Workshop-overhauled single-column eccentric press, eccentric stamping press

WEINGARTEN AV 40

Workshop-refurbished Single-column Eccentric Press WEINGARTEN Type AV 40
Machine No. 121826 D Year of manufacture 1976 - Completely overhauled in 2003
Pressing force 40 tons
Throat depth 225 mm
Table opening Ø 195 mm
Table size 560 x 470 mm
Ram size 260 x 200 mm
Adjustable ram stroke 8-88 mm
Ram adjustment 63 mm
Installation height max. 500 mm
Clamping shank bore Ø 40 mm
Stroke rate 40-120 strokes / min. (infinitely variable)
Motor power 4 kW
Electrical connection 400 Volt, 50 Hz
Table height above floor 800 mm
- Infinitely variable stroke speed via electric PIV gear unit
- Table height adjustment with 2 support spindles
- Knockout hole in table as round table opening with reducing ring
- Clutch-brake combination by WEINGARTEN friction screw clutch with TDC overrun protection
- Stroke actuation via electric foot switch or two-hand control desk
- Front crankshaft support bearing
- Overload protection by shear plate
Cedpoxlkq Ijfx Abwehc
- Manual central lubrication
- Electrical cabinet with dual-contactor control from 2003, fixed to the machine
- Workplace safety (UVV) for manual loading operations
The machine is equipped with the following operating modes:
- Setup
- Single stroke two-hand control
- Single stroke foot pedal
- Continuous operation foot pedal
- Automatic continuous run
- External engagement
Footprint L x W x H 1900 x 950 x 2600 mm
Weight 3.1 tons
Very good condition
