Eccentric press

Weingarten ARP 200

Year of construction: 1965, condition: used, pressure 150 t throat 550 mm stroke 10 - 140 mm table surface area 1180 x 980 mm no. of strokes 40 Hub/min dayligth 500 mm ram surface 1040 x 800 mm ram adjustment 70 - 150 mm tool shank hole (depth x diameter) 435 x 55 mm required power 15 kW weight of the machine ca. 12 t dimensions of the machine ca. 3 x 1,7 x 3 m - with additional brake - slide weight compensation - motorized slide adjustment - central grease lubrication (manual) - table mounting plate - safe for manual inlay work Dkjdpfxscubato Ah Ssg

Condition: used, Year of construction: 1977, pressure 250 t stroke 40 - 190 mm no. of strokes 40 /min throat 500 mm passage to the back 1050 mm dayligth 615 mm table surface area 1380 x 880 mm hole in the table 450 mm table height over floor 800 mm ram surface 1200 x 800 mm ram adjustment 125 mm power requirement 22,0 kW Dsdpfxovuuais Ah Sokg Weight 24,0 t dimensions of the machine ca. 2,0 x 2,5 x 3,95 m x m x m permitted for manual loading according to the German Safety Regulations (UVV) with motor, pneumatic clutch/brake combination, hydraulic overload protection in ram, pneumatic counterbalance in ram, motoric ram adjustment, manual stroke adjustment, motoric centralized lubrication, bolster plate, two-hand operation

Condition: ready for operation (used), Year of construction: 1980, Power: 300 to Size of bolster: 1.200 x 850 mm Dedpfx Asd A Hbcjh Sskg Overhang: 400 mm Width of ram: 1.100 mm Opening in bolster: 400 x 250 mm Daylight: 500 mm Frequency: 32 1/min Stroke: 30 - 140 mm Ram adjustment: 105 mm Weight: app. 19.500kg Other - allowed for 2-Hand safe working - euqipped by safety valve Herion Xsz 20 - Motorized grease lubrication - Pneumatic ram balancing cylinders - Motorized ram adjustment - T-slots in ram - Stand alone control panel - bearing of con rod overhault

Condition: used, Year of construction: 1989, pressure 250 t Dkedpfx Asvut Ncsh Seg stroke 20 - 190 mm no. of strokes 24 / 48 /min throat 500 mm passage to the back 1000 mm dayligth 615 mm table surface area 1400 x 880 mm hole in the table 450/500 mm table height over floor 800 mm ram surface 1380 x 620 mm ram adjustment 125 mm power requirement 29,0 kW Weight 27,0 t dimensions of the machine ca. 2,0 x 2,6 x 4,1 m x m x m permitted for manual loading according to the German Safety Regulations (UVV) with motor with 2 speeds, pneumatic clutch/brake combination, hydraulic overload protection in ram, pneumatic counterbalance in ram, motoric ram adjustment, semi-automatic stroke adjustment, motoric centralized lubrication, two-hand operation can be inspected in running function in our warehouse

Condition: new, Year of construction: 2025, functionality: fully functional, machine/vehicle number: 25.12.15, Fresan FP 15P - C Frame Eccentric Press - 15 Tons (150kN) TECHNICAL DATA: * Power: 15 tons (150kN) Djdonvfv Njpfx Ah Sokg * Strokes Per minute: 200 * Ram-Table Distance: 215 mm * Stroke Adjustment: 0 - 40 mm * Ram Adjustment: 40 mm * Table Dimensions: 320 x 490 mm STANDARD SPECIFICATIONS: * Conformity to CE safety regulations * Welded steel frame * Crankshaft made of AISI 4140 (42CrMo4) alloy steel. Highly durable and ductile. CNC ground for minimum surface friction. * SnBz-12 quality bronze bearings * Pneumatic clutch-brake combination * Double body press safety valve * Safety PLC control (Pilz) * Covers with safety switches * Light curtains around work table * Ram with 4 sliding surfaces * Mechanical fuse for overload protection (Starting from 20 tons) * Pneumatic counterbalance cylinders (Starting from 40 tons) * Central lubrication & used oil collectors (Thin oil / slideways oil) OPTIONAL EQUIPMENT: * Additional work table * Automatic central lubrication * Speed control with AC inverter * HMI / Touchscreen operator panel * Part ejector mechanisms(upper and/or lower ejectors) * Material feeding, loading & unloading systems (Decoilers, straighteners, pneumatic & servo feeders...) * Special design / customized machine

Year of construction: 1981, condition: ready for operation (used), There are two identical eccentric presses available, nominal force: 1000kN, stroke speed: 30-85/min, stroke adjustment: 20-125mm, weight: 8t, year of construction machine 1/ 2: 1978/ 1981, with documentation. Dksdpfx Ahelc N Rvs Sog
