2 x 65 m³ aluminum silo / storage silo

Zeppelin

Year of construction: 2000, condition: used, functionality: fully functional, Aluminum storage silo with a sturdy base ring Technical data / Dimensions Available quantity: 4 Volume: approx. 174,000 liters Container type: Silo Condition: used Food grade: no Design: vertical Internal diameter: approx. 4,200 mm External diameter: approx. 4,260 mm Cylindrical height: approx. 15,000 mm Overall height: approx. 16,250 mm Weight: approx. 3,500 kg Specific gravity of the medium: 1 ton/m³ Operating pressure: non-pressurized Notes: A new access ladder for the silo system can be offered as an option. Material / Properties Material, inner shell: Aluminum Internal welds ground smooth Notes: Material AlMg3 / AlSi Equipment Base design: Foot ring / base ring Quantity: 1 Mounting: fixed Top bottom type: Conical bottom Bottom type: Cone Cone angle: 90 degrees Top: 1 x roof edge railing, height: approx. 1,200 mm 1 x walkway with platform 2 x crane eye 1 x manhole DN 500 1 x connection flange for level measurement Cjdoy Ufigspfx Aipjrc 1 x threaded socket for max. sensor 1 x flange DN 100 (filling) 1 x vent with hood Shell: 1 x operating room door (approx. 1,800 x 850 mm) 1 x cable protection conduit 1 x filling line DN 100 (insulated) ending in a TW connection 1 x welded adapter for empty message Bottom: The silos end at the bottom in a 90° cone with a flange DN 200 and an emergency shut-off valve. Fittings: The measuring and control technology installed on the silo will be supplied free of charge. However, no guarantee can be given for its proper functioning. Documentation Drawing

Year of construction: 1987, condition: used, functionality: fully functional, machine/vehicle number: 17526, For sale: aluminium silo suitable for storing granulate, 4 units available. The price is per unit. Cjdpfxexx Nnlo Aipsrc

Condition: used, functionality: fully functional, Aluminum flour/sugar silo with a tall support base (used), designed for a bulk density of 0.95 kg/dm³. Volume: 70,000 liters Available quantity: 4 Diameter: approx. 2,400 mm Cylindrical height: approx. 17,500 mm Total height: approx. 19,200 mm (incl. roof edge railing) Material: AlMg3 Bulk density: 1.0 kg/dm³ Equipment and connections: Crodpjyhzm Rofx Aipec In the upper section: 1 x access opening DN 600 with cover 1 x over/under pressure valve 1 x top-mounted ventilation filter (ø 1000 x 5 mm) 1 x flange DN 125 for filling pipe 1 x flange DN 50 for pressure transmitter 1 x roof edge railing with handrail 2 x crane lugs In the body: 1 x access door 850 x 1800 mm 8 x pipe supports ø 108 mm for filling pipe 1 x filling pipe DN 100, ending in a threaded connection at the bottom 1 x cable protection pipe DN 50 1 x block flange for level sensor Partially, manhole DN 500 in the body Various pipe penetrations in the area of the lower support base The silo has a 40° cone at the bottom, which ends in a flange DN 1500 for accommodating a vibratory base. At the bottom/cone: 1 x vibratory base VB 1400 with motor, manufacturer AZO 1 x block flange for empty sensor The currently connected measuring and control technology is included in the above offer. However, no guarantee is given for its functionality! Please note that the connections and equipment of the four silos may differ slightly. Otherwise, as per the images and drawing.

Condition: excellent (used), Aluminum silos standing on foot ring (plastic granulate silos) - used - designed for a bulk density of 1.0 kg/dm³. volume: 105.000 ltr. Manufacturer: Zeppelin Available quantity: 1 diameter: approx. 3.000 mm Cyl. height: approx. 17.500 mm Total height: approx. 15,000 mm (incl. 1,250 mm roof edge railing) Material: AlMg3 Bulk density: 1.0 kg/dm³ Inclination of the top soil: 15°. Inclination of the cone: 60 Equipment and connections: In the top floor: Codpslg Dcfjfx Aiporc 1 x access dome DN 500 with hinged cover 1 x vent hole with hood 2 x flange DN 100 PN 10 (filling + level indicator) 1 x connection piece for full indicator 1 x roof edge railing with handrail 2 x crane eyes On the mantle: 1 x access door 850 x 2000 8 x pipe holders for filling pipe DN 100 1 x filling pipe DN 100 1 x cable pipe 1 x connection piece for full detector The silo ends at the bottom in a 60° cone with flange DN 200 (discharge height: approx. 500 mm) with suction box. The currently connected measuring and control technology is included. However, no warranty is assumed for their function! Additional price: The silo has a two-row access ladder with back protection and dwell platform (additional price: 950 € plus VAT). Otherwise according to pictures and drawing.

Year of construction: 2004, condition: used, functionality: fully functional, Silo Manufacturer: ZEPPELIN - Capacity: 10 m³ - Total height: approx. 5.00 m - Diameter: 2.0 m - Year of manufacture: 2004 - Inspection opening There are 3 units available, 1 of which is equipped with an internal rotary mixer Subject to prior sale. Please make inquiries by email only. Note: The machine/unit is still installed and can be inspected on site. The buyer is responsible for dismantling and transport. This is not included in the offer price. Crsdpfxsualkke Aipsc

Condition: excellent (used), functionality: fully functional, 2 x aluminium silos with extended support ring + filter housing, ø 3,000 mm, designed for a specific gravity of 0.6 kg/dm³ Manufacturer: Zeppelin Capacity: approx. 80,000 litres Cjdpogh Dgbefx Aiperc Diameter: approx. 3,000 mm Total height: approx. 16,000 mm Weight: approx. 2,000 kg Design density: 0.6 kg/dm³ Connections and fittings: On top: 1 x crane eye In filter housing: 1 x filter frame, approx. 900 x 1,000 mm, with aeration nozzle 1 x manhole DN 600 3 x connections for control/measurement technology (incl. silo pilot, min-max indicator, and additional measuring probe) On silo shell: 1 x access door with lock to filter housing 1 x access door (cone) 1 x signal light Various openings for filling pipes Silo ends in a 60° cone. The 2 silos are equipped with a dual-lane ladder system with rear safety cage.

Year of construction: 1983, condition: ready for operation (used), Various mixing and storage silos are available. 1) Stainless steel silo. 2) Stainless steel silo Zeppelin, year of construction: 1983, capacity: 32m³, friction angle range: 25°-45°, overpressure range: 5mbar-45mbar, max operating temperature: 50°C, bulk density: 0.6kg/dm³, silo height: 11250mm, silo diameter: 3000mm. 3) Stainless steel silo. 4) 3x identical HD-PE mixing silos, total height: approx. 10500mm, diameter: 3000mm, volume: approx. 49.5m³, mixing pipes: NW 150, motor power: 15kW. 5) 2x identical storage silos Zeppelin, year of construction: 1980, volume: 127m³, capacity: 119m³, silo diameter: 3500mm, inclination angle: 15°, hopper height: 1680mm, support ring height: 3700mm, total height: 17500mm. Documentation available. An on-site inspection is possible. Individual sale possible. Credpfxsxxl I Uj Aipec

Condition: excellent (used), functionality: fully functional, Aluminum flour silo with extended base ring (used), designed for a bulk density of 0.8 kg/dm³ Volume: 56,000 liters Available units: 1 Diameter: approx. 2,400 mm Cylindrical height: approx. 15,000 mm Total height: approx. 16,500 mm (incl. roof perimeter safety railing) Material: AlMg3 Bulk density: 0.8 kg/dm³ Crsdpfxoyhznzj Aipoc Equipment and connections: Top head: - 1 x pressure/vacuum relief valve - 1 x venting filter add-on - 1 x flange for filling pipe - 1 x flange for level measurement - 1 x flange for pressure transducer - 1 x flange for level indicator - 1 x roof perimeter safety railing with handrail - 2 x lifting lugs Silo shell: - 1 x access door 850 x 1800 mm - 8 x pipe brackets ø 108 mm for filling pipe - 1 x filling pipe DN 100, ending at TW connection at the bottom - 1 x cable protection pipe DN 50 - Various pipe penetrations in the area of the lower base ring The silo features a 40° conical bottom, terminating in a DN 1500 flange for fitting a vibrating floor. At the bottom/cone: - 1 x block flange for empty indicator - 1 x vibrating floor The currently installed measuring and control technology is included in the above offer, but no guarantee is given for its functionality! Otherwise, as per images and drawing.

Condition: excellent (used), Year of construction: 2007, Zeppelin Diesel Genset Type: PPO2000 - C32 Csdpfx Aieizbdaepsrc Serial No.: ZPSU1023; Arr.No: 273-9683; Year: 2014; Voltage [V]: 400; Rating [kW]: 1600; Rating [kVA]: 2000; speed [RPM]: 1500; Frequency [Hz]: 50; SMU [hrs]: 0; Application: prime; Layout: Canopy; condition: pre-owned; Notes: Diesel Engine 2 * CAT C32 PPO, new Stamford HC6J alternator, with ComAp automatic Panel Inteli Compact, 2 x circuit breaker, 4000 L in two fuel tank, Jacketwater heater. L/W/H: 11 m,/ 2,3 m/ 3,2 m, weight. 26t, Import duty unpaid.

Condition: excellent (used), functionality: fully functional, Aluminum silo with extended support ring - used - Volume: approx. 48,000 liters Container type: silo Condition: used Suitable for food: yes Construction: vertical Internal diameter: approx. 2,400 mm Cylindrical height: approx. 13,750 mm Overall height: approx. 15,000 mm Specific gravity of medium: 0.8 t/m³ Operating pressure: non-pressurized Material / Design Shell material: aluminum Features Support structure: foot ring/stand collar Top end plate: conical top Slope: approx. 15% Bottom end plate: cone Cone angle: 60 degrees Top: 1 x flange DN 100 PN 10 (filling) 1 x flange DN 150 PN 10 (vent) 1 x flange DN 150 PN 10 (level measurement) 1 x flange DN 100 PN 10 (spare) 1 x threaded socket 1 1/2" (sensor technology) 1 x roof edge railing with handrail 2 x crane lugs Crodpfx Aisx Stccepsc Shell: 1 x stand collar door (approx. 880 x 1800 mm) 5 x pipe brackets for filling pipe 5 x pipe brackets for overflow pipe 1 x filling pipe DN 100 (filling lines and connections for silo trucks may need to be retrofitted in part) 1 x overflow pipe DN 80 1 x threaded socket 1 1/2" (measuring probe) Bottom: 1 x cone (60°) 1 x flange DN 80 (overflow pipe) Fittings: The measuring and control equipment currently installed (where present) is included in the scope of delivery. However, no warranty is provided for its functionality! Otherwise as shown in the photos and drawing. Documentation: Drawing
