Sack Packaging and Palletizing Line

Aventus FIBC

A line for packing and palletizing bags of products such as salt or fertilizer is available. It includes specialized machines for the precise filling, packaging and stacking of bags on pallets for shipping. The system is designed for continuous operation. 1) Palletizing robot for the bags, max. pallet dimensions X/Y: 1300mm/900mm, loading height including pallet: 700mm-1500mm, max. loading weight: 1500kg, max. loading capacity: 500-600 bags/h, recommended loading capacity: 450-550 bags/h. 2) Big bag filling station Aventus FIBC EGF 1, big bag weight: 500kg, 600kg, 1000kg, max. big bag height: 1400mm, max. big bag width: 1000mm, max. big bag depth: 1000mm, loop length: 250mm, filling support diameter: 400mm, filling support height: 500mm, max. bag sag: 250mm, accuracy: +/-1g per 1kg. 3) Stretch-Hood-System Aventus KL Stretch-Hood, max. loading width: 900mm, max. loading length: 1300mm, max. loading height including pallet: 1500mm, max. loading weight: 1500kg, loading material: FFS-PE, film thickness: 100µm-120µm, stretch capacity: 80-120 packages/h. 4) Conveyor system with checkweigher, total conveyor length: approx. 9000mm, belt width: 700mm, checkweigher table width: 1300mm, working height: 600mm-750mm. 5) Label printer/thermal transfer printer Smart Date X, print speed: 350 packages/min, resolution: 300dpi, print area X/Y: 53mm/73mm. Documentation available. On-site inspection is possible.
