - ContourLine - Microweld - FastLine - FlyLine - AdjustLine - Teleservice via Internet - Integrated e-shop Ijdpfx Ajxw Uryob Hotp Data Transfer - USB interface - RJ-45 network socket Safety - CE marking - Light barriers - Multi-chamber extraction system - Compact dust extractor - Machine enclosure with certified viewing window (right door) - Roll-up roof Special Equipment: • 3001 on TruDisk 4001 • Extended pallet extraction • Dust protection device panel • Viewing window left • Side viewing windows right • Storage interface • Brightline Fiber • Titanium cutting package • Brass cutting package • Copper cutting package • Nozzle changer

Condition: used, functionality: fully functional, Year of construction: 2022, operating hours: 9,000 h, laser hours: 9,000 h, TRULASER LASER 3030 L95 4kW + LOADMASTER Year of Manufacture: 06/2022 Machine Hours: 14,000 h Laser Beam Hours: 9,800 h Basic Machine: - TruLaser 3030 fiber (L95) - Working area: 3000 x 1500 mm - Box frame construction - Longitudinal conveyor belt - High-precision motion unit - Gantry drive combined with linear direct drives - Process cooler for machine and laser (water/air) - Illuminated work area - Pilot laser - Spraying equipment - Automatic nozzle cleaning - Integrated electrical cabinets - Integrated auxiliary cabinet - Enclosed beam guidance via laser light cable (LLK) - Machine status indicator light - Transport and installation equipment TRUMPF Laser: - Excitation via pump diodes - Laser power regulation Cutting Unit: - Single cutting head concept - Universal cutting unit with adaptive lens system - Protective window - Online protective window condition monitoring - Automatic nozzle centering Control: - Quick post-production features - SINUMERIK 840D SL CNC controller - Ergonomic control panel with 21.5" widescreen multi-touch color display - Integrated technology database - Auto-shutdown feature - Programmable cutting gas/pressure selection - Micro-welding function - Remote support interface - Production scheduling - Multi-sheet processing - Condition Guide - Cutting Guide Itjdpfjxw Uy Djx Ab Hsp Functions: - AdjustLine - ControlLine - FastLine - FlyLine - FocusLine - NitroLine - PierceLine - PlasmaLine - Copper Cutting Package - Brass Cutting Package Data Transfer: - USB interface - RJ45 network port - Central Link - Online Update Manager Safety: - CE marking and EC Machinery Directive compliance - Light barriers - Multi-chamber compact dust extractor - Fully enclosed safety housing with certified viewing panel (right) Advanced Standard Configuration: - Compact dust extractor - Sliding roof - Mild steel support slats - TruDisk power supply via machine - Longitudinal automatic pallet changer - Suitable for ambient temperatures 5 to 40°C / max. 45°C - External solid-state TruDisk 4001 laser with single output ADVANCED EQUIPMENT: - External solid-state TruDisk 4001 laser with single output, includes BrightLine fiber - Camera 1 - Drop & Cut feature - Highspeed Eco cutting package (high-speed cutting with low gas consumption) - Thick sheet metal cutting package - Wireless Operation Point - MDE Interface AUTOMATION: - LoadMaster 1530 loading system Technical Data: Control, Hardware, Electricals: - Control: Siemens 840D SL - Operating system: Windows 10 IoT - Display: Multi-touch screen - Screen size: 21.5" - Interface: USB Axis Data – Maximum Axis Speed: - Simultaneous: 170 m/min Working Range, Workpiece Size – Nominal Range: - X axis: 3000 mm - Y axis: 1500 mm - Z axis: 116 mm Laser-Specific Data (TruDisk 4001): - Maximum laser power: 4000 W - Max. sheet thickness (mild steel): 25 mm - Max. sheet thickness (stainless steel): 20 mm - Max. sheet thickness (aluminum): 20 mm LoadMaster 1530: Loading Specifications: - Max. sheet size: 3000 mm x 1500 mm - Max. sheet thickness: 25 mm - Max. sheet weight: 900 kg
