Vertical Turret Lathe - Single Column

DÖRRIES VCE 200/140

Condition: refurbished (used), Year of construction: 1974, functionality: fully functional, machine/vehicle number: 1276, CNC Hot Radial Forging GFM SX-13 New in 1974 / 2022 New control system PLC SIEMENS S7 Machine number: 1276 No. of Hammers: 4 Forging force each hummer: 160 Ton Hammer stroke / min: 700/min Hammer lenght: 240 mm Bedpjq U R T Njfx Ah Iswi Diameter setting range: 80 mm Maximum forging diameter: Structural steel, round-cross section: Ø 130 mm square cross section: Ø 115 mm Smallest dimensions forged: Ø 25 mm Manipulator A max. displacement: 6820 mm Manipulator B max. displacement: 7150 mm Maximum workpiece length: 6000 mm Rapid speed manipulator: 400mm/sec Total connected power: 300 kW 380 V, 50 Hz Machine dimensions: Forging height over floor: 615 mm Total height pf the machinr over floor: 1665 mm Total machine lenght: 32670 mm Total foundation lenght: 33400 mm Tot. machine width (without auxliary equipments): approx 3885 mm Total foundation width: 16000 mm Total weight of the machine: 84.000 Kg

Condition: used, Technical details: faceplate diameter: 1000 mm swing diameter: 1600 mm turning height: 1200 mm main drive: 75 kW faceplate speeds from - to: 7 - 800 U/min milling motor: 25 kW milling head speed: 7 - 3000 U/min milling spindle - taper: ISO 50 cross rail adjustment - vertical: 800 mm ram head dimension: 240 x 240 mm weight of the machine ca.: 40 to dimensions of the machine ca.: 9 x 7,8 x 6,0 m Bedpfx Aevb Dcaeh Iowi Machine general overhould in 2004 and equiped with Siemens 840 D control - tool changer rack magazine - C-axis, live tooling, - Transmit function electronical Y-axis - angular milling head - complete splash housing - coolant device, chip conveyor *

Condition: used, Year of construction: 1981, machine/vehicle number: 78.977, Equipment: documentation/manual, Year of manufacture: 1981 / Year of retrofit: 1996/1997 Control: Siemens 840 C Siemens control for X/Y/Z/W/U/B/V axes Spindle diameter: 200 mm Main motor Siemens: 68 kW Spindle speeds: I gear: 3 - 202 rpm II gear: 180 - 808 rpm X travel: 12,000 mm Y travel: 4,500 mm Z travel: 2,400 mm (supporting sleeve □ 520 mm/travel 1200 mm + W axis 1200 mm) Mount: SK60 (SK50) Facing slide: yes Milling head: 2 units Prepared for CNC rotary table (4th axis) Without rotary table and clamping field (available separately) Full documentation Bedpfjqc Umgex Ah Iowi Net weight: approx. 140 tons Video available!

Condition: ready for operation (used), Broadbent Heavy Duty Lathe 1041mm x 10,000mm Year approx. 1973. Bsdpfsv I T Ewex Ah Ijwi Swing over bed 1041mm (41”) Swing bin gap1575mm (62”) Distance between centres 9300mm (30’ 6”) Spindle bore 115m (4 ½”) Spindle speeds (18) 3.3 – 360 rpm Spindle motor 30 HP or 40 HP (To be confirmed) Tailstock 6 MT Imperial Metric screw-cutting with change gears. 36” Faceplate with 4 adjustable jaws, 54” Faceplate, Taper turning attachment, Power feed to top slide, 2 x 18” 3 point steadies, 24”/28” Steady.

Condition: ready for operation (used), controller model: Num, empty load weight: 35,000 kg, total length: 11,000 mm, total width: 2,950 mm, total height: 2,000 mm, swing diameter over cross slide: 6,500 mm, Robuuste draaibank met 4 geharde lineaire geleidingen Maximaal werkstukgewicht: 20 ton bestemd voor staalfabrieken, walsgieterijen, smederijen voor het maken van producten zoals turbinerotoren, grote assen en staafproductie Bwedpfx Aswaiu Rsh Isi Swing over bed: 1400 mm Swing over cross-slide: 1100 mm Power on the spindle: 81 kW Chuck: 900 mm

Condition: used, Max. turning diameter: 650 mm Min. turning diameter: 200 mm Max. turning length: 4000 mm Max. workpiece weight: 10 tons Bwsdpfx Asvk T S Ajh Ioi Center height: 400 mm Faceplate diameter: 650 mm Speed: 1 - 58.4 rpm Drive power: 45 HP Tailstock

Condition: used, Year of construction: 2013, Year 1978 Retrofit 2013 max. turning diameter 1300 mm table diameter 1000 mm workpiece height max. 1500 mm working lenght 1050 mm 280 U/min. T-slots 48 x 28 speeds 4,75 - 250 U/min rapid traverse 6000 mm/min In our opinion, the machine is in good used condition and can be inspected condition and can be inspected under power by appointment. Bwjdpfx Ahjxmk E Uj Iji Retrofit 2013 Precision class: IT7 Technical features - 4-fold swivel head Accessories, illustrated tools and clamping devices are only included in the scope of delivery if this is noted in the additional information . Changes and errors in the technical data and information as well as prior sale reserved. subject to prior sale

Condition: used, Year of construction: 1987, functionality: fully functional, turning height: 3,000 mm, workpiece weight (max.): 50,000 kg, turning diameter: 4,000 mm, Technical data Siemens Sinumerik 840 DSL control system Main dimensions and travels Face plate diameter 3,500 mm Rotation diameter (max.) 4,000 mm Workpiece height (max.) 3,000 mm Total height of the machine 7,250 mm Maximum workpiece weight 50,000 kg Table base Y Bwedpju R D Tnefx Ah Isi Horizontal table displacement 2,000 mm Cross beam Vertical adjustment of the crossbeam in 50 steps 1,500 mm Crossbeam support (right) Horizontal adjustment of support -25 + 2170 mm Vertical displacement of the chisel slide 1,800 mm Cross-section of the chisel slide 250x210 mm Tool positions Cross beam support (left) Horizontal adjustment of support -25 + 2170 mm Vertical displacement of the chisel slide 1,800 mm Cross-section of the chisel slide 250x210 mm Tool changer without side support (right) Main drive: Power of the main motor 100 kW Speed range of the faceplate 1-100 rpm. Maximum torque on the face plate 100 kNm Drilling and milling drive vertical support: Power of the drive motor 22.5 kW Maximum torque 900 Nm Without drilling and milling drive side support Total weight Connection values of the machine Machine connection voltage 380 Volt / 50Hz Control voltage 220V AC / 24V DC Total connected load 150 kVA Required back-up fuse 400 A Equipment and accessories: Operator platform Chip conveyor Cooling lubricant system Tool changer Tool measuring probe RENISHAW

Condition: used, Year of construction: 1995, functionality: fully functional, Technical data Bwjdpeu R Imljfx Ah Iji Control system Siemens Sinumerik 840 Dsl Main dimensions and travels Face plate diameter 3,600 mm Rotation diameter (max.) 4,200 mm Workpiece height (max.) 4,800 mm Total height of the machine 8,700 mm Maximum workpiece weight 80,000 kg. Table base Y Horizontal table displacement 2,000 mm Cross beam Vertical adjustment of the cross beam in 100 mm steps 2,800 mm Crossbeam support (right) Horizontal adjustment of support - 1,800 to + 2,200 mm Vertical adjustment of the chisel slide 1,500 mm Cross-section of the chisel slide 240x240 mm Tool positions 20 pcs. Without vertical support (left) Lateral support (right) Vertical adjustment of support 2,800 mm Horizontal displacement of the chisel slide 1,000 mm Cross-section of the chisel slide 240x240 mm Turning diameter max./min. 4500/2500 mm Tool changer Main drive: Power of the main motor 105 kW Speed range of the faceplate 0.4-90 rpm Maximum torque on the faceplate Drilling and routing drive Vertical support: Power of the drive motor 22.5 kW Maximum torque 900 Nm Side support drilling and milling drive: Power of the drive motor 22.5 kW Maximum torque 900 Nm Connection values of the machine Machine connection voltage 380 Volt / 50Hz Control voltage 220V AC / 24V DC Total connected load 150 kVA Required back-up fuse 400 A Equipment and accessories: Operator platform Chip conveyor Cooling lubricant system Tool changer Tool measuring probe RENISHAW
