Lead/traction spindle lathe

WEILER CONDOR VS2

Condition: excellent (used), spindle bore: 38 mm, turning diameter over bed slide: 340 mm, turning diameter over top slide: 200 mm, turning length: 750 mm, total length: 1,700 mm, total width: 650 mm, total height: 1,500 mm, spindle speed (max.): 2,800 rpm, spindle speed (min.): 12 rpm, overall weight: 800 kg, Equipped with: – Tailstock – Multifix tool holder – RÖHM 3-jaw chuck (Ø 160 mm) Fsdewxq Icepfx Afpjgh

Condition: good (used), WEILER CONDOR VS 2 from university (test laboratory) Fgodpfx Ajxc H Tyofpsh - Guideways "as new" - Centre height: 165 mm - Swing diameter over bed: 330 mm - Distance between centres: 800 mm - Speed range: 28-2800 rpm - Automatic longitudinal / cross feeds - Spindle bore: 40 mm - Threads / Metric / Inch etc. - Collet quick-change system incl. collets - Four-jaw chuck Röhm - Face plate - Four-jaw face plate - Chuck guard - Multifix with inserts - Emergency stop - Documentation Dimensions: LxWxH 2x0.8x1.6 m / Weight 900 kg Subject to errors / input mistakes.

Condition: good (used), 1 used lead and feed screw lathe Make: Weiler Model: Condor VS 2 Technical Data: Centre height: 160 mm Centre distance: 800 mm Spindle bore: 40 mm Fjdpfx Aow Rcrcofpegh Bed width: 240 mm Speeds: 12 - 2800 rpm Drive power: 3 kW Tailstock taper: MK 3 Quill stroke: 110 mm Feeds: 0.037 - 1.253 mm/rev Weight, approx.: 800 kg Dimensions (W x D x H), approx.: 1930 x 880 x 1470 mm Equipment: 3-jaw chuck Quick-change toolholder system Multifix

Condition: ready for operation (used), Center height: 165mm, center width: 800mm, turning diameter over bed/face slide: 330mm/185mm, spindle bore: 40mm, speed: 2800rpm, machine dimensions X/Y/Z: approx. 2000mm/1000mm/1700mm, weight: approx. 900kg. On-site inspection is possible. Fsdpfx Ajwq R N Dofpsgh

Condition: used, Year of construction: 1980, Weiler Condor VS2 lathe with 3-axis Heidenhain digital display, built in 1980, four-jaw chuck, Multifix with 3 holders. Machine in very good, operational condition, comes from a training workshop. Ready to demonstrate with power on by arrangement. Fgedpfx Aovx Sw Hsfpeh

Condition: good (used), Weiler Condor VS 2 center lathe and feed spindle lathe Technical data: Center height 160 mm Center width 800 mm Spindle bore 40 mm Bed width 240 mm Speeds 12 - 2800 min-1 Drive power 3 kW Tailstock holder MK 3 Quill stroke 110 mm Feed rates 0.037 - 1.253 mm/rev Weight, approx. 800 kg Dimensions (WxDxH), approx. 1930 x 880 x 1470 mm Equipment: 3-jaw lathe chuck Quick-change holder system Multifix size A incl. 1 change holder Fsdpfxeu E H Iwj Afpjgh Electrically locked chuck guard Brake motor retrofitted Bed stop Emergency stop button Coolant device Machine light Chip back panel ELESTA 3-axis digital display Moving tip The machine has been technically inspected and is in very good condition. Backlash face spindle 0.2mm Top slide backlash 0.15mm Inspection under power possible at any time. Price net free loading ex warehouse

Condition: good (used), functionality: unexamined, machine/vehicle number: 10279, turning diameter over cross slide: 200 mm, spindle bore: 35 mm, turning diameter: 300 mm, center height: 150 mm, turning length: 750 mm, total length: 1,860 mm, total width: 700 mm, total height: 1,800 mm, spindle speed (max.): 2,800 rpm, spindle speed (min.): 40 rpm, overall weight: 1,030 kg, - Operating voltage: 380 V Fgedpfxjv Irgto Afpeh - Connected load: 3 kW - Nominal current: 25 A - Frequency: 50 Hz Equipment: - Tailstock - Multifix type B tool holder - Three-jaw chuck (diameter: 160 mm) - 2-axis digital display from the manufacturer RSF
