Planer and moulder

Weinig Hydromat 22BL hartverchromte Tischplatte

Condition: excellent (used), WEINIG Hydromat H23 Line, S/N 87321, year 1999, Ref-No. 103437 WEINIG Cross Conveyor HighMech E-1, equipped with 6 flat chains approx. 2000 x 3500 mm Hydraulic WEINIG Accelerator Model 814 Short infeed table with heavy-duty 4-roller feed unit Planer/moulder with reinforced KASCHWIG three-sided soundproof enclosure • Max. working width: 230 mm • Max. working height: 160 mm • Electronic feed, frequency-controlled, 8–80 m/min • Feed motor 18.5 kW • 1st spindle bottom 11.0 kW • 2nd spindle right 11.0 kW • 3rd spindle left 11.0 kW • 4th spindle right 11.0 kW • 5th spindle left 11.0 kW • 6th spindle top 15.0 kW • 7th spindle bottom 11.0 kW • 8th spindle top 15.0 kW • 9th spindle bottom 15.0 kW • 10th universal spindle 11.0 kW (four-sided) • Spindle speed 6,000 rpm • Spindle diameter ø 50 mm • All spindle motors equipped with NEW motor start/stop brake units • Pneumatically supported top pressure rollers • Feed rollers D=140 mm • 6 driven rollers in the table • Spindles 1 + 6 + 7 + 8 + 9 with counter bearings • Spindles 8 + 9 with straight jointer • Spindles 8 + 9 with profile jointer • Spindles 6 + 8 with pneumatic pressure • Reduced spacing between feed rollers • Hard-chromed table plates • Hard-chromed fences • Pneumatically supported side pressure rollers • Automatic table lubrication • Centralized lubrication points • Free-standing control panel • Connected load approx. 145 kW / approx. 400 A • Free-standing electrical cabinet • Operating instructions, spare parts list and wiring diagram included • Machine sold without cutterheads Machine dimensions approx.: • Length: 6,000 mm • Width: 2,250 mm • Height: 1,800 mm • Weight: approx. 8,500 kg Factory-new WEINIG components installed: NEW horizontal/vertical spindle NEW counter bearings All spindles with HL bearings All motors newly fitted NEW electronic motor soft start/brake devices NEW hard-chromed table plates NEW hard-chromed fences Many other new parts fitted in the machine Condition: see attached photos – technically in excellent condition Kjdpfx Anowvqkljwedn Infeed mechanization unrefurbished – complete – fully functional Payment: Net cash before loading Delivery time: By arrangement Delivery: EXW Inspection: Anytime by appointment Errors and prior sale excepted.

Condition: excellent (used), Four-side planer Weinig Hydromat 23C Working width: 230 mm Working height: 160 mm Number of spindles: 7 Spindle arrangement: 1. Bottom 15 kW 2. Right 7.5 kW 3. Left 7.5 kW 4. Top 15 kW 5. Bottom 30 kW (multi-blade saw) 6. Bottom 7.5 kW (hydro support) 7. Top 7.5 kW (hydro support) Spindle speed: 6000 rpm Spindle diameter: 50 mm Kodpoxlcufjfx Anwsdn 4 feed rollers in the worktable Feed speed adjustable via frequency inverter up to 36 m/min Feed drive powered by cardan shaft Pneumatic pressure elements Technical documentation

Condition: good (used), Year of construction: 1989, functionality: unexamined, working width: 220 mm, planing height: 120 mm, spindle diameter: 50 mm, planing width: 220 mm, working height: 120 mm, overall weight: 7,500 kg, spindle speed (max.): 6,000 rpm, spindle speed (min.): 6,000 rpm, height adjustment type: electric, type of input current: three-phase, number of spindles: 10, power: 105 kW (142.76 HP), input frequency: 50 Hz, Equipment: cabin, motor brake, Weinig Hydromat 22 B With grooved bed Kdedpfx Anju Udd Sewon 10 spindles, Working width: 220 mm, working height: 120 mm, spindle diameter: 50 mm, Feed rate: 7.5 kW / 8- 40 m/min, Spindle arrangement: 1-bottom (7.5 kW) - with hydraulic clamping 2- Right (7.5 kW) 3-Left (11 kW) 4-Right (7.5 kW)- with straight jointer 5-Left (7.5 kW) 6-Top (15 kW) - with hydraulic clamping 7-Bottom (7.5 kW) - with hydraulic clamping 8-Top (7.5 kW) - with hydraulic clamping and straight jointer 9-bottom (7.5 kW) - with hydraulic clamping and straight jointer 10-Uni (7.5) 6 driven rollers in the table

Condition: good (used), Weinig Hydromat H23 8 spindle 50mm spindles 6,000 RPM Bottom 7.5kW jointer ready Right 7.5kW straight jointer ready Left 15kW straight and profile jointer ready Right 11kW profile jointer ready Top 15kW jointer ready Bottom 18.5kw jointer ready Top 11kw straight and profile jointer ready + outboard bearing Bottom 7.5 kw straight and profile jointer ready + outboard bearing 7.5kW feed motor. Automatic lubrication system. Full heavy duty sound enclosure Kodpfxexgq Rwo Anwjdn Possible to supply with moulder infeed and outfeed as needed. Possible to offer tooling if needed.

Condition: good (used), Year of construction: 1989, Serial No : 220-1198 Consist of : Weinig cross infeed, max lenght : 2200mm Weinig 22B 8 spindle moulder Max working width : 220 x 140mm Spindle diameter : 50mm Infeed engine : 7,5 Kw Spindle configuration : 1. Under11 Kw 2. Right 11 3. Left 11 4. Right 7,5 5. Left 7,5 Kdedpsxbn Rqofx Anwjn 6. Top 18,5 7. Under 11 8. Top 11 Cross outfeed, max lenght : 2200mm Lots of heads/tools included

Condition: excellent (used), functionality: fully functional, Working width: 230 mm Working height: 160 mm Number of spindles: 5 Spindle configuration: 1. Bottom 15 kW 2. Right 11 kW 3. Left 11 kW 4. Top 15 kW 5. Bottom 7.5 kW Spindle speed: 6000 rpm Kedpfxjx Hzv Ts Anwsdn Spindle diameter: 50 mm 3 feed rollers in the work table Feed speed adjustable via inverter up to 60 m/min Feed driven by cardan shaft Pneumatic pressure rollers Technical documentation Machine dimensions: 300x180x170 cm (H) Weight: 3500 kg
