Condition: good (used), Year of construction: 1986, Grinding depth: 500 mm Internal diameter: 20...400 mm Workpiece spindle speed: 40...400 rpm Table speed: 0.1...8 m/min Rapid traverse: 10 m/min Total power consumption: 17 kW Machine weight approx.: 6.5 t Additional information: grindable diameter within the workpiece guard: internal: 20..400 mm; external: 500 mm max. workpiece diameter within the workpiece guard: 500 mm max. grinding depth: 315 mm grindable taper angle: 60° Internal grinding spindle speeds: 2640...16500 rpm Drive power for surface grinding unit: 4 kW Drive power for workpiece motor: 1.5 kW Workpiece spindle speeds: 40...400 rpm Table speed: 0.1...8 m/min Rapid traverse: 10 m/min Table travel: 630 mm max. distance from the workpiece spindle flange to the grinding spindle support: 1250 mm Nledps Afxqvefx Ab Rsh

Condition: good (used), Year of construction: 1982, number of straightening rollers: 13, straightening roller diameter: 145 mm, bale length: 2,330 mm, Year of construction / YOM: 1982/2024 Sheet width: 2000 mm Sheet thickness - max.: 10 mm Sheet thickness - min.: 3 mm Number of straightening rollers: 13 rollers Straightening roller diameter: 145 mm Straightening speed: 16 m/min Bundle length: 2330 mm Center distance between straightening rollers: 150 mm Nedpfs Afxcisx Ab Rolh Support roller diameter: 290 mm Main drive motor: 30 kW Weight: 32 t Additional information: - Number of support rollers: 21/24 - Number of supports (top/bottom): 3 /3 - Traverse lift speed: 0.71 mm/sec - Traverse lift stroke: -18 mm to +42 mm - Max. tilting of lower traverse: 8 mm

Condition: good (used), Year of construction: 1969, number of straightening rollers: 7, straightening roller diameter: 290 mm, max. sheet width: 2500 mm Nodj Afxb Espfx Ab Rolh Convexity length of rollers: 2700 mm max. sheet thickness (St 50): 32 mm max. sheet thickness (St 34): 39 mm min. sheet thickness (St 50): 8 mm number of straightening rollers: 7 rollers number of driven straightening rollers: 5 rollers diameter of straightening rollers: 290 mm diameter of input/output straightening rollers: 345 mm number of support rollers: 13 diameter of support rollers: 288 mm stroke of upper beam: 120 mm Straightening speed: 16 m / min Rated power of main drive: 90 kW Total load: 138 kW

Condition: good (used), Year of construction: 1975, Pressure: 250 t Throat: 400 mm Stroke: 30...140 mm Table size: 1000 x 750 mm Njdpfx Ae Afvbpob Relh Passage opening in table: 360 x 400 mm Ram area: 630 x 500 mm Ram adjustment: 110 mm Total power requirement: 18 kW Machine weight approx.: 16 t

Condition: good (used), Year of construction: 1994, Pressure: 250 t Throat depth: 360 mm Table size: 1250 x 630 mm Table diameter: 250 mm Ram clamping surface: 850 x 450 mm Nedo Afva Sopfx Ab Rjlh Installation height: 800 mm Piston stroke: up to 500 mm Piston diameter: 400/360 mm Ram speed downward: 200 mm/sec Ram speed upward: 110 mm/sec Total power requirement: 20.5 kW Machine weight approx.: 8 t

Condition: used, Offered is a CNC knee-type milling machine, model FU 400 × 1600. Clamping surface: milling table with T-slots. CNC control: VEB Numerik CNC-H 646. Equipped with a machine vise, flexible coolant hose and swiveling CNC control panel. Inspection possible by arrangement. Nodo Afpkwjpfx Ab Rolh

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,600 mm, travel distance Z-axis: 1,600 mm, feed length W-axis: 900 mm, workpiece weight (max.): 12,000 kg, overall weight: 30,000 kg, year of last overhaul: 2020, For Sale – Used CNC Horizontal Boring Machine UNION BFKR 150 Nledpfx Abo Afm Uyo Reh CNC Control: HEIDENHAIN TNC 530 CNC Retrofit: The machine was retrofitted with CNC control in 2020. Technical Specifications: X-axis travel: 3,000 mm Y-axis travel: 1,600 mm Z-axis travel: 1,600 mm W-axis travel: 900 mm (spindle travel) Spindle diameter: Ø 150 mm B-axis: 360° – CNC-controlled rotary table Table dimensions: 1,600 × 2,000 mm Machine Condition: The machine is currently still connected to the power supply and is available for inspection and a test run. The machine underwent a mechanical overhaul approximately three years ago, including the replacement of bearings and other components. The machine has been out of operation for approximately six months.

Condition: excellent (used), Year of construction: 1985, functionality: fully functional, pressing force: 250 t, stroke length: 500 mm, operating speed: 200 mm/s, reverse speed: 110 mm/s, table width: 900 mm, table length: 630 mm, throat depth: 800 mm, ram plate width: 750 mm, ram plate length: 450 mm, oil tank capacity: 500 l, total length: 2,200 mm, total width: 1,250 mm, total height: 3,700 mm, overall weight: 8,000 kg, Hydraulic press PYE 250 SS. Manufacturer: WMW VEB Zeulenroda (Germany), year 1985. Specifications: Maximum pressing force 250 tons. Working pressure 18.6 MPa. Upper table 750x450 mm. Lower table 900x630 mm. Clearance 800 mm. Cylinder stroke 500 mm. Downwards speed 200 mm/s. Upwards speed 220 mm/s. Power requirement 24 kW. Weight 8,500 kg. Height 3,680 mm, length 2,200 mm, width 1,250 mm. The machine is in very good technical condition. Fully overhauled. Nlsdpjvcb Tlsfx Ab Roh

Condition: used, turning height: 1,400 mm, turning diameter: 4,000 mm, faceplate diameter: 3,500 mm, Technical data: CNC control Siemens 802 D Dead weight 66 tons Drive power 63 kW Installation dimensions 13,600x9,800x6,750 mm Face plate diameter 3,500 mm Max. Workpiece height 2,000 mm Max. Support adjustment 30 degrees Max. Workpiece diameter 4,000 mm Nlsdpfx Absu R Ezyo Roh Max. Workpiece diameter with side support 3,750 mm Number of supports 2 Max. Turning height 1,400 mm Max. Workpiece weight 25 to Max. Speed 30/min Min. speed 1/min

Condition: used, Year of construction: 1969, turning diameter over bed slide: 1,000 mm, turning length: 10,000 mm, TECHNICAL DATA: Circulation diameter over bed 1,000 mm Diameter in the recess 1,120 mm Circulation diameter over bed slide 690 mm Center height above floor 1,110 mm Center height above bed 460 mm Width of the bed 800 mm Width of the recess in front of the faceplate 550 mm Turning length 10,000 mm Max. Center width 10,535 mm Diameter of the faceplate 1,000 mm Diameter of the lead screw 60 mm Cross section of cutting steel 40 x 63 mm Maximum permissible workpiece weights Between centers, without setting vice 5,000 kg Two centers, with 1 setting vice 6,300 kg Between centers, with 2 setting sticks 8,000 kg Drive power of the main motor For speed series 1,2 22 kW For speed ranges 3,4,5,6 30 kW Speed of the main motor For speed ranges 1,2 1000 min-1 Njdpfx Aou R Hzheb Rslh For speed ranges 3,4,5,6 1500 min-1 Number of work spindle speeds For speed series 1,3,5 22 For speed ranges 2,4,6 18 Page -2- Speed of the working spindle speeds For speed series 1 2.8...355 min-1 For speed series 2 7.1...355 min-1 For speed series 3 3.55...450 min-1 For speed series 4 9...450 min-1 For speed series 5 4.5...560 min-1 For speed series 6 11.2...560 min-1 Step change 1.25 Maximum permissible face plate speed 355 min-1 24 Normal longitudinal feeds 0.25...3.55 mm/rev 14 longitudinal feeds fine 0.05...0.224 mm/rev 24 normal face feeds 0.09...1.25 mm/rev 14 fine face feeds 0.018...0.08 mm/rev Thread pitches normal 22 pitches in mm 1...14 24 pitches in gear to one inch 28...2 18 pitches according to module 0.25...3.5 24 pitches according to diametral pitch 112...8 Fine thread - protruding values 1.5 Steep thread - protruding values 12 times Steep thread for speed series 1,3,5 With spider face plate - protruding values 32 times Maximum permissible workpiece weight Without setting vice 5000 kg With 1 setting vice 6300 kg With 2 setting vices 8000 kg Maximum torque 1700 mkp Characteristic speed for speed series 1,2 9 min-1 Characteristic speed for speed series 3,4,5,6 14 min-1
