Rundtisch

Zeiss

Condition: ready for operation (used), Year of construction: 2008, travel distance X-axis: 430 mm, travel distance Y-axis: 850 mm, travel distance Z-axis: 400 mm, number of axes: 3, This 3-axis ZEISS ScanMax was manufactured in 2008. It features a travel range of 430 x 850 x 400 mm and can handle a workpiece weight up to 50 kg on its standard base frame or 20 kg on the rotary tilt table. The machine's overall dimensions are 640x1057x2080 mm. If you are looking to get high quality measuring capabilities consider the ZEISS ScanMax machine we have for sale. Contact us for more information. Cjdoyab Aropfx Ah Ijgp • Permissible workpiece weight with standard base frame: 50kg • Permissible workpiece weight with rotary tilt table: 20kg • Max. probe length: 300mm • Weight of components: • Appliance: 60kg • Underframe: 315kg • Electronic unit: 25kg • Rotary tilt table: 12kg • Overall dimensions (LxWxH): 640 x 1057 x 2080 mmRetrofit - (HW + SW) update of the Dual PC measuring station: 25.08.2014 Latest OS version: Windows XP Measuring software: ScanWare 2.8.4/556

Condition: good (used), Year of construction: 2012, functionality: fully functional, measuring range X-axis: 400 mm, measuring range Y-axis: 400 mm, measuring range Z-axis: 200 mm, travel distance X-axis: 400 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 200 mm, input voltage: 230 V, Equipment: lighting, type plate available, Year of manufacture: 2012 Tactile: Vast XXT E0 X/Y (1D) in [μm] at 20 ±2 °C 1.7 + L/250 E0 XY (2D) in [μm] at 20 ±2 °C 1.7 + L/250 E0 (3D) in [μm] at 20 ±2 °C 1.9 + L/250 Cgedpfxeuq Nfhe Ah Iep Scanning probing deviation MPE according to ISO 10360-4:2000 THP at 2.7 [μm] Single probe probing deviation form MPE according to ISO 10360-5:2010 PFTU 1.9 [μm] Camera system: Zeiss Discovery 12 EB X/Y (1D) 5) in [μm] at 20 ±2 °C 1.7 + L/250 EB XY (2D) 5) in [μm] at 20 ±2 °C 1.7 + L/250 Probe deviation MPE according to ISO 10360-7:2011 PF2D 5) 1.7 [μm] Probe deviation of the image processing system MPE according to ISO 10360-7:2011 PFV2D 5) 1.2 [μm] Possible services: delivery, commissioning

Condition: ready for operation (used), Year of construction: 2019, total height: 2,797 mm, overall weight: 1,570 kg, This 3-axis ZEISS Contura 7/10/6 RDS was manufactured in 2019 and features a robust motorized CNC drive system with a maximum vector speed of 465 mm/s. It includes the ZEISS RDS-C articulating head and VAST XXT TL3 sensor, capable of scanning speeds up to 150 points/second. Ideal for precise measurements with a maximum workpiece weight of 730 kg. Consider the opportunity to buy this ZEISS Contura 7/10/6 RDS CMM machine. Contact us for more information about this machine. Additional information • Maximum workpiece size: approx. 1344 x 910 x 716 mm • Maximum workpiece weight: 730 kg • Table height: 850 mm • Equipped with vibration damping system • Sensor System: • Articulating head: tilt ±180°, rotation increments 2.5° • Scanning speed: up to 150 points/second Cgedpfxex D Ngfe Ah Iep • Max. stylus length: 150 mm • Max. stylus weight: 15 g • Min. stylus tip diameter: 0.3 mm • Accuracy (per ISO 10360 standards): • Length measurement error (E₀): 1.7 + L/350 µm (at 18–22°C) • Scanning error (THP): 2.7 µm • Form measurement error (RONt): 1.7 µm • Repeatability (R₀): 1.2 µm • Controller: ZEISS C99L • Software: ZEISS CALYPSO, ZEISS GEAR PRO, ZEISS HOLOS • Control mode: Motorized / CNC • Interface: Ethernet, USB • Performance: • Drive system: Motorized CNC • Travel speed (axes): 0–70 mm/s • Max. vector speed: 465 mm/s • Max. acceleration: 1.85 m/s² • Scanning speed: up to 125 mm/s • Utilities: • Power supply: 100–240V AC (±10%), 50–60 Hz • Max. power consumption: 800 VA • Typical power usage: 200 W • Compressed air: 6–8 bar, pre-cleaned, dry (ISO 8573-1 Class 4) • Air consumption: max. 120 Nl/min • Environmental Conditions: • Operating temperature: 18°C–22°C • Relative humidity: 30–60% (non-condensing) • Compliance & Certifications: • Conforms to EC Machine Directive 2006/42/EC • EMC Directive 2014/30/EU • Quality management: ISO 9001:2008 • Environmental management: ISO 14001:2004 • Accredited ISO / IEC 17025:2005 Dimensions Machine Depth 1975 mm

Condition: ready for operation (used), Joystick box for Zeiss C99 controllers Box without speed override €750,-- Cedpsfh Dpmofx Ah Iegp

Year of construction: 2022, condition: ready for operation (used), Optical measurement machine manufactured in 2022. This ZEISS GOM ATOS 5 features a scanning principle based on the Triple Scan Principle and utilizes LED structured blue light for precise measurements. If you are looking to get high-quality optical measurement capabilities, consider the ZEISS GOM ATOS 5 machine we have for sale. Contact us for further details. • ZEISS ATOS Q – Optical 3D Measuring System • System type: Industrial structured-light 3D scanner • Measuring principle: Fringe projection / Triple Scan technology • Light source: LED with Blue Light Equalizer Cgsdpfx Asymmq Ujh Iep • Laser pointer for distance adjustment • Cameras: 2 × 8 megapixel CMOS • Camera resolution: 3357 × 2456 pixels • Measuring fields included: • 350 × 260 mm • 170 × 130 mm • Sensor dimensions: approx. 325 × 240 × 90 mm • Sensor weight: approx. 4 kg • Robust industrial housing • Fiber-optic sensor cable connection • Calibration objects with DAkkS certificate • Acceptance test according to VDI/VDE 2634 Sheet 3 • Traceable acceptance certificate • Mobile controller: Converter box with image processing card (fiber optic to Thunderbolt) • External power supply • Workstation (Laptop 7760 Mobile): Intel 2.6 GHz Octa-Core CPU • 64 GB RAM • NVIDIA Quadro graphics card • 17" display • 1 TB SSD • External USB backup drive • WiFi / LAN / USB 3.2 / Thunderbolt • Operating system: Windows 10 (64-bit) • Software: ZEISS Quality Suite • ATOS sensor driver • GOM Inspect • CAD import formats: IGES, STEP, VDA, JT, STL, PLY • Export formats: STL, G3D

Condition: used, 3D Coordinate Measuring Machine ZEISS NUMEREX - Not Functional Granite Measuring Table, Granite Surface Plate, Measuring Table Cgjdjfy U Ewjpfx Ah Iop Model No. 3648-18, Serial No. X-1019, Year of Manufacture approx. 1986 Measuring Range X = approx. 1250 mm, Y = approx. 900 mm, Z = approx. 400 mm Measuring Plate L x W 1525 x 1435 mm Usable Surface 1525 x 1100 mm Plate Thickness 305 mm Clearance Width in the Portal 1100 mm Probe Mount Ø 9.5 mm Compressed Air Connection 6 bar Power Supply 230 Volt, 50 Hz - Granite plate with steel inserts with internal threads - Axis adjustment with pneumatic slide guide for X, Y, and Z axis - Plate mounted on base frame with 5 leveling feet, 3 support plates for the feet - Computer and software missing (not available and not included) → not functional! Space required for the measuring machine L x W x H 1600 x 1850 x 2200 mm Machine weight approx. 2.8 tons Plate is damaged on one side – see photo, otherwise in good condition

Condition: excellent (used), Passameter Manufacturer: Zeiss (108150) Csdpfeylkkvjx Ah Ijgp Measuring range: 75 - 100 mm Complete with 2 center stops and pin spanner

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, machine/vehicle number: 153888, measuring range X-axis: 400 mm, measuring range Y-axis: 400 mm, measuring range Z-axis: 400 mm, workpiece weight (max.): 20 kg, total height: 1,770 mm, type of input current: DC, total width: 1,351 mm, total length: 1,055 mm, year of last overhaul: 2022, ambient temperature (max.): 35 °C, ambient temperature (min.): 17 °C, Equipment: lighting, For sale: Optical-Tactile Measuring Machine The device is in excellent condition and has been serviced regularly and professionally. Calibration certificates are available. Technical data: Measuring range: 400 mm x 400 mm x 400 mm Year of manufacture: 2011 Sensor technology: Cgedpfx Ahsylkfaj Isp Optical: ZEISS Discovery zoom lens Tactile: VAST XXT probing system Software: ZEISS CALYPSO Additional software: CALYPSO Freeform Surface BasLic; dongle-based basic license for the current software version Accessories: • Computer, mouse, keyboard, monitor • Smooth calibration sphere (for tactile probe) • Matte calibration sphere (for white light interferometer) • Calibration standard – optical • Calibration standard – tactile • 3 probes: reference probe, 3x50, 1x20 with 30 mm extension • DAkkS calibrated in 2022 • Software: Calypso 2019 dongle license • Tactile probe head • Optics • White light interferometer • 3-position probe change rack • Operating manual • Additional software: CALYPSO freeform surface, BasLic, dongle-based basic license for the current software version Transport and loading can be organized on request, at an additional cost, Europe-wide. Prices are subject to VAT. Viewing by appointment possible. Please contact us – our team will be happy to assist you. Trade-in or exchange possible! Machinery Purchase & Sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES, AND MORE. Gjbn N Ay Dowza Dxogoil Are you looking for a high-quality yet affordable metalworking machine for your production? Or do you want to sell yours? For further information or to get in touch, please visit our website.

Condition: used, Year of construction: 2011, functionality: fully functional, machine/vehicle number: 141447, Technical characteristics: Max. measuring range in mm X axis 500; Y axis 500; Z axis 500 Dimensions in mm Without base: length: 1160; width: 1080; height: 1803 With base: length: 1170; width: 1090; height: 2480 Mass of CMM in kg: without base: 350 with base: 445 Max admissible workpiece mass in kg: 100 Equipment consists of: Coordinate measuring machine (CMM) with base Control (integrated) Control console Software (Calipso 5.4) Documents Probing system Master stylus Reference standard Changer rack Machine status: WORKING Codpfx Aoxxvbroh Isgp

Condition: used, Year of construction: 2013, functionality: fully functional, machine/vehicle number: 201310504039 623534 -9805-130, Technical characteristics: 📏 Measuring Range & Dimensions X-axis: 700 mm Y-axis: 1000 mm Z-axis: 600 mm Maximum workpiece weight: approx. 730 kg Table height: 850 mm Machine footprint: approx. 1600 × 2100 mm Height: approx. 2800 mm 🧠 Accuracy & Performance Length measurement error (MPE): Cgedpfxexxu Hgj Ah Ijp VAST XXT: (1.8 + L/300) µm TP20/TP200: (2.2 + L/300) µm Probing error (MPE_P): VAST XXT: 1.8 µm TP20/TP200: 2.0 µm Scanning performance: Up to 500 points/sec VAST Navigator and Fly Mode for optimized path planning 🔧 Sensor & Probe Options Probe head: ZEISS VAST XXT or RDS articulating head Stylus length: Up to 150 mm (TL3 module) Stylus weight: Max. 15 g Angular positions: 20,736 with CAA correction Optional sensors: ZEISS ViScan (optical) ZEISS LineScan (laser triangulation) ZEISS DotScan (white light confocal) 🌡️ Environmental Conditions Operating temperature: 17–35 °C Guaranteed accuracy: 18–22 °C Humidity: 30–60% (non-condensing) Vibration damping: Integrated passive system ⚡ Utilities & Control Power supply: 100–240 V AC, 50–60 Hz Maximum power consumption: approx. 800 VA Compressed air: 6–8 bar, max. 120 Nl/min Controller: ZEISS C99L with CALYPSO software Protection class: IP53 Machine status: WORKING
