Center lathe

BEHRINGER

Condition: good (used), Year of construction: 2018, Burning and Drilling System Plate Processing Center Manufacturer: Vernet-Behringer Type: MAG EVO 420 Year of construction: 2018 CNC control Power source: Kjellberg HiFocus 360 Plasma cutting for material thickness: 5 to 50 mm Spindle speed: 160 – 4,000 rpm Automatic turret Tool holder: 14 Drive power: 16 kW Drilling diameter: 5 - 40 mm V-scoring for marking: 5 to 40 mm Sheet metal dimensions min.: 1,500 x 300 mm (750 x 400 mm with limitations) Minimum dimensions of finished parts: 80 x 80 mm Sheet metal weight max.: 2,600 kg and 650 kg/m Fpodpsvzrczefx Afusn Infeed side: Roller conveyor for flat steel or plates: 4,000 x 2,000 mm Zero-point transverse conveyor Number of carriages: 2 clamps NC feed carriage, positioned to the side 4 clamping jaws (2+2) 3 short-stroke transverse conveyors Working height: 1,000 mm Outfeed side: Outfeed roller conveyor with a lowerable discharge table with a chute into a material collection container for unloading small parts. Filter unit incl. piping Powerful for use with carbide tools. For drilling, tapping, marking, milling, plasma cutting of flat steel and sheets. Software options for milling and scoring LANTEK license 121026ä Availability: immediate!

Condition: new, Manufacturer: Behringer Eisele Type: VMS 350 Condition: NEW Machining cross section max. round at 90° 120 mm Machining cross section max. rectangle at 90° 170 x 100 mm Machining cross section max. round at 45° 120 mm Machining cross-section max. rectangular at 45° 120 x 100 mm Saw blade diameter 350 mm Saw blade width 3 mm Bore diameter 40 mm Fsdpfsy S Eytsx Afuepn Adjustable saw blade speed 17 rpm / 34 rpm Machine head swivels 45-90-45-30° Total motor power 1.4/1.9 kW Width 900 mm Length x width x height 1050 x 900 x 1900 mm

Condition: used, Year of construction: 2008, functionality: fully functional, operating hours: 7,765 h, Behringer HBP 263 AG fully automatic metal bandsaw (2008) Manufacturer: Behringer Model: HBP 263 AG fully automatic metal bandsaw Year of manufacture: 2008 Fodjzwhdpspfx Afuopn

Condition: good (used), Year of construction: 2001, machine/vehicle number: 201224, functionality: fully functional, cutting speed: 110 mm/min, Used band saw Type: Semi-automatic *This machine was initially automatic, it has been modified to be semi-automatic. Cutting capacities: 90º round, 15º left-right, 30º left-right, 45º left-right: 410mm. Square at 90º: 850x400mm Square at 15º left-right: 800x400mm Square at 30º left-right: 700x400mm Square at 45º left-right: 550x400mm Minimum cutting capacity: 10mm / 10x8mm Minimum cutting length: 35mm Cutting speed: 17-110m/min. Drive motor power: 7.5kw Fpodpfouc Tpaex Afuon Hydraulic pump motor power: 5.5kw Actions from control panel: Rotation to degrees. Saw drive Drive forward and backward the feed rollers. Raise and lower clamp clamps. Open and close clamp Machine being overhauled. Request operating video.

Condition: new, Year of construction: 2026, 10 machines in stock, Behringer Eisele VMS 350 & 370 in standard configuration, new machines, including 1 saw blade and full warranty. Fpsdpoz Ihbtsfx Afusn Great prices!

Condition: used, Year of construction: 1985, cutting diameter 200 mm band length . mm stroke . mm total power requirement . kW weight of the machine ca. . t dimensions of the machine ca. . m The tech. Data are manufacturer or operator information and therefore non- Fsdpoz Icx Hefx Afuopn binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Year of construction: 2019, condition: ready for operation (used), Plate processing center manufactured in 2019. This Behringer MAG EVO 420 is suitable for drilling, tapping, marking, milling, and plasma cutting of flat steel and sheet metal. It features a roller conveyor for sheets up to 4000 x 2000 mm and an automatic turret tool changer with 14 tool positions. If you are looking to get high-quality plate processing capabilities, consider the Behringer MAG EVO 420 machine we have for sale. Contact us for further details. - Infeed System: Roller conveyor for flat steel/plates up to 4000 x 2000 mm with zero-position transverse conveyors, NC feed carriage, and retractable clamps- Outfeed System: Outfeed roller conveyor with lowerable discharge table and chute into material collection container for small parts- Drilling Unit Drive Power: 16 kW- Spindle Speed: 160 to 4000 RPM- Tool Changer: Automatic turret tool changer with 14 tool positions- Software Options: Milling, V-scoring marking, and DSTV interface for machining data import- Plasma Cutting Unit: Kjellberg HiFocus 360i (for material thicknesses up to 50 mm)- Exhaust System: Large-dimensioned filter unit of older year of manufacture with available piping- Control & PC: Modern CNC control enabling remote maintenance by Vernet Behringer service department, machine computer including software, and office software license- Sheet Dimensions: Min. 1500 x 300 mm (750 x 400 mm with restriction), Max. 4000 x 2000 mm- Min. Finished Part Dimensions: 80 x 80 mm- Sheet Weight: Max. 2000 kg and 650 kg/m- Drilling Diameter: 5 to 40 mm- V-Scoring Marking Depth/Diameter: 5 to 40 mm- Plasma Cutting Thickness: 5 to 50 mm- Number of Carriages: 2 clamps - feed carriage, laterally placed- Number of Clamps: 4 clamps (2 + 2)- Transverse Conveyors: 3 short-stroke transverse conveyors to align sheets against clamps after loading- Working Height: 1000 mm Fpodpfxsz H Nwgj Afuon

Condition: used, Behringer VPS60-220A - Industrial Plate Sawing Machine The BEHRINGER VPS60-220A is a fully automatic industrial plate sawing machine / vertical bandsaw. It is designed for sawing large metal plates, slabs, and blocks across the grain – in particular, steel, aluminum, and other metals. Fjdpfoz H Ac Nox Afuspn - Chip conveyor - Safety device consisting of a safety fence and light barriers - Staircase - Operating manual and technical documentation - Year of manufacture: 2015 Technical Data - Cutting range (W x H): 2250 x 600 mm - Minimum flat (W x H): 500 x 20 mm - Maximum round: 500 mm - Minimum remaining piece length in automatic operation: from 40 mm - Minimum remaining piece length in manual operation: from 30 mm - Saw band dimensions: 11080 x 54 x 1.6 mm - Cutting speed: 17 – 120 m/min - Material support height: approx. 1650 mm - Quantity of coolant: approx. 250 l - Motor power – sawing drive: 7.5 kW - Motor power – hydraulic pump: 2.2 kW - Motor power – coolant pump: 0.33 kW - Motor power – chip conveyor: approx. 0.25 kW - Connection value: approx. 15 kW - Voltage: 400 V, 50 Hz - Control voltage / hydraulic valve voltage: 24 V = (DC) - Current consumption: approx. 35 A - Fuse rating: 50 A - Minimum cable cross-section: 35 mm² - Machine dimensions W x H x D: 17793 x 9817 x 4500 mm - Weight (net): approx. 19000 kg

Condition: used, Year of construction: 2017, Behringer LPS 60-T – Vertical metal band saw - Servo feed with cutting pressure control - Robust cast iron band guide - Fast band change - Operating hours of the saw drive: 32441 h - Year of manufacture: 2017 Technical data - Working area L x W x H: 1260 x 720 x 600 mm - Minimum material height: 10 mm - Minimum section width: 5 mm - Inner table support area: approx. 1260 x 680 mm - Inner table max. load: 3000 kg - Outer table support area: approx. 1260 x 680 mm - Outer table max. load: 3000 kg Fpsdpfx Afjz H Ac Ajusn - Material support height approx.: 1050 mm (incl. base pan) - Cutting speed: 10 - 110 m/min - Saw band dimensions: 5400 x 54 x 1.6 mm - System/band tension pressure: 85 bar - Coolant quantity: approx. 100 l - Motor power – Saw drive: 5.5 kW - Motor power – Hydraulic pump: 2.2 kW - Motor power – Coolant pump: 0.15 kW - Motor power – Chip conveyor: approx. 0.26 kW - Connection value: approx. 10.5 kW - Voltage: 400 V, 50 Hz - Control voltage / hydraulic valve voltage: 24 V = (DC) - Current consumption: approx. 31 A - Fuse rating: 35 A - Conductor cross-section: min. 10 mm2 - Machine dimensions W x H x D: 3150 x 2970 x 2500 mm - Weight (net): approx. 3200 kg

Condition: used, Year of construction: 2014, Behringer LPS 40-4 - Vertical metal bandsaw - Hydraulic band tensioning - Servo-controlled feed - Sturdy C-frame - Year of manufacture: 2014 Fpodpfez H Acpsx Afusn Technical data - Working area (L x W x H): 4000 x 680 x 400 mm - Smallest cutting height: 10 mm - Minimum cutting width: 15 mm - Inner table support area: approx. 680 x 4000 mm - Inner table maximum load: 7500 kg - Outer table support area: approx. 680 x 4000 mm - Outer table maximum load: 9500 kg - Material support height: approx. 1385 mm - Cutting speed: 17 - 120 m/min - Saw band dimensions: 5400 x 54 x 1.6 mm - System/band tensioning pressure: 85 bar - Coolant capacity: approx. 250 l - Motor power - saw drive: 5.5 kW - Motor power - hydraulic pump: 2.2 kW - Motor power - chip conveyor: approx. 0.26 kW - Connection value: approx. 11 kW - Voltage: 400 V, 50 Hz - Control voltage / hydraulic valve voltage: 24 V= (DC) - Current consumption: approx. 25 A - Fuse rating: 35 A - Conductor cross-section: min. 10 mm2 - Machine dimensions W x H x D: 6450 x 2870 x 2350 mm - Weight (net): approx. 10000 kg
