Stainless steel tank 14000l , 316L steel

140hl

Condition: used, Item: AV-11841-Vertical40m3tank Used vertical tanks, capacity 40.000L Exterior dimensions: Dia Ø 3200/3400 mm Total H 9600 mm incl. gear. Cylinder height: 7200 mm. Vertical stainless steel tanks - 3 pcs. Insulated with 100 mm rockwool completed with flat plate. Conical bottom 35 degrees with 4" outlet. Klöffer top with manhole. Itjdpfx Aei E Abijgded Powerful top mounted agitator. 37 kw agitator. AISI 316.

Condition: ready for operation (used), Used stainless steel reactor with double jacket and insulation item number: 10255 Final use: Chemicals Volume: approx. 7000L Working pressure: +6/-1 Bar Operating pressure double jacket: +12Bar Operating temperature: Max. 200°C Type: Standing on feet with claws Iodpfx Aod Dwkwogdetd Material (wetted parts): 1.4301 / AISI304 Design: Double jacket and insulated Underbody: dished boiler end Top plate: dished end with flange ring Operating pressure according to type plate: ATM Tank dimensions: Container inner diameter: 1790mm cyl. height: 950mm Total height: Ca 1860mm height of the feet: 670mm materials: Interior: 1.4301 / AISI 304 Outside: 1.4301 / AISI 304 / steel painted facilities: Top panel completely removable, flanged Insulation Double jacket around cylinder and underbody Various connections on the top panel Manhole cover on the top floor

Condition: used, functionality: fully functional, usable tank capacity: 15,000 l, Item: AV-12052-AV12053-Vertical-Tank-15000L Exterior dimensions: Dia Ø 2300 mm Total H 5500 mm. Vertical stainless steel tanks - one piece to offer Iedpfsq A R S Dox Agdotd Conical bottom 35 degrees with 4" outlet. Conical top 15 degrees with manhole. AISI 304.

Condition: good (used), Used stainless steel reactor with double jacket, insulation and agitator Item number: 10257 Final use: Chemicals Volume: approx. 8000L Operating pressure: +16/-1 Bar Type: Standing on feet Material (wetted parts): 1.4301 / AISI304 Design: Double jacket and insulated Underbody: dished boiler end Top soil: dished boiler end Tank dimensions: Container inner diameter: 2140mm cyl. height: 1600mm Total height: Ca 3820mm height of the feet: 710mm outer diameter: 2200mm distance drain to floor: 500mm materials: Interior: 1.4301 / AISI 304 Outside: 1.4301 / AISI 304 / steel painted Itjdpfed Dwmwex Agdod facilities: Insulation Double jacket around cylinder Various connections on the top panel Manhole cover on the top floor Agitator with double-acting mechanical seal

Condition: excellent (used), functionality: fully functional, Item: AV-12421-Vertical-12000L Jacketed Insulated Vertical Tanks Dimensions: Dia Ø 2600 mm Total H 4400 mm. Stainless steel tank - 4 pcs. identical Itjdpjrnuhpjfx Agdjd Manhole at top, conical top with ventilation and conical bottom 15 degrees with 2" outlet. Scrape agitator with gear AISI 304

Condition: good (used), - Material: AISI 316 stainless steel - Standing on feet - Tanks, above, adapted to the cellar vault Dimensions : - Width: approx. 1150 mm Ijdevlkgaopfx Agdjtd - Depth: approx. 1800 mm - Total height at rear: 2500 mm - Total height at front: 3650 mm (including dome) - Ground clearance: 340 mm Equipment: - Rectangular door 320 x 420 mm - Total drain: flap valve DN 40, Friedrich no 2 - Residual drain: flap valve DN 40, Friedrich no. 2 - Taster - Level indicator - Dome DN 200

Year of construction: 1991, condition: used, Fermentation tank with two dished bottoms. - 4 tanks with 52 hl butto content each - 2 tanks with 79 hl gross capacity each Additional title: vertical stainless steel tanks Total volume: 79 hl storage tank 2 pcs. Operating pressure: 0 bar Isdpfx Agevcqzxjdjtd Operating temperature: 20 °C Width: approx. 1400 mm Height: approx. 4100 mm Material: Stainless steel 1.4310 Position: vertical Base construction: 4 x pipe feet, height-adjustable Features: Side manway; CIP piping; outlet valve (butterfly valve)

Condition: good (used), Year of construction: 2001, 2 x wheat beer fermentation tanks with a net capacity of 14,600 liters Technical data / dimensions: Available quantity: 2 Volume: approx. 14,600 liters (gross volume approx. 19,000 liters) Type of container: wheat beer fermentation tank Condition: used Suitable for food: yes Design: upright External diameter: approx. 2600 mm Cylindrical height: approx. 4100 mm Total height: approx. 4700 mm Operating pressure: pressureless Ground clearance: approx. 500 mm Operating temperature: + 20 degrees Celsius Manufacturer: Gresser Behälterbau Year of construction 2001 Material/condition: Inner casing material: V2A (1.4301) Cooling: External cooling coils Cooling medium: glycol Operating pressure: + 2.0 bar The containers have a gross capacity of around 19,000 litres and a net capacity of around 14,600 litres. The difference is due to the "overflow spout" (see drawing) Itjdpfx Agsvn Ihtodsd The platform and the cleaning gate are also offered

Condition: as good as new (ex-display), Year of construction: 2023, type of input current: AC, El. heated roller sintering furnace, make Riedhammer type: TR 18/4x33/10-E 90 Ijdpsp T Th Hsfx Agdotd condition: as new length of debinding zone: 6.12 m length of heating/holding zone: 6.12 m length of the cooling zone: 6.12 m total length of oven without conveyors: approx. 18.4 m total length of oven with conveyors: 20.4 m total width of oven: 3.5 m total height of oven: approx. 2.5 m clear oven width: 1,540 mm usable width: 4x 330 mm usable height from top edge of roll: 100 mm roller spacing: approx. 85 mm roll diameter: approx. 50 mm number of oven conveyor drives (controlled): 3 pieces number of rule groups: 34 connected load of oven: approx. 476 kW maximum temperature on the thermocouple: 900 °C max. temperature: 930°C power type: 400/230V, 50Hz cooling water consumption: approx. 50 m³/h

Year of construction: 1997, condition: good (used), Item: AV-11828-5000L Vertical Tank Vertical, stainless steel tanks - 2 pcs. identical Iedpfeiha Anox Agdstd Exterior dimensions: Dia Ø 1200 mm Total H 7000 mm incl. gear. Outlets height 1200 mm. Vertical, stainless steel tanks - 2 pcs. Conical top, conical bottom with 2" outlet. Top mounted agitator. Manhole front at bottom. Year 1997. AISI 316
