Lead/traction spindle lathe

WEILER Condor 81 B

Condition: new, turning length 850 mm turning diameter 400 mm swing diameter over bed slide 245 mm spindle bore 52.0 mm turning speeds 45 - 1800 U/min bed width 260 mm spindle taper DIN 55029 D 1-5 taper in tailstock 3 MK quill travel 120 mm total power requirement 3.0 / 4.5 kW weight of the machine ca. 1255 kg range L-W-H 1900 x 1000 x 1610 mm Equipment: - 3-axis digital display ES-12 V with LCD display - 3-jaw chuck PS3-200 mm / D5 - Clamping disk 320 mm - Fixed steady rest - passage diameter max. 130 mm - Follow-on steady rest - passage diameter max. 100 mm - Coolant system - Quick-change tool holder with 4 inserts - Protective device for quick-change tool holder - Micrometer longitudinal stop - Slip clutch - Motor with magnetic brake in accordance with CE standard - Initial filling with Shell Tellus 46 - Extendable chip tray - LED machine light - Change gears Kdodpoxaaxwefx Akwjt - Reduction sleeve - 2 centering points - Chip rear wall - Operating tool

Condition: reconditioned (used), Steel grinding machine Manufacturer: REMA Model: DS 07/ST Kdjdehvu Tmjpfx Akwst Version with reversible motor 0.22/0.37 kW 1450/2900 rpm Year of manufacture: unknown Serial no.: 022857 Equipment: - Reversing switch for right/left rotation - Benchtop version with chip tray - Wet grinding system - 2 pcs. support table ATS (left) adjustable from -5° to +15° and with spring suspension - 2 pcs. angle stops - Adjustable support table ATK (right) for grinding chip guide steps - Steel holder for support table ATK 360° rotatable, pivotable, with height adjustment and knurled screw for adjusting the chip depth - Enlarged protective cover (left) with silicon carbide cup wheel Ø 175 mm with mounting flange - Protective cover (right) for grinding wheels Ø 125 mm with mounting flange - Operating manual Used, as is, no guarantee

Condition: good (used), Year of construction: 2010, Conventional lathe, center high 254 mm, between centers 1000 mm, bore Ø 80 mm, 12 speed 30 - 2200 rpm, motor 5,5 kw, camlock 6'', dimensions 230x115x165 cm, weight ca. 1750 kgs; equipement: DRO on 2 axis, coolant device, 3-jaws chuck Ø 250 mm, rotating pin, tool post MULTIFIX C with toolholders, steady and following rest Kjdpfx Aetv Iy Eekwodt

Condition: good (used), Year of construction: 1990, CNC Universal Milling Machine MAHO MH600-C Control MAHO 432 with universal clamping table . Spindle holder : ISO 40 Travels : X 600 mm Y 400 mm Z 500 mm Spindle speeds up to 2 000 rpm Kedpfx Aourcybokwodt with work area enclosure Machine documentation available . Machine from tool shop in good clean general condition Ready for demonstration under power .

Condition: used, functionality: fully functional, Manufacturer: Haaf (formerly Gema) Type: LZ 185 Swing diameter over bed 365 mm, over cross slide 225 mm Turning length 750 mm Center height 185 mm Spindle bore 40 mm Spindle flange KK5 (DIN 55022) Spindle bore MK5 Speed range 20 – 1,600 rpm Digital display Heidenhain VRZ 773 B in 2 axes (Scales on the cross slide and longitudinal slide) Dimensions 1,900 x 900 x 1,700 mm Spindle brake with foot pedal Adjustable stop on the cross slide (feed shut-off) Splash guard Accessories: - Operating manual - Multifix B holder with 2 inserts - Coolant pump integrated in the machine base (no coolant hose connected) Kodpfxsw Svtce Akwjdt - 3-jaw chuck Röhm 200mm with turning and drilling jaws Weight approx. 950 kg Condition: Used The machine runs smoothly and can be inspected while powered on. All information is without guarantee, errors and omissions excepted; all dimensions are approximate. This offer is non-binding. The machine can be inspected by appointment. Changes and errors in the technical data, specifications and prices, as well as prior sale, are reserved! All prices are net plus VAT. Payable by prepayment, including any freight costs, within 14 days after conclusion of the contract. If the purchase price is not paid in full within this period, the seller reserves the right to cancel the purchase contract. The sale is only made to entrepreneurs within the meaning of § 14 BGB. The machine is sold with exclusion of any warranty for defects. This exclusion does not apply to claims for damages arising from warranty for defects, which are based on a gross negligent or intentional breach of obligations by the seller or his agent, as well as in the event of injury to life, body and health. Any existing claims against third parties arising from warranty for defects are assigned to the buyer. Please understand that I cannot assume any liability for compliance with any safety regulations that may apply to you and are generally required for the sold machine and its components. Such compliance with safety regulations is the responsibility of the final operator. German law shall apply exclusively to all contracts concluded by me, to the exclusion of the UN Sales Convention. Mannheim is agreed as the place of jurisdiction.

Condition: new, Precision lead screw and feed screw lathe Manufacturer: GDW Model: LZ 400 V economyline Condition: New machine with stepless speed control to the highest safety standard Centre height: 200 mm Centre distance: 1,000 mm Spindle bore: 62 mm Standard configuration includes: -- 3-axis digital readout, 7" colour display with constant V feature - LED machine light, integrated into machine enclosure - Electromechanical limit switch system for threading and feed operations - Quick-change toolpost size B with turning tool holder - Main drive brake system (spindle brake) - Sliding chuck guard with interlock monitoring - Removable chip guard rear panel - Sliding splash guard - Extendable chip tray - Simple bed stop - Central lubrication system - Set of change gears (number of teeth: 21-33-84-120) - Reducing sleeve for main spindle inner taper ME 70/MK 4 Kedpfjxg Emysx Akwedt - Protective flange for spindle nose DIN 55027-6 - Additional service socket - 2 fixed centres DIN 806-MK 3 - Set of operating tools, keys and oil gun - Spare shear pins - Operating manual with spare parts list and electrical documentation

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, Kunzmann WF4/3 Tool Milling Machine with Heidenhain TNC 320 Contouring Control – Excellent Condition, CE-compliant, from a Training Workshop!! Technical Data: >> Year of manufacture: 2010, Machine No. 347247 >> Fixed angle table >> Infinitely variable spindle speed up to 4,500 rpm >> Infinitely variable feed on 3 axes from 0 to 2,000 mm/min >> Rapid traverse X and Y axis: 5,000 mm/min Z axis: 4,000 mm/min >> Travel X/Y/Z: 400/350/400 mm >> Table surface: 650 x 350 mm >> Table load capacity: 250 kg >> Vertical quill stroke: 60 mm >> Vertical and horizontal quill - SK40 >> Hydraulic tool clamping system >> Weight: approx. 1,800 kg >> Space requirement: approx. 2.3 x 2 x 2 m >> Drive power: 15 KVA Accessories and Features: >> Heidenhain TNC 320 contouring control >> Hydraulic clamping for vertical and horizontal axes >> Automatic central lubrication system >> Spindle brake >> Technical documentation, spare parts diagrams, operating manual for the control, and programming examples >> Handwheels >> Coolant system Kjdpfxoxupc Uj Akwjdt >> Electronic handwheel HR410 About the Machine: Offered here is a Kunzmann WF4/3 tool milling machine equipped with a Heidenhain TNC 320 contouring control. This universal milling machine is in excellent condition, with very few operating hours. Previously used exclusively for training purposes, it features a highly user-friendly control system. The machine offers hydraulic clamping for both vertical and horizontal operation. Conversion from vertical to horizontal milling is extremely easy via the tilting vertical head. Guideways are continuously lubricated via the central lubrication system. The Kunzmann has been mechanically and electrically inspected by us. You are welcome to view and test the Kunzmann machine under power at our facility. A total of 7 Kunzmann WF4/3 milling machines with TNC 320 Heidenhain controls are available. The machines are immediately available.

Condition: as good as new (ex-display), Year of construction: 2025, functionality: fully functional, machine/vehicle number: 2025-09/2404095, turning diameter over cross slide: 224 mm, spindle bore: 51 mm, center height: 180 mm, quill diameter: 32 mm, quill travel distance: 100 mm, total length: 1,680 mm, total height: 1,400 mm, TECHNICAL DATA: Centre distance: 1000 mm Centre height: 180 mm Swing diameter over bed: 360 mm Swing diameter over cross slide: 224 mm Swing diameter without gap bridge: 502 mm Gap bridge length: 235 mm Cross slide travel: 170 mm Top slide travel: 95 mm Max. turning tool cross section: 16x16 mm Chuck mounting: D1 - 4 Spindle mounting (lathe spindle): MT 6 Spindle bore: 51 mm Spindle speed: 70 - 2000 rpm Number of speed ranges: 8 Longitudinal feeds: (32) 0.052 - 0.392 mm/rev Cross feeds: (32) 0.014 - 0.380 mm/rev Metric thread pitch: (26) 0.4 - 7 mm Metric module threads: (26) 0.4 - 7 mm Inch threads, TPI: (34) 4 - 56 TPI Inch module threads, TPI: (34) 4 - 56 TPI Leadscrew pitch: 4 mm Leadscrew diameter: 32 mm Quill mounting: MT 3 Quill diameter: 32 mm Quill travel: 100 mm Motor power: 1500 W Coolant pump: 40 W Electrical connection: 400/50 V/Hz Total length: 1680 mm Total height: 1400 mm Weight: 520 kg Standard accessories: - RÖHM 3-jaw chuck Ø 200 mm - 4-jaw faceplate chuck Ø 200 mm Kdsdpfxoxykafs Akwot - Face plate Ø 320 mm - 2 fixed centre points - Live centre MT 3 - Travelling steady - Fixed steady - Quick-change tool post set ME - Thread dial and change gear set - Halogen machine lamp - Emergency stop button / No-voltage release - Chuck guard with safety switch - Machine base / chip tray / splash guard - Tool kit / operating manual / CE

Condition: used, Year of construction: 2004, turning length 750 mm turning diameter 310 mm turning diameter over slide rest 175 mm spindle bore 32,0 mm tailstock quill taper MT 3 MK turning speeds 85 - 2200 U/min bed width 200 mm total power requirement 2.2 kW weight of the machine ca. 710 kg range L-W-H 1884 x 717 x 1262 mm New price ~ 23.000 euros from a training workshop (!!) Furnishing: - Spindle speed continuously adjustable in 2x switching stages - "TOS" 3-jaw lathe chuck Ø 160 mm, with spare jaws & chuck key - "NEWALL" digital display, front left - MULTIFIX steel holder with inserts - Movable tailstock - live center, incl. quick-action drill chuck - digital speed display - Change gears - Foot/spindle brake * all technical data: - Turning diameter over bed 310 mm - Distance between centers 750 mm - Spindle bore 32 mm - Turning diameter over cross slide 175 mm - bed width 200 mm - Spindle mount / DIN55027 5 - Spindle taper 4.5 M - Spindle speed infinitely variable in switching stages 2 Kjdpjxaa D Tefx Akwsdt - Spindle speed stepless 85-405; 470-2200 rpm - Number of feeds 48 - Metric thread range 0.1 - 28 mm - Thread module range 0.1 - 1.75 - Thread DP range 4 - 70 - Adjustment range cross slide 150 mm - Adjustment range top slide 95 mm - Tailstock quill diameter 40 mm - Tailstock recording 3 MK - Tailstock quill travel 100 mm - Motor power 2.2 kW - Weight 710 kg

Condition: good (used), Year of construction: 2001, feed length X-axis: 600 mm, feed length Y-axis: 400 mm, feed length Z-axis: 400 mm, CNC milling machine KUNZMANN - WF7/3 X-Axis: 600mm Y-Axis: 400mm Z-Axis: 400mm Table Length:650mm Table Width: 400mm Table load: 250 Stroke pinole:40mm Length: 2800mm Width: 2400mm Kodpfx Akswq Ndgjwsdt Height: 2100mm Weight: 2000kg
