Universal Tool Room Milling Machine

DECKEL FP 1

Condition: used, Year of construction: 1979, x-travel 300 mm y-travel 160 mm z-travel 340 mm spindle taper ISO 40 spindle turning speed range 40 - 2000 U/min feeds -stepless- 5 - 500 mm/min rapid traverse 1200 mm/min creep feed 4 mm/min Lredpfoviyf Hjx Agmew control Heidenhain TNC 113 total power requirement 1,6/2 kW weight of the machine ca. 570 kg dimensions of the machine ca. 1,2 x 1 x 1,75 m with active digital display "Heidenhain TNC 113", for automatic retraction of preselected slide positions in absolute and incremental travel, autom. feeds stepless in x + z axis, sliding upper arm 100 mm. We ask private interested parties to refrain from making an inquiry, as this is a well-maintained professional machine and usually exceeds the budget of hobby mechanics, including VAT. Machine dealer with own stock of 1600 m².

Condition: good (used), DECKEL Tool Milling Machine FP 1 No. 2101 with HEIDENHAIN 3-axis digital readout Travel: X/Y/Z: 300 x 160 x 340 mm Manual adjustment of milling head arm: 100 mm Expansion of working area to: 300 x 260 mm Spindle speeds, vertical/horizontal: 40 – 2,000 rpm Gear stages: 16 Spindle taper: SK 40 Tool holder: S20 x 2 (Deckel standard) Quill travel: 60 mm Lrodpfxoxyc Tke Agmjw Feed X/Z axis: 5 – 500 mm/min Feed adjustment: stepless Rapid traverse X/Z axis: 1,200 mm/min Feed Y axis: manual Fixed angle table: 600 x 210 mm Tilting vertical head: +/- 90 degrees Weight: 710 kg Dimensions: approx. 1,250 x 1,200 x 1,850 mm Technical data subject to change! Features: - For horizontal machining, the milling head is swiveled 90 degrees and pushed to the rear. - 3-axis precision digital readout HEIDENHAIN - Stepless feed on X/Z axis - The machine was partially overhauled by a specialist company a few years ago. Equipment: - 3-axis digital readout HEIDENHAIN - Micro coolant spray system - Fixed angle table - Chip tray - Machine lamp - Machine feet Further accessories available on request! Condition: Good to very good, from a training workshop Available from March 2026

Condition: used, Universal Tool Milling Machine DECKEL Type FP 1 Machine No. 51265 Year of manufacture: approx. 1967 Travel paths X: 300 mm Y: 150 mm Z: 340 mm Table size 600 x 200 mm Spindle taper SK 40 - S20 x 2 Spindle speed 40–2000 rpm, 16 steps Motor power 1.0 and 1.6 kW, pole-changing Power supply 380 Volt, 50 Hz Lredpfxjghtvao Agmow - Feed on X and Z axes - Spindle speed via 2 motor speeds and 8 gear steps - Quill movement at vertical milling head 60 mm - Swiveling, rotating, and tilting angle table - Coolant pump in machine base - Separate control cabinet Space requirements L x W x H 1100 x 1100 x 1600 mm Weight 690 kg In good condition

Condition: good (used), Internal item no.: 25094 Universal milling machine Ledpfx Ajxxkwnsgmorw Deckel FP1 + Accessories (machine vice / dividing head / SK40 tool holders / tailstock) The milling head is equipped with an M16 drawbar + Additionally, S20x2 drawbar The machine can be inspected under power.

Condition: used, Universal Milling Machine DECKEL FP1 Travel X: 300 mm Travel Y: 150 mm Travel Z: 300 mm Horizontal + vertical spindle Spindle speed: from 40 to 2000 RPM Horizontally tiltable head Ledpsxyymbjfx Agmerw Spindle motor: 2 speeds Motor: 1,5 kW Feeds: X - Z auto / Y manual Supplied without table only with one 4 concentric jaws Ø 140 mm Voltage: 380 V Width: 1200 mm Depth: 1200 mm Total height: 1600 mm Weight: approx 900 KG

Condition: ready for operation (used), Working travels 300x150x340mm Universal table 600x260mm Lredpjdr E Apsfx Agmew Spindle taper 40 Spindle speeds 40-2000 rpm Digital read-out Misc.accessories MARCELS MASCHINEN CH

Condition: good (used), functionality: fully functional, feed length X-axis: 300 mm, feed length Y-axis: 160 mm, feed length Z-axis: 340 mm, For sale is a conventional milling machine of the brand Deckel and type FP1 The small size of the machine makes it ideal for fast work with a small footprint The machine is fully functional Technical data: x-path 300 mm y-path 160 mm z-path 340 mm Tool holder SK40 Speed 40-2000 rpm Conventional control Table size: 600 x 210 mm Total power requirement 2 kW Machine weight approx. 0.73 t Space requirement approx. 1200x1100x1600 mm Loading and shipping throughout Europe can be organized on request. Prices plus VAT Viewing possible by appointment. Contact us, our team will be happy to help you. Trade-in or exchange possible! Machines purchase / sale Lrjdpfx Aeugv Hvegmew PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MUCH MORE. Do you need a high-quality but inexpensive metalworking machine for your production? Or do you want to sell yours? For further information or contact options, please visit our website

Condition: excellent (used), DECKEL Universal Milling Machine FP 1 No. 2101 with HEIDENHAIN 2-axis Digital Readout Travel Paths: X/Y/Z: 300 x 160 x 340 mm Manual Adjustment Milling Head Arm: 100 mm Extension of Working Area to: 300 x 260 mm Spindle Speed Vertical/Horizontal: 40 – 2,000 rpm Gear Steps: 16 Spindle Taper: SK 40 Tool Fixture: S20 x 2 (Deckel Standard) Quill Travel: 60 mm Feed X/Z Axis: 5 – 500 mm/min Feed Control: stepless Rapid Traverse X/Z Axis: 1200 mm/min Feed Y Axis: manual Fixed Angle Table: 600 x 210 mm Tilting Vertical Head: +/- 90 degrees Weight: 710 kg Dimensions: approx. 1250 x 1200 x 1850 mm Technical data not binding! Features: For horizontal machining, the milling head is swivelled 90 degrees and slid to the rear. 2-axis precision digital readout HEIDENHAIN POSITIP VRZ 719 Infinitely variable feed on X/Z axis The machine underwent partial overhaul by a specialized company a few years ago. Equipment: 2-axis HEIDENHAIN digital readout Fixed angle table Chip tray Machine lamp Machine feet Further accessories on request! Lsdpexyc N Ejfx Agmjrw Condition: good to very good from training workshop Available from March 2026

Condition: used, Year of construction: 1985, machine/vehicle number: 294, x-travel:400 mm y-travel:190 mm z-travel:310 mm table clamping surface:280 x 750 mm Reach of the vertical spindle:115-575 mm feed steps:16 feed range:11,2-355 mm/min tool taper:SK 40 speed steps :16 speeds::56-1800 min-1 total power requirement:2,2 kW dimensions of the machine ca.:1550 x 1250 x 2000 mm weight of the machine ca.:1200 kg Lsdpfx Agovcf Hpomsrw

Condition: used, Universal Milling Machine DECKEL FP1 Ljdoxxpp Nspfx Agmorw Travel X: 300 mm Travel Y: 150 mm Travel Z: 300 mm Horizontal + vertical spindle Spindle speed: from 40 to 2000 RPM Table size: 600 x 210 mm Horizontally tiltable head Straight table Spindle motor: 2 speeds Motor: 1,3 kW Feeds: X - Z auto / Y manual Voltage: 380 V Width: 1200 mm Depth with electrical panel: 1200 mm Height:1600 mm Weight: approx 900 kg
