Profile bending machine

Zopf ZB70/2H

Condition: good (used), ZOPF ZB 70/2 H – Ring Bending Machine / Profile Bending Machine Manufacturer: ZOPF GmbH Model: ZB 70/2 H Serial number: 5710276 Year of manufacture: 2005 Category: Ring Bending Machine / Profile Bending Machine Location: Germany Technical Specifications Power supply: 400 V / 50 Hz Motor power: 2.2 kW Current: 6.5 A Number of driven rolls: 2 Top roll adjustment: Hydraulic (H version) Roll speed: 8.5 rpm (max.) Speed control: rotational speed adjustable via potentiometer Bjdpjxw Np Tjfx Af Hsdk Mechanical Specifications Shaft diameter of rolls: approx. 40 mm Roll/bending roll diameter: approx. 152 / 162 mm Hydraulic pressure force: approx. 80 kN Adjustment travel of top roll: approx. 120 mm Working position: suitable for both horizontal and vertical operation Construction: welded steel frame, conical roller bearings, interchangeable slideways Bending Capacity (indicative) Round tube: up to approx. Ø 70 × 2 mm Solid round: approx. Ø 35 mm Angle profile: approx. 50 × 50 × 6 mm Dimensions and Weight Machine weight: approx. 470 kg Dimensions: 800 mm wide x 900 mm deep x 1200 mm high Please note: The information on this page has been obtained and compiled to the best of our knowledge, but accuracy cannot be guaranteed. Accordingly, it does not constitute a representation or contract and we recommend that you verify all relevant details independently. Financial Information VAT/margin: VAT/margin: VAT: The price shown is excluding VAT (VAT deductible for businesses).

Condition: new, Year of construction: 2024, Bending machine ZB 70/2 H- with foot pedal- with standard roller setTECHNICAL SPECIFICATIONS:- two driven shafts, knurled surface - hydraulic adjusting of the center roller- working position horizontal and vertical - digital readout with memory- shafts are supported by conical bearings- slide bars on the slide-support are exchangeable- shaft diameter: 40 mm- roller diameter: 152/162 mm- shaft rpm: 8,5 U/min- voltage: 400V 50Hz 3Ph- drivingmotor: 1,1 kW- motor for hydraulic: 1,1 kW- hydraulic pressure: 8 to.- adjusting way: 120 mm- weight: 470 kg- dimensions: 900x600x1100 mm Bdedpfxsdktnke Af Hsk
