Moulder

Weinig Hydromat 23C (6 spindle)

Condition: excellent (used), Year of construction: 2003, Weinig Hydromat 23C with 6 Spindles. Separate electrical panel. Automatic lubrication system for bedplates Maximum dimensions 140mm x 230mm Bwsdpfxsyl Rmwe Ah Ioi No 1.  11kw - Bottom 6000rpm + Outboard bearing - straight jointer prepared No 2. 11kw - Right 6000rpm - straight and profile jointer prepared No 3. 11kw - Left 6000rpm - straight and profile jointer prepared No 4 . 15kw - Top 6000rpm + Outboard bearing - jointer prepared No 5 . 11kw - Top 6000rpm + Outboard bearing - straight jointer No 6 . 18.5kw - Bottom 6000rpm + Outboard bearing - straight jointer 7.5 kw feed. 6-60m/min (Possible to increase speed as needed). 50mm spindles Beam 0.55kW Full documentation included. Possible to supply with hydro tooling if needed. Possible to supply with infeed and outfeed if needed.

Condition: good (used), Year of construction: 1989, functionality: unexamined, working width: 220 mm, planing height: 120 mm, spindle diameter: 50 mm, planing width: 220 mm, working height: 120 mm, overall weight: 7,500 kg, spindle speed (max.): 6,000 rpm, spindle speed (min.): 6,000 rpm, height adjustment type: electric, type of input current: three-phase, number of spindles: 10, power: 105 kW (142.76 HP), input frequency: 50 Hz, Equipment: cabin, motor brake, Weinig Hydromat 22 B With grooved bed Bwjdou Udd Sjpfx Ah Isi 10 spindles, Working width: 220 mm, working height: 120 mm, spindle diameter: 50 mm, Feed rate: 7.5 kW / 8- 40 m/min, Spindle arrangement: 1-bottom (7.5 kW) - with hydraulic clamping 2- Right (7.5 kW) 3-Left (11 kW) 4-Right (7.5 kW)- with straight jointer 5-Left (7.5 kW) 6-Top (15 kW) - with hydraulic clamping 7-Bottom (7.5 kW) - with hydraulic clamping 8-Top (7.5 kW) - with hydraulic clamping and straight jointer 9-bottom (7.5 kW) - with hydraulic clamping and straight jointer 10-Uni (7.5) 6 driven rollers in the table

Condition: excellent (used), Year of construction: 2003, Weinig Hydromat 23C with 6 Spindles. Separate electrical panel. Automatic lubrication system for bedplates Maximum dimensions 140mm x 230mm No 1.  11kw - Bottom 6000rpm + Outboard bearing - straight jointer prepared No 2. 11kw - Right 6000rpm - straight and profile jointer prepared No 3. 11kw - Left 6000rpm - straight and profile jointer prepared No 4 . 15kw - Top 6000rpm + Outboard bearing - jointer prepared No 5 . 11kw - Top 6000rpm + Outboard bearing - straight jointer No 6 . 18.5kw - Bottom 6000rpm + Outboard bearing - straight jointer 7.5 kw feed. 6-60m/min (Possible to increase speed as needed). 50mm spindles Beam 0.55kW Full documentation included. Possible to supply with hydro tooling if needed. Bsdpfxeycvd Ao Ah Iewi Possible to supply with infeed and outfeed if needed.

Condition: excellent (used), Four-side planer Weinig Hydromat 23C Bwedpfx Ahsxlcufj Isi Working width: 230 mm Working height: 160 mm Number of spindles: 7 Spindle arrangement: 1. Bottom 15 kW 2. Right 7.5 kW 3. Left 7.5 kW 4. Top 15 kW 5. Bottom 30 kW (multi-blade saw) 6. Bottom 7.5 kW (hydro support) 7. Top 7.5 kW (hydro support) Spindle speed: 6000 rpm Spindle diameter: 50 mm 4 feed rollers in the worktable Feed speed adjustable via frequency inverter up to 36 m/min Feed drive powered by cardan shaft Pneumatic pressure elements Technical documentation

Condition: good (used), Weinig Hydromat H23 8 spindle 50mm spindles 6,000 RPM Bottom 7.5kW jointer ready Right 7.5kW straight jointer ready Left 15kW straight and profile jointer ready Right 11kW profile jointer ready Top 15kW jointer ready Bottom 18.5kw jointer ready Bwodpfoxgq Rwex Ah Iei Top 11kw straight and profile jointer ready + outboard bearing Bottom 7.5 kw straight and profile jointer ready + outboard bearing 7.5kW feed motor. Automatic lubrication system. Full heavy duty sound enclosure Possible to supply with moulder infeed and outfeed as needed. Possible to offer tooling if needed.

Condition: ready for operation (used), Year of construction: 1983, functionality: fully functional, working width: 220 mm, planing height: 140 mm, spindle diameter: 50 mm, planing width: 220 mm, working height: 140 mm, power of feed motor: 15,000 W, spindle speed (max.): 6,000 rpm, spindle speed (min.): 6,000 rpm, height adjustment type: electric, type of input current: three-phase, number of spindles: 7, input frequency: 50 Hz, Weinig Hydromat 22 BL 7 spindles, Working width: 220 mm, working height: 140 mm, spindle diameter: 50 mm, feed: 15 kW / 6 - 60 m/min, Beesjj3Vck9 Spindle arrangement: 1-bottom (7.5 kW) with hydraulic clamping Bwjdpfx Asulnr Ajh Iji 2- Right (11 kW) 3-Left (11 kW) 4-Top (11 kW) 5-bottom (7.5 kW)-with hydraulic clamping, straight jointer and profile jointer 6-Top (11 kW) with hydraulic clamping, straight jointer 7-bottom (11 kW) - with hydraulic clamping, straight jointer and profile jointer 6 driven rollers in the table

Condition: excellent (used), Weinig Hydromat 23C with 6 Spindles. Max width 245mm Max Thickness 160mm Separate electrical panel. Separate remote control panel Automatic lubrication system for bedplates Full heavy duty sound enclosure. 15kW feed motor 100m/min No 1.  7.5kw - Bottom 6000rpm straight jointer prepared No 2. 11kw - Right 6000rpm straight and profile jointer prepared No 3. 15kw - Left 6000rpm straight and profile jointer prepared No 4 . 15kw - Top 6000rpm + Outboard bearing + straight and profile jointer prepared No 5 . 30kw - Top 6000rpm + Outboard bearing + straight and profile jointer prepared No 6 . 15kw - Bottom 6000rpm + Outboard bearing + straight and profile jointer prepared 50mm spindles Beam 0.55kW Full documentation included. Heavy duty sound enclosure. Possible to supply with hydro tooling if needed. Bwsdpfx Ahsx Dq Rfo Isi Possible to supply with full mechanisation if needed.

Condition: good (used), Year of construction: 1989, Serial No : 220-1198 Consist of : Weinig cross infeed, max lenght : 2200mm Weinig 22B 8 spindle moulder Max working width : 220 x 140mm Bodpexbn Rqsfx Ah Iswi Spindle diameter : 50mm Infeed engine : 7,5 Kw Spindle configuration : 1. Under11 Kw 2. Right 11 3. Left 11 4. Right 7,5 5. Left 7,5 6. Top 18,5 7. Under 11 8. Top 11 Cross outfeed, max lenght : 2200mm Lots of heads/tools included
