Centerless grinder SASL 200x300

WMW Mikrosa SASL 125 1A, 200x300, 125x250, KCH 63

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, CNC Fanuc Series Max. turning diameter on the machine bed: 780 mm Max. turning diameter on the carriage: 630 mm Max. turning diameter: 406 mm Max. turning length: 520 mm Bar passage: 65 mm Spindle nose: ASA A2-6 Spindle bore: 52 mm Spindle speed: 5000 rpm Spindle motor power: 18.5 kW Tailstock bore: 45 mm Tailstock nose: ASA A2-5 Bellegrandi tool holders on the spindle and tailstock + 2 self-centering chucks X-axis travel: 260 mm Z-axis travel: 590 mm Y-axis travel: +102 - 51 mm Bwodpfxeyiu Dno Aqwst B-axis travel: 590 mm Rapid traverse rate for X/Z/B axes: 30 m/min Rapid traverse rate for Y-axis: 10 m/min Turret type: BMT Number of turret stations: 12 Rotation speed of powered tools: 5000 rpm Dimensions: 3530x1863 mm, H=2163 mm Weight: 5900 kg No. 10 tool holders for powered tools.

Condition: good (used), Manufacturer: WMW Zeulenroda Type: PYE 160 SS Year of manufacture: 1980 C-frame construction Die height 850 mm Thickness bolster plate 100 mm Throat C side 360 mm Specifications Metric US Standard Capacity 160,000 Bjdpfxjwp Nv Hs Aqwowt Table length 1,250 mm Table width 600 mm Ram stroke 500 mm Starting speed 100 mm/min Working speed 10 mm/min Return speed 125 mm/min Power 22.5 kW Dimensions (Estimate) Length: 2,150 mm Width: 1,250 mm Height: 3,600 mm Weight: 7,500 kg Please note: The information on this page has been provided to the best of our knowledge and, where possible, from the manufacturer. The information is given in good faith, but accuracy cannot be guaranteed. Accordingly, they do not represent a warranty or contract terms. We recommend you check all important details.

Condition: excellent (used), Year of construction: 1983, Faceplate diameter: 1250 mm Max. swing diameter: 1400 mm Max. swing height: 1160 mm Max. ram stroke, vertical / horizontal: 755 / 840 mm Table load capacity: unlimited Faceplate speed range: 5.6 - 300 rpm Vertical slide angular adjustment: 45° Feed rate range: 0.044-8 mm/rev Rapid traverse rate: 2 m/min Drive power: 55 kW Footprint L x W x H: 2660 x 2710 x 3360 mm Total weight: 16,500 kg Accessories / Special features: • 2-axis digital display, manufacturer: ACU-Rite • Faceplate, Ø 1250 mm, with 4 chuck jaws Bwsdjy Ex Epspfx Aqwet • 5-position turret • Taper turning • Profile turning Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel / Germany

Condition: ready for operation (used), Year of construction: 1989, total width: 4,000 mm, overall weight: 5,000 kg, workpiece diameter (max.): 140 mm, product length (max.): 2,000 mm, number of axes: 2, This Schaudt Mikrosa SASL 125 was manufactured in 1989. A centerless external grinding machine, it features NC-controlled operations and hydrodynamic axis bearing. Both wheels can be dressed via a controlled axis. Refurbished by UHLMAN Werkzeugmaschinen-Service in 2021/22, it has been regularly maintained. Consider the opportunity to buy this Schaudt Mikrosa SASL 125 centerless grinding machine. Contact us for more information. Working range: • Maximum workpiece diameter • that can be ground • with a grinding wheel Ø 500 mm: 140 mm • Maximum workpiece diameter • that can be ground • with a grinding wheel Ø 630 mm: 80 mm • Minimum workpiece diameter that can be ground: 3.5 mm • Maximum workpiece length for through-feed grinding: 200 mm • Maximum workpiece length in plunge grinding 245 mm • Maximum grindable profile depth on the workpiece 25 mm Grinding wheel: • Maximum outer diameter 500 or 630 mm • Minimum outer diameter 380 mm • Maximum grinding wheel width 250 mm • Grinding wheel bore 305 mm • Guide wheel: • Maximum guide wheel outer diameter 315 mm • Maximum guide wheel width 250 mm Bwjdsx Enapjpfx Aqwjt • Bore diameter 127 mm Power requirements: • Power consumption approx. 33 kW Additional equipment • Optional: Additional equipment available Machine Benefits Technical Machine Benefits • Hydrodynamic axis bearing • Regular maintenance during series production • Retroffited by Uhlman Werkzeugmaschinen-Service in 2021/22

Condition: used, turning diameter 1.600 mm Bwsdpsvp Shgsfx Aqwst max. swing diameter 1.700 mm control Siemens - 840D faceplate turning speed range 1 - 320 U/min rapid traverse 3.000 mm / min feed range 1 - 3.000 mm/min size of pallet 1.168 mm numbers of pallets 2 main drive 55 kW Vertical turret lathe with cnc | SCHIESS MOWEG - BERTHIEZ TFM 125 has been overhauled by SCHIESS MOWEG (RETROFIT) in 2007. The machine video from the production plant will be shared on request. The machine is in very good condition and was in operation at an aviation company until recently. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: TFM125 | TFM-125

Condition: excellent (used), functionality: fully functional, machine/vehicle number: 11903, grinding length: 5,200 mm, grinding wheel diameter: 660 mm, grinding diameter: 1,600 mm, grinding wheel width: 50 mm, spindle speed (max.): 30 rpm, spindle speed (min.): 5 rpm, Churchill Roll Grinder Swing 1600 mm Centres 5200 mm Cambering Wheel Size 26” x 2” Roll speeds 5-30 rpm Bodpfxsxvrptj Aqwewt Bed and table were re-ground and not much use since so both are perfect.

Condition: used, Year of construction: 1973, functionality: unexamined, Vertical Turret Lathe - Double Column | Brand: TITAN | Type: SC 2500 Year of manufacture: 1973; modernization in 2011 to Siemens SINUMERIK 840D sl control system The machine is a ‘TITAN’ model, i.e. from a Romanian manufacturer. However, the design is licensed from SCHIESS in Düsseldorf and is therefore comparable to the well-known SCHIESS machines from that period. The machine was professionally disassembled by technicians from the machine manufacturer SCHIESS, properly preserved and placed in storage by the owner. TECHNICAL SPECIFICATIONS / EQUIPMENT: - Faceplate diameter: 2.500 mm - Swing diameter: 2.600 mm - Max. workpiece weight: 12 tons - Turning height: 1.600 mm - Number of turning supports / RAMs: 2 * Ram dimensions: 250 x 210 mm each - Main drive: 55 kW EQUIPMENT: - CNC control: Siemens SINUMERIK 840D sl - Tool turret (right) Bodpfx Ajzlb H Tjqwjwt - Chip conveyor Dimensions / Weight: - Installation area: 5.600 x 4.800 mm - Hall space inc. operating and service areas: approx. 7.000 x 7.000 mm - Machine height: 6.200 mm - Machine weight: approx. 45 tons There is no guarantee for correctness and completeness of the technical details and accessories. - Subject to prior sale -

Condition: excellent (used), Year of construction: 2014, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,800 mm, spindle diameter: 130 mm, overall weight: 32,450 kg, year of last overhaul: 2014, The machine is in very good technical condition, equipped with a Heidenhain iTNC 530 CNC control system. Specifications: Spindle diameter: 130 mm X-axis travel: 3000 mm Y-axis travel: 1800 mm Bodjx Hfk Iepfx Aqwowt Taper in spindle: ISO 50 Spindle extension: 1120 mm Horizontal spindle head extension: 450 mm Total installed motor power: 50 KVA Dimensions (L x W x H): 10100 x 4380 x 5250 mm Weight: 32,450 kg

Condition: good (used), WMW BR 40/2 x 1250 radial drilling machine Drilling capacity in steel (diameter): 60 mm Arm reach: 1250 mm Max. workpiece height: 820 mm Spindle speed: 20-1200 rpm Spindle taper: MK 5 Spindle stroke: 400 mm Feed rate: 0.063-0.63 m/min Bwjdpfx Ajx U Ectjqwet Vertical arm adjustment: 950 mm Electrical connection: 380 / 50 V / Hz Clamping surface of base plate: 1400x800 mm Total power requirement: 5 kW Machine weight approx.: 3 t Floor space required approx.: 2.2 x 1.0 x 2.8 m

Condition: not inspected (used), Faceplate: 2500 mm Swinging diameter: 3200 mm Max. turning height under tool: 2500 mm Max. workpiece height under support: 2780 mm Max. workpiece weight: 25 tons Cross slide: 2000 mm Ram travel, vertical: 1600 mm Ram travel, horizontal: 1800 mm Ram cross-section: 250 x 300 mm Smallest distance between two rams: 1150 mm Faceplate drive: 71 kW Faceplate speed: 125 rpm Milling drive motor: 18 kW Milling drive speed: 1600 rpm Bwjdpszdk A Uefx Aqwot Milling drive torque: 710 Nm
