2 x 80 m³ aluminium silos, Ø 3,000 mm

Zeppelin

Condition: used, functionality: fully functional, Aluminum silo with a long base ring (flour silo) Technical data / Dimensions Available quantity: 3 Volume: approx. 63,200 liters Container type: Silo Condition: used Food-grade: yes Design: standing Inner diameter: approx. 2,400 mm Outer diameter: approx. 2,500 mm Cylindrical height: approx. 17,500 mm Overall height: approx. 19,000 mm Specific weight of the medium: 0.60 t/m³ Operating pressure: Non-pressurized Material / Properties Rodpfx Aljzw Nv Tsaocf Material, inner lining: Aluminum Notes: Material: AlMg3 Equipment Base design: Foot ring / base ring Number: 1 Mounting: fixed Bottom type, top: Conical bottom Bottom type, bottom: Cone Top: 1 x Roof edge railing with handrail 2 x Crane lugs 1 x Overpressure valve 1 x Strainer on flange DN 1000 with reducer 1 x Flange for level limit indication 2 x Flange for level measurement The connections vary slightly between the three existing silos. Shell: 1 x Manhole DN 500 with star-grip closure 1 x Vent dome DN 500 1 x Access door 850 x 1800 mm 7 x Pipe clamps for filling pipe 1 x Filling pipe, ending in a threaded connection at the bottom 2 x Cable protection conduit DN 50 Bottom: The silo has a 40° cone at the bottom, which ends in a flange DN 1500 for the attachment of a vibratory floor. At the bottom / cone: 1 x Vibratory floor VB 1400 with motor and emergency shut-off slide Notes: The currently connected measuring and control technology is included in the above offer. However, no guarantee is given for its function! There are a few weld seams on the base ring (closed connections / openings).

Condition: used, Year of construction: 2003, Technical details: Pressure: 60 t stroke: 400 mm table surface area: 700 x 700 mm passage opening in table: Ø 100 mm distance between columns: 700 mm distance between columns: 700 x 1300 mm table height over floor: 850 mm dayligth: max. 1150 mm Rcedpfx Alezvnrdjaof daylight dimension : table/slide up: 400 - 800 mm cylinder diameter: Ø 110 mm total power requirement: 4,8 kW machine weight approx.: 930 kg dimension machine approx.LxWxH: 1,2 x 0,7 x 3,0 m HYDRAULIC DOUBLE COLUMN PRESS Special construction welded from 25 mm sheet steel Operating mode: single stroke Punch holder: pin M 70 x 2.5mm and punch Ø 128 x 440mm Table protection housing Round punch Ø 130 x 120 mm Hydraulic unit *

Condition: used, Used Zeppelin / Henschel Model FM1000 stainless steel high intensity mixer. Approximate capacity: 1,000 litre (product dependent). Stainless steel mixing chamber rated atmospheric pressure at 200°C. External mild steel heating / cooling jacket rated 5 bar pressure at 95°C. Unit includes 3-tier mixing attachment bottom driven by 250 kW, 1490 rpm, 280/660 V, 50/60 Hz motor. Has a top-clamped lid. Includes pneumatically operated discharge valve. Rsdpfx Aozun Hfelajcf

Year of construction: 1983, condition: ready for operation (used), Various mixing and storage silos are available. 1) Stainless steel silo. 2) Stainless steel silo Zeppelin, year of construction: 1983, capacity: 32m³, friction angle range: 25°-45°, overpressure range: 5mbar-45mbar, max operating temperature: 50°C, bulk density: 0.6kg/dm³, silo height: 11250mm, silo diameter: 3000mm. 3) Stainless steel silo. 4) 3x identical HD-PE mixing silos, total height: approx. 10500mm, diameter: 3000mm, volume: approx. 49.5m³, mixing pipes: NW 150, motor power: 15kW. 5) 2x identical storage silos Zeppelin, year of construction: 1980, volume: 127m³, capacity: 119m³, silo diameter: 3500mm, inclination angle: 15°, hopper height: 1680mm, support ring height: 3700mm, total height: 17500mm. Documentation available. An on-site inspection is possible. Individual sale possible. Rjdpfxjxxl I Uo Alaocf

Year of construction: 2001, condition: good (used), Manufacturer: Zeppelin Silo- und Apparatetechnik GmbH Type: Stainless steel silo Year of manufacture: 2001 Volume: 70 m³ per silo Material: Stainless steel Filling material: PA/PP granules Bulk density: 0.6 kg/dm³ Silo height: 12,500 mm Silo diameter: 3,000 mm Max. operating overpressure: 45 mbar Permissible underpressure: 5 mbar Max. operating temperature: 50 °C Max. insertion depth: 11,000 mm Redjzqkfpjpfx Alaocf Wall friction coefficient: 0.3–0.4 Horizontal load ratio λ: 0.5–0.7 Bottom load factor cb: 1.5 Discharge factor eh: 1.2 Bulk material coefficient βG: 0.4 μH: 0.2–0.4 Available quantity: 3 silos

Condition: used, functionality: fully functional, Aluminum flour/sugar silo with a tall support ring (used), designed for a bulk density of 0.95 kg/dm³ Volume: 70,000 liters Available quantity: 1 Diameter: approx. 2,400 mm Cylindrical height: approx. 17,500 mm Overall height: approx. 19,200 mm (including roof edge railing) Material: AlMg3 Bulk density: 1.0 kg/dm³ Equipment and connections: In the upper section: 1 x access opening DN 600 with cover 1 x over/underpressure valve 1 x top-mounted ventilation filter (ø 1000 x 5 mm) 1 x flange DN 125 for filling pipe 1 x flange DN 50 for pressure transmitter 1 x roof edge railing with handrail 2 x crane eyelets On the shell: 1 x access door 850 x 1800 mm Rcjdpfxsyhzm Re Alaef 8 x pipe support ø 108 mm for filling pipe 1 x filling pipe DN 100, ending in a TW connection at the bottom 1 x cable protection conduit DN 50 1 x block flange for level indicator 1 x rupture disc Various pipe penetrations in the area of the lower support ring The silo has a 40° cone at the bottom, which ends in a flange DN 1500 for mounting a vibratory base. At the bottom/cone: 1 x vibratory base VB 1400 with motor, manufacturer AZO 1 x block flange for empty level indicator The currently connected measuring and control technology is included in the above offer. However, no guarantee is given for its function! Please note that the connections and equipment of the four silos may differ slightly. Otherwise, as per the images and drawings.

Condition: excellent (used), functionality: fully functional, total height: 16,250 mm, outer diameter: 3,550 mm, 5 x 125 m³ aluminum storage silo with a wide base (plastic granulate silo) Technical data / Dimensions Available quantity: 5 Volume: approx. 125,000 liters Container type: Silo Condition: used Food grade: no Design: vertical Internal diameter: approx. 3,500 mm External diameter: approx. 3,550 mm Cylindrical height: approx. 15,000 mm Overall height: approx. 16,250 mm Weight: approx. 2,500 kg Specific gravity of the medium: 1 ton/m³ Operating pressure: non-pressurized Wall thickness, bottom: approx. 5.5 mm Wall thickness, top: approx. 5.0 mm Wall thickness, shell / cylinder: approx. 3.5 - 5.5 mm Ground clearance: approx. 500 mm Material / Properties Material, inner shell: Aluminum Internal welds ground smooth Notes: Material: AlMg3 / AlSi Equipment Base design: base ring/wide base Quantity: 1 Mounting: fixed Bottom type, top: conical bottom Bottom type, bottom: cone Cone angle: 90 degrees Top: 1 x roof edge railing, height: approx. 1,200 mm 1 x walkway with platform 2 x crane eye 1 x manhole DN 500 with safety grid 1 x flange DN 100 (filling line) 1 x flange DN 300 (level measurement) 1 x threaded socket for Max sensor 1 x flange DN 100 (filling) 1 x vent DN 200 with hood Shell: 1 x service access door (approx. 1,800 x 850 mm) 1 x cable protection conduit 1 x filling line DN 100, ending in a TW connection Rcodpeznn Ntefx Alasf 1 x threaded socket 1 1/2" for empty indicator Bottom: The silos end at the bottom in a 90° cone with a flange DN 150 with emergency shut-off valve and suction box. Fittings available Notes: A matching access ladder (two-section) can be optionally purchased (additional cost: €1,500 plus VAT). The measuring and control technology installed on the silo will be supplied free of charge. However, no guarantee can be given for its perfect functioning.

Condition: excellent (used), 5 x aluminum silos standing on a foot ring (plastic granulate silos) - second-hand - designed for a bulk density of 0.6 kg/dm³ Technical data / dimensions Available quantity: 5 Volume: approx. 100,000 liters Container type: Silo Condition: used Design: upright External diameter: approx. 3,000 mm Cylindrical height: approx. 16,250 mm Total height: approx. 17,500 mm Specific weight of the medium: 0.6 to/m³ Material / composition Jacket material: Aluminum Features Stand form: Foot ring/stand frame Top base type: Conical base Gradient: approx. 15% Bottom shelf type: Cone Cone inclination: 90 degrees Top floor: 1 x DN 600 access dome with hinged lid and safety grille 1 x NW 200 ventilation nozzle with rain hood 1 x flange nozzle for Silopilot (level measurement) 1 x Block flange for full detector 1 x Roof edge railing with handrail 2 x crane eyes Jacket: 1 x access door 850 x 2025 mm 1 x filling pipe NW 80 with tangential entry into the silo, ending at the bottom in Rsdpfx Alotq A Emsajcf B-coupling at the bottom 1 x cable protection conduit (19 mm) 1 x connection piece for full detector Various openings in the frame shell for the passage of pipes The silo ends at the bottom in a 90° cone with an outlet flange DN 500 (outlet height: approx. 500 mm). Remarks: The currently connected measurement and control technology is included (if available). However, no warranty is given for their function! One of the silos has a two-pass access ladder with back protection and dwelling platform (surcharge: € 1,500 plus VAT). Otherwise according to pictures and drawing

Year of construction: 2004, condition: used, functionality: fully functional, Silo Manufacturer: ZEPPELIN - Capacity: 10 m³ - Total height: approx. 5.00 m - Diameter: 2.0 m - Year of manufacture: 2004 - Inspection opening There are 3 units available, 1 of which is equipped with an internal rotary mixer Subject to prior sale. Please make inquiries by email only. Note: The machine/unit is still installed and can be inspected on site. The buyer is responsible for dismantling and transport. This is not included in the offer price. Rcjdpfx Aljualkkeasf

Condition: good (used), 3 x 65 m³ aluminum silo (granulate storage silos) with long frame (used) Contents approx. 65,000 liters Diameter (inside) approx. 3,000 mm Total height approx. 12,000 mm Bulk density: 0.6 kg/dm³ Cone inclination: 90 degrees Connections in the topsoil: 1 vent nozzle with hood DN 200 1 flange nozzle DN 100 In the shell: Rcjdpsvmidyjfx Alaef 1 folding dome DN 450 1 filling pipe pulled downwards DN 80 Cone: The cone ends in a flange DN 150 with suction box otherwise as per sketch and photos
