Profile milling machine

VERTONGEN Pentho C4

Condition: refurbished (used), Year of construction: 2001, machine/vehicle number: 081001, WOODWORKING TENONING MACHINE WITH AUTOMATIC FEED, 4 OPERATIONS Brand: VERTONGEN Model: PENTHO C 4 B Serial No.: 081001 Year: 2001 (Photos taken prior to overhaul, functional testing & cleaning) Automatic cycle woodworking tenoner with manual operator group selection and fine adjustment. MACHINING CAPACITIES: - Max. wood section (thickness x width): 135x230 mm - Max. cutting height: 135 mm MACHINE CONFIGURATION: Table: - Cast iron table 400x600 mm, tiltable up to 60°, positioning by clamping - 2 pneumatic hold-down clamps for wood clamping - Extendable metric stop ruler with double stop, anti-splinter profile, and end support 1) Sawing: cross-cutting - 2.2 kW (3 HP), blade speed 3,000 rpm - Saw blade Ø400 mm, bore Ø30 mm - Cutting depth adjustment 140 mm 2) Top and bottom planing cutterheads with carbide knives: - Cutterhead with W3 carbide knives, Ø160xL140 mm - Top head 3 kW / bottom head 2.2 kW, rotation speed 4,500 rpm - Independent manual fine adjustment for withdrawal or positioning: Top cutterhead axial movement: -40/+35 mm, vertical travel 0-135 mm Bottom cutterhead axial movement: -40/+10 mm, vertical travel 0-80 mm 3) Spindle moulder: - Power 5.5 kW, speed 4,000 rpm - Spindle Ø50 mm, useful length 160 mm - Vertical travel 150 mm, horizontal travel 130 mm - Max. tool diameter (tenoning discs) Ø350 mm 4) Shoulder head (cutterhead) for left and right operation: - Power 2.2 kW (3 HP), speed 4,500 rpm - W3 carbide knife cutterhead Ø160xL140 mm - Manual fine adjustment for withdrawal, positioning, and travel OTHER TECHNICAL FEATURES: - Main power supply: 3-phase + N + PE, 400V, 50Hz - Installed power: 15.1 kW (20.5 HP), rated IN 30A - Counters for manual operational adjustments - Pneumatic supply: 6 bar working pressure (for hold-downs) - Dust extraction ports and recommended airflows: 360 (saw) + 2500 (cutterheads) + 1250 (spindle moulder) + 2500 (shoulder head) m³/h Air velocity 25-30 m/s Codpjwxdb Nofx Abwjrh Manifold supplied, 1 connection, flanged edge 280 mm. If shoulder operation is used, provide for branching: 160F/150F/150F flex hoses - CE marking, automatic retraction of guards, braked motors, padlockable main isolator, emergency stop buttons Transport dimensions (LxWxH): 3.70 x 1.70 x h.2 m Weight: 1650 kg
