Automatic Punching Press

BRUDERER BSTA 80H

Condition: used, Year of construction: 1994, operating hours: 28,000 h, functionality: fully functional, The Bruderer BSTA 80H is an 80-ton high-speed stamping press built for heavy-duty progressive-die production, fitted with a BBV 320/200 strip feeder and Unidor tool monitoring. In stock in Pforzheim, ready for inspection. Nominal force: 800 kN (80 tons) Tool monitoring: Unidor Stroke rate: 100–1,000 spm Strip feeder: Bruderer BBV 320/200 Adjustable stroke: 16–63 mm Clamping plate area: 970 mm Main drive: 43 kW Power supply: 380 V / 50 Hz Ram area: 760 x 510 mm Table area: 950 x 910 mm Strip inlet height (adjustable): 80–180 mm Max. strip width: 360 mm Itodpfx Aszibtbjg Aen Max. material thickness: 3 mm Machine dimensions: 2834 x 1742 x 3460 mm Weight: approx. 15,550 kg Operating hours (main drive): approx. 28,067 h More machines from brands Bruderer, Bihler, Soprem, Noxon, Huras, Schaal and Mabu on stock available on request

Condition: good (used), functionality: fully functional, number of straightening rollers: 7, coil outer diameter: 1,400 mm, coil inner diameter: 508 mm, roller diameter: 80 mm, number of feed rollers: 2, feed roller diameter: 80 mm, straightening roller diameter: 80 mm, coil width: 400 mm, load capacity: 3,000 kg, 1. Decoiler Make: Dimeco Model: 2371 E-FPS Year of manufacture: 2006 Load capacity: max. 3 tons Strip width: max. 600 mm Expansion range: 470 – 530 mm Coil outer diameter: max. 1,400 mm Equipped with: • Hydraulic expansion • Pneumatic hold-down roller from above • 6 strip edge guide arms • Pneumatic disc brake 2. Straightening Machine Make: Dimeco Ijdpfx Ajtgvgpeg Aotn Model: 1676 C-VV Year of manufacture: 2000 Strip width: max. 400 mm Strip thickness: 0.8 – 4.5 mm Number of straightening rollers: 7 Number of entry and exit rollers: 2 each Roller diameter: 80 mm Equipped with: • Frequency-controlled drive • Hydraulic strip feeding aid with support table, feed tongue, hold-down arm from above • Pneumatically liftable entry roller • Lateral strip guide rollers • Pneumatically swivelling strip transfer table between straightening machine and feeder

Condition: good (used), Schuler PE4s 50/800 high-speed press Iodpfx Agjgryc No Ajtn Manufacturer: Schuler Type: PE4s 50/800 61/21 600/3 Press force: 50 tons Stroke: 800 mm Strokes per minute: 125-300 Ram stroke: 40 mm Kohler unwinding reel 500.1 M More items – new and used – can be found in our shop! International shipping costs available upon request!

Condition: used, Year of construction: 1987, functionality: fully functional, table length: 950 mm, table width: 910 mm, pressing force: 80 t, overall weight: 16,500 kg, punching force: 80 t, Max. pressing force: 80 tons / 800 kN Strokes per minute: 100 - 1000 SPM Mains voltage: 400 V Mains frequency: 50 Hz, 60 Hz Power consumption: 43 kW Control voltage AC: 24 V Compressed air connection: 6–10 bar Stroke length adjustment: 16, 19, 26, 35, 43, 51, 58, 63 mm Ram adjustment: 76 mm Average upper tool weight: 600 kg Maximum tool width: 970 mm Bolster area: L–R: 950 mm F–B: 910 mm Ram area: L–R: 760 mm F–B: 510 mm Max. tool width (L–R): 970 mm Strip inlet height: Max.: 160 mm Min.: 70 mm Strip feeder (left): Bruderer BBV 202/120 Max. strip width: 202 mm Feed pitch: 0–120 mm Bed opening: Itodpfx Ajxzr Ruog Ajn L–R: 920 mm F–B: 320 mm Machine dimensions: Length: 2834 mm Width: 1742 mm Height: 3460 mm Total weight with 1× BBV 202: approx. 17,500 kg Electrical cabinet dimensions: Length: 1200 mm Width: 500 mm Height: 1025 mm Weight: approx. 250 kg The soundproof cabin is not included in the offer, but it can be purchased separately. We also have many additional Bruderer, Schaal, Mabu and Bihler press models in stock, as well as decoilers and strip straighteners.

Condition: used, Year of construction: 2008, functionality: fully functional, The Bruderer BSTA 500-110B is a 500 kN Swiss-built high-speed stamping press, fitted with a BSV 75T double servo feeder for precision two-track strip feeding. Capable of up to 750 strokes per minute with B2 touch-screen control. Including sound insulating cabin. Nominal force: 500 kN (50 tons) Year of manufacture: 2008 Stroke rate: 100–750 spm (variable) Adjustable stroke: 19 / 25 / 34 / 43 / 51 / 57 / 64 mm Ram height adjustment: 64 mm Press table area: 1080 x 650 mm Control: B2, IPC-based touch-screen press control, programmable memory for fast retooling BSV 75T DOUBLE SERVO FEEDER Type: tandem dual-feed servo unit, independently controlled tracks Max. strip width: 70 mm per track Max. material thickness: 2 mm Feed length: variable, freely programmable Feed angle: variable Pilot release angle: variable No clamping/gripper bars — strip held by driven feed rollers during stamping Designed for parallel advancing of two strips or feeding pre-profiled/pre-stamped strip Isdpfezh Nnwox Ag Ajtn

Condition: refurbished (used), Year of construction: 1985, functionality: fully functional, Completely overhauled BRUDERER high-speed stamping press BSTA125 incl. new press control system Technical data: Tonnage: 1250 kN Tooling opening: 1170 mm Strokes per minute: 100–850 SPM (depending on selected stroke) Adjustable stroke: 16, 19, 26, 35, 43, 51, 58, 64, 70, 75 mm Ram adjustment range: 89 mm Tool installation height: 268–386.5 mm (depending on selected stroke) Bolster plate: 1150 x 1070 mm Ram area: 1040 x 600 mm Strip pass width: 440 mm Itsdjy D H H Eepfx Ag Aen Base plate opening: 1120 x 350 mm Strip entry height: 80–180 mm Strip feed direction: left to right Feeder: servo feed

Condition: refurbished (used), Year of construction: 2027, pressing force: 60 t, Machine made to order: High speed press BSTA 60 Retrofit and general overhaul. Conversion to electronic drive und new Unidor PC-control system. Tool area enlargement possible. Isdpfx Ajzlqlfog Astn Please contact us for detailed offers.

Condition: used, Year of construction: 1995, operating hours: 42,000 h, functionality: fully functional, machine/vehicle number: 10317, The BSTA 50UL is a Bruderer high-speed precision stamping press rated at 500 kN (50 tons) nominal force, engineered for continuous progressive-die production at variable stroke rates from 100 to 1,120 strokes per minute. The press is equipped with a Bruderer BBV 202/120 strip feeder, delivering strip widths up to 203 mm and handling material thicknesses up to 2 mm. Adjustable stroke is set between 16 and 51 mm, with strip inlet height adjustable across a 50–140 mm range to accommodate varying tooling and material profiles. Iedpfx Agszibrqj Ajtn Nominal force: 500 kN (50 tons) Tool monitoring: Unidor Stroke rate: 100–1120 strokes per minute (variable) Strip feeder: Bruderer BBV 202/120 Adjustable stroke: 16–51 mm Mounting space / clamping plate: 760–940 mm Main drive: 22 kW Power supply: 400 V / 50 Hz Table area: 940 x 580 mm Strip inlet height (adjustable): 50–140 mm Max. strip width: 203 mm Max. material thickness: 2 mm Machine dimensions: 3100 x 2700 x 1800 mm Weight: approx. 8,150 kg Operating hours: 42,416 h Sound-insulating cabin available on request More machines from brands Bruderer, Bihler, Soprem, Noxon, Huras, Schaal and Mabu on stock available on reqest

Condition: used, Year of construction: 2004, functionality: fully functional, machine/vehicle number: 1002570003, total height: 3,450 mm, ram adjustment: 80 mm, installation height: 270 mm, table height: 1,280 mm, total width: 1,700 mm, total length: 3,065 mm, drop-through hole in table: 210 mm, table length: 1,500 mm, table width: 750 mm, pressing force: 63 t, control cabinet height: 2,200 mm, control cabinet length: 1,800 mm, control cabinet width: 600 mm, stroke adjustment: 80 mm, clearance between the columns: 1,540 mm, working width: 1,500 mm, distance between side stands: 360 mm, distance between stands: 2,020 mm, overall weight: 17,000 kg, punching force: 63 t, RASTER punching system RST 630-1500 DH with soundproof enclosure and tool monitoring. The machine is in good condition. Stroke rate: 30 - 700 1/min. Operated in single-shift operation. The machine can be inspected under power. Price on request. Iodpfx Agjyyppbs Ajtn

Condition: reconditioned (used), Year of construction: 1996, pressing force: 50 t, stroke length: 51 mm, Bruderer BSTA 50USL Itjdpfx Agszlqgie Ajn - Tool loading area 1100mm L-R - Machine under refurbishment, with new controls, - Roll feed BBV or optionally servo feeder available Please contact us for a detailed quotation!
