Spare Parts WEINIG

WEINIG

Condition: good (used), WEINIG HYDROMAT H-23 10 SPINDLE MACHINE WITH TILT BEAM SHORT INFEED TABLE 1: BOTTOM 7,5KW 2: RIGHT 11 KW 3: LEFT 11 KW 4: RIGHT 11 KW 30° TILTABLE 5: LEFT 11 KW 6: TOP 11 KW Hfodpfx Ajycvfmsc Neh 7: BOTTOM 11 KW 8: TOP 11 KW 9: BOTTOM 11 KW 10: UNIVERSAL 11 KW 360° TILTABLE 80 M/MIN+ ELECTRIC. FEED 14 x DRIVEN TOP FEED ROLLERS 7 x DRIVEN BED FEED ROLLERS AUTOM. BED LUBRICATION PNEUM. POWERED SIDE PRESSURE ROLLERS PNEUM. POWERED HOLD DOWN ON 7+9 DIMENSION: APPR 5400 X 2000 X 1800 MM WEIGHT: APPR. 7500 KGS DUSTHOODS: 10 x 140 MM DIAMETER SOUND ENCLOSURE ROOM INCLUDED

Condition: ready for operation (used), Year of construction: 2005, chain width 340mm max cutting height 120mm variable adjustment of feeder 5-35m/min Hodpfxsw A H Dno Ac Nefh 2 lasers year 2005 motor power 37kW weight 2200kg

Condition: excellent (used), Set of 2x Weinig Powerlock L=310 Z=2 heads 8000 rpm Hjdpfxszdq H Te Ac Njfh Alu Lightweight Diameter 125 mm 1x bottom + 1x top Weinig 10025811 (20 05 071) Weinig 10025812 (20 05 070) Centrolock reversible knife system Z2 Mounting: PowerLock HSK

Condition: used, Weinig Powerlock L=240 Z=2 head with rebate cutter below Type 536, diameter 93 mm 536.095.04 Centrolock reversible knife system Z2 Mounting: PowerLock HSK Length: 240 mm Hedpjzdq Htofx Ac Nefh Price: 425 Euro

Condition: reconditioned (used), 1 x Elektronic Motor Braking Unit EMG15 Power range 3 - 15KW Voltage range 200-575V Power frequency 50Hz/60Hz Siemens EMG 15 Motor brake for Weinig machine Unimat and Hydromat series Working tested on Weinig machine Hedpfx Acozdpc To Njfh

Condition: used, Year of construction: 1980, used, in top condition Hjdpfxoxuv Nuo Ac Nofh Make: Raimann Model: K 23 Year of manufacture: 1980 Chain width: 250 mm Cutting width: approx. 230 mm Cutting height: approx. 120 mm without pressure bar / with pressure bar 110 mm Feed speed max. 8 - 35 m/min steplessly adjustable Saw blade diameter: 360 mm x 80 – bushing Shaft diameter: 65 mm Minimum workpiece length: 290/750 mm Extraction connection D 200 mm Space requirement: approx. 2400 mm x 1500 mm x 1600 mm Weight: approx. 2100 kg Total connected load: approx. 75 A Location: 97447 Gerolzhofen, free loaded, unpacked Handed over in as-is condition, as inspected No guarantee or warranty

Condition: not inspected (used), Year of construction: 1999, Tenoning spindle 1 St. Number of milling agregates 4 St. Spindle diameter 50 mm Control Weinig PC-Nexus # 7015 Weinig Unicontrol 6 with NC spindles ----- Machine available for inspection while still in operation until September 2026 Summary of technical data (please inquire about any additional accessories included) Item 1: Cross-cut saw ----- > Electronic cross-cut saw, horizontally continuously adjustable > Number of tools: 1 unit > Spindle speed: 2,800 rpm > Spindle diameter: 40 mm > Max. tool diameter: 400 mm > Motor power: 3.0 kW > Laser alignment light for identifying the cut position > NC length stop mounted on the slotting table included; positioning of the cross-cut saw integrated into the control system. > Length 3500 mm Item 2: Tenoning and slotting spindle ----- > Number of tools: variable, infinitely adjustable via NC axis > Tool clamping length: 320 mm > Vertical spindle stroke: variable, infinitely adjustable 254 mm via NC axis > Spindle speed: 3500 rpm > Spindle diameter: 50 mm > Max. tool diameter: 320 mm > Motor power: 11 kW Item 3: 1st profiling spindle (climb-cut and conventional-cut capable) ----- > Position: vertical right > Number of tools: 1 pc. > Tool clamping length: 120 mm > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Max. tool cutting circle: 232 mm > Motor power: 7.5 kW Item 4: 2nd profiling spindle ----- > Position: vertical right > Number of tools: variable, infinitely adjustable via NC axis > Tool clamping length: 320 mm > Vertical spindle stroke: variable, infinitely adjustable 254 mm via NC axis > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Max. tool cutting circle: 232 mm > Motor power: 11 kW Item 5: Horizontal profile milling unit (top) ----- > Clamping length: 40 mm > Spindle diameter: 40 mm > Motor power: 3.0 kW > Speed: 5,850 rpm > Max. tool cutting circle: 130 mm > Axial adjustment range: 2 positions > Radial adjustment range: 2 positions Item 6: 3. Profiling spindle (hardware groove spindle) ----- > Position: vertical, right > Tool clamping length: 160 mm > Axial adjustment range: 3 positions > Radial adjustment range: 2 positions > Spindle speed: 5,850 rpm > Spindle diameter: 40 mm > Max. tool cutting circle: 210 mm > Motor power: 3.0 kW Additional features ----- > Network-ready (online capability) > Rebating unit for tear-free rebating > Double-part processing package > Return conveyor system for one-man operation: slat conveyor > Screen-based control system > Angled window processing unit > Electronic angle display for angled windows > Industrial PC, PC control/NEXUS > Excluding machining tools ----- Price of the above-mentioned machine available on request! ----- Optional extra: EUR 6,500.00 Note regarding used tools: We currently have used "Gold" series tools in stock (Stock No. #2790) Window tools (Gold series) for IV78 Wood and IV78 Wood/Aluminum Previously used on a Weinig Unicontrol 10; a jointing cutter is additionally Hsdpfszdk Hysx Ac Njfh required for use on a Unicontrol 6. Tool set for fixed-stroke or CNC spindle machines (80 mm and 95 mm stroke), (Tool set prepared for IV92 where technically feasible) Wood-aluminum tool set ...

Condition: used, functionality: fully functional, Maximum planing width: 230 mm Maximum planing height: 120 mm Number of spindles: 6 Maximum spindle speed: 6,000 rpm Feed table length approx. 2,000 mm Spindle diameter: 40 mm Hjdpezdk Dfjfx Ac Nsfh Motorized adjustment of planing width and height Maximum feed rate: 24 m/min Emergency stop Dimensions approx. (LxWxH): 4,100 x 1,500 x 1,600 mm Weight approx.: 2,800 kg

Condition: good (used), functionality: fully functional, working width: 255 mm, planing height: 160 mm, spindle diameter: 40 mm, planing width: 255 mm, working height: 160 mm, power of feed motor: 3,000 W, spindle speed (max.): 6,000 rpm, spindle speed (min.): 6,000 rpm, height adjustment type: electric, planer shaft diameter: 40 mm, type of input current: three-phase, number of spindles: 5, input frequency: 50 Hz, Equipment: cabin, motor brake, Weinig Unimat 23 E with 5 spindles, Working width: 255 mm, Working height: 160 mm, Spindle diameter: 40 mm, Feed: 3 kW / 6 – 36 m/min, Spindle arrangement: 1-Bottom (5.5 kW) 2-Right (5.5 kW) 3-Left (7.5 kW) 4-Top (5.5 kW) 5-Bottom (4.0 kW) One driven roller at the outfeed table. Hfedpfx Acoxg Sa Ho Nsh

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, Unicontrol 12 Consisting of: Cut-off unit (item A), Tenon and slotted spindle (item C), Transfer belt (Pos. I), profiling spindle (Pos L), profiling spindle (Pos. N), Profile shaving unit vertical right (Pos. P) For the production of individual parts and elements in frame-by-frame or serial production. Consisting of a cross processing unit and a longitudinal processing unit connected to a transfer belt. Working width 40-140mm (See pressure ruler left 40 - 140 mm) Working height 40-120mm Workpiece length min. approx. 275 mm + 1 x end profile length Long machining: approx. 220 mm + 2 x end profile length Workpiece length max. 3500 mm The part dimensions depend on the machine equipment, production type and tool assignment. A final definition of the part dimensions is only possible after receipt, inspection and approval of the complete and final layout drawings. Cross machining: Table feed Motor power 0.3 kW (0.4 HP) Pre-set feed speed for cutting, profiling and return 3-25 m/min Hodpfxsumci Ss Ac Nsfh Vario table with (studio window production possible) The clamping length of all tenoning and slotting spindles can be used without a tool blank. Workpiece clamping by means of a clamping bridge. Operated by a clamping cylinder installed under the table. NC-controlled long fence mounted on the slotting table. Studio window device Swivel angle max. +/- 75° The minimum workpiece length for slanted windows depends on the angle and the width of the wood. Possible part dimensions for slanted window production Angle Max. Min. Working width Workpiece length +/-75° 80 mm 800 mm +/-70° 120 mm 490 mm +/-60° 240 mm 360 mm +/-90° 350 mm 185 mm For angles greater than 60° only counter processing Commission not documented 1)NC automatic angle adjustment for machining angled parts Splinter protection by means of overtravel counter Over the entire spindle length of the tenoning and slotting spindle for 90° machining Manually trackable counter-rail for angled part machining 2) Additional counter-rails
