Horizontal Machining Centre

Brother Speedio S700X1

Condition: good (used), Year of construction: 2016, Ref. -No.: 10411 Manufacturer: BROTHER Type: Speedio S700X1 Year of construction: 2016 Type of control: CNC Control: BROTHER CNC Storage location: Halberstadt Country of origin: Germany X-Travel: 700 mm Y-Travel: 400 mm Z-Travel: 300 mm Main spindle drive power: 15,4 kW Main spindle speed range: 16 - 16.000 RPM Table surface: 800 x 400 mm Distance Spindle /Table: 180 - 480 mm Table Load: 300 kg Max. Tool Weight: 25 kg Csdjxc Tq Eopfx Agmerh Max. Tool Length: 250 mm Max. Tool Diameter: 110 mm Tool change time: 0,8 s Tool Taper: BT 30 Tool Piece Magazine With: 21 Pcs./pcs. Feed Speeds X/Y/Z Axis: 10.000 - 20.000 mm / min Rapid Traverse X-Axis: 50 m / min Rapid Travel Y-Axis: 50 m / min Rapid Traverse Z-Axis: 56 m / min X - axis acceleration: 2,0 G Y - Axis acceleration: 1,3 G Z - axis acceleration: 2,2 G Acceleration time: 0,30 sec Machine length: 2360 mm Machine width: 2120 mm Machine Height: 2500 mm Weight Of The Machine Ca.: 2,4 t Further information: THREAD Speed: 6,000 rpm Acceleration time: 0.11 s CUTTING CAPACITY Drilling capacity in aluminum: max. 24 mm / F0.2 Drilling capacity in C45 steel: max. 18 mm / F0.1 Tapping capacity in aluminum: max. M22 Tapping capacity in C45 steel: max. M14 Milling capacity in aluminum: max. 660 cm³/min. Face milling cutter: Ø 100 / depth 2.2 mm / F=3000 Milling capacity in steel C45: max. 48 cm³/min. Face milling cutter: Ø 40 / depth 2.5 mm / F=484 HIGH-SPEED TOOL CHANGER Stations with directional logic: 21 Change time T - T: 0.8 seconds Changeover time C - C at n=10,000 rpm and XYZ positioning: 1.4 seconds Positioning accuracy: ± 0.006 mm Repeat accuracy: ± 0.004 mm Accuracy of thread depth: 0.05 mm Air consumption: 45 l/min Air pressure: 0.5-0.6 MPa Air quality: 99% anhydrous Including FANUC robot / automation Machine can be inspected under power.

Condition: used, TECHNICAL DETAILS - Number of axes : 4 MILLING SPINDLE - Tool holder type : BT30 - Spindle power : 6.7 [kW] - Spindle speeds : 10.000 [rpm] LINEAR AXES - Travels on X/Y/Z axes : 700 x 400 x 300 [mm] - Rapid traverses rates (X/Y/Z) : 50 / 50 /56 [m/min] - Cutting feed rates (X/Y/Z) : 1 - 30 [m/min] - Distance table / spindle nose (min./max.) : 330 - 630 [mm] TOOL CHANGER - Auto. Tool Changer type : Parapluie - Tool magazine capacity : 21 - Tool exchange time : 0,8 [sec] TABLE - Table dimensions : 800 x 400 [mm] - Maximum weight upon table : 250 [kg] POWER SUPPLY - Supply voltage : 220 [V] - Total installed power : 9,5 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2.050 x 2.220 [mm] - Machine height : 2.497 [mm] - Machine weight : 2.400 [kg] EQUIPMENT - CNC : Brother CNC-C00 - Interface : Ethernet / USB - Electronic handwheel - Type of divisor : 4e axe CNC intégré Credpovt Eifofx Agmoh * Coolant tank * with high-pressure pump - Coolant through spindle - Electric transformer

Condition: like new (used), Year of construction: 2017, operating hours: 11,700 h, functionality: fully functional, travel distance X-axis: 700 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 300 mm, spindle speed (max.): 27,000 rpm, power: 8.9 kW (12.10 HP), The machine is used for fine machining of small pieces. (Al, steel) Crjdpfxjq N Ayfs Agmeh
