Angular Clamping Device

WMW

Condition: used, functionality: fully functional, machine/vehicle number: 7085, Used universal cylindrical grinding machine Manufacturer: WMW Model: SU 315 x 1000 mm Equipped with internal grinding attachment Maximum workpiece diameter: 315 mm Maximum grinding length: 1000 mm Grinding spindle speed: 1340 rpm Workpiece speed: 22–500 rpm Longitudinal table travel: 5–1680 mm Table feed rate: 0.05–5 m/min Maximum workpiece weight: 300 kg Connected load: 12.5 kW Machine weight approx.: 5.8 t Pjdpewl A H Djfx Aigera

Condition: used, Rotary table, make WMK 'Fritz Heckert' Model D315 k TGL 28 561/01 Serial number 33402 • Clamping surface D = approx. 310 mm Prsdpfxjzw H Rho Aigea

Condition: used, Technical details: material thickness: 1,0 mm material width: 17,0 mm internal diameter: 30,0 mm external diameter: 78,0 mm Spare part for bench drill BT 2 Patt spring - Return spring - Spiral spring Declaration of conformity according to ISO/IEC 17050-1 Acceptance test certificate 3.1 according to DIN EN 10204 available Predpfju N E Evox Aigja *

Condition: used, Technical details: height: 1600 mm width: 1270 mm depth: 1000 mm 2 pieces clamping angle available ( Priece per piece) T-slot according to DIN 650 a=35mm; b=60mm; c=27mm; h=65mm Pjdou N Ea Hopfx Aigera *

Year of construction: 2020, condition: ready for operation (used), functionality: fully functional, WMW Niles, Czeck Republic Made, CNC(Siemens Controls, Retrofitted in 2020) Floor Type Heavy Duty Lathe ,With heavy Duty Tail Stock, Steady Rest, Rollers, and with 6000 MM X 4000 MM Floor plates Predpszww R Sjfx Aigea

Condition: used, Center height: 180mm, distance between centers: 1000mm, max. grinding diameter: 355mm, stop accuracy: 1µm, max. workpiece weight: 500kg, max. workpiece weight when machining in the chuck: 120kg, max. workhead spindle speed: 355rpm, workhead spindle power: 1.5kW, Morse taper: MK5, workhead swivel range toward the grinding wheel/away from the grinding wheel: 90°/10°, quill travel: 40mm, table feed during longitudinal grinding: 0.05m/min-5m/min, travel during longitudinal grinding: 4mm-2180mm, dwell time at reversal point: 0s-5s, max. grinding spindle speed: 1860rpm, grinding wheel dimensions diameter/width/bore: 630mm/125mm/305mm. Weight: approx. 5100kg. The machine has been geometrically reconditioned. Documentation available. An on-site inspection is possible. Prodezwpg Espfx Aigea

Condition: used, Year of construction: 1987, Technical details: spindle diameter: 110 mm x-travel: 1985 mm y-travel: Spindelstock vert. 1270 mm z-travel: Tisch längs: 1260 m. Setzstock/1490 m. Setzstock mm table adjustment: nein ° B-axis (table): 360 W-axis (spindle longitudinal): axial: 710 mm U-axis: Planschieber radial: 250 mm control for program: Heidenhain 320 tool taper: ISO 50 table-size: 1600 x 1400 mm table rotating: 360 ° table load: 6,3 t range drill spindle revolution per minute: 6,3 ... 1250 / 4 step U/min revolution per minute: Plansupport: 6,3 ... 315 / 2 step U/min feed steps: Tisch: 5...2500 und Spindelstock vert. 5...2500 mm/min total power requirement: ca. 90 kW weight of the machine ca.: 30 t Tailstock Facing slide 700 Pedpfx Aou Utwbeigsra Electronic handwheel max. turning Ø for drilling: 630mm max. turning Ø for facing: 1250mm At the moment the Horizontal Boring and Milling Machine has an electrical fault in the control (unknown). Our offer/sale is as described and as is! *

Condition: used, Technical details: spindle diameter: 110 mm x-travel: 2000 mm y-travel: 1600 mm z-travel: 2000 mm control for program: TNC Heidenhain 360 Psdpfx Aiou Idp Djgjra B-axis (table): ja W-axis (spindle longitudinal): Planschieber mm tool taper: ISO 50 table-size: 1400 x 1250 mm machine dimensions LxWxH: 8,0 x 6,0 x 4,5 m weight of the machine ca.: 28 t with face slide 700mm , electronic hand control *

Condition: good (used), Year of construction: 1982, Year of construction / YOM: 1982/2024 Sheet width: 2000 mm Sheet thickness - max.: 10 mm Sheet thickness - min.: 3 mm Number of straightening rollers: 13 rollers Straightening roller diameter: 145 mm Straightening speed: 16 m/min Prsdpezwl Ifofx Aigja Bundle length: 2330 mm Center distance between straightening rollers: 150 mm Support roller diameter: 290 mm Main drive motor: 30 kW Weight: 32 t Additional information: - Number of support rollers: 21/24 - Number of supports (top/bottom): 3 /3 - Traverse lift speed: 0.71 mm/sec - Traverse lift stroke: -18 mm to +42 mm - Max. tilting of lower traverse: 8 mm

Condition: good (used), Year of construction: 1969, max. sheet width: 2500 mm Convexity length of rollers: 2700 mm max. sheet thickness (St 50): 32 mm max. sheet thickness (St 34): 39 mm min. sheet thickness (St 50): 8 mm number of straightening rollers: 7 rollers number of driven straightening rollers: 5 rollers diameter of straightening rollers: 290 mm diameter of input/output straightening rollers: 345 mm number of support rollers: 13 Pjdpozwl D Hjfx Aigsra diameter of support rollers: 288 mm stroke of upper beam: 120 mm Straightening speed: 16 m / min Rated power of main drive: 90 kW Total load: 138 kW
