Tool Room Milling Machine - Universal

DECKEL FP1

Condition: excellent (used), Year of construction: 1988, functionality: fully functional, Technical details x-travel 300 mm y-travel 160 mm Hnedpfx Aox Ux Hrshuog z-travel 290 mm table surface area 210 x 600 mm tool taper SK 40 spindle turning speed range (16) 40 - 2000 U/min feeds -stepless- 5 - 500 mm/min rapid traverse 1,2 m/min spindle motor 1,5 / 1,9 kW total power requirement 9,5 kVA weight of the machine ca. 730 kg dimensions of the machine ca. 2000 x 2200 x 1655 mm Additional information The machine is in very good condition and comes from a training workshop. Equipment: Safety cover and LED lamp retrofitted in 2016 3-axis active digital readout made by Heidenhain Fixed angle table Coolant equipment

Condition: used, Year of construction: 1980, x-travel 300 mm y-travel 160 mm Hsdpfx Ahsw A Ap Heusng z-travel 340 mm tool taper SK40 Speed 40-2000 U/min. control Aktiv HEIDENHAIN table-size 600 x 210 mm total power requirement 2 kW weight of the machine ca. 0,73 t dimensions of the machine ca. TBH 1200x1100x1600 m - Active feed in the X and Z axes - Additional swiveling table 600 x 210 mm - Coolant system - Counter bearing for horizontal milling - Several fixtures and clamping devices/milling cutters - Operating instructions

Condition: reconditioned (used), Year of construction: 1994, Universal Tool Milling Machine DECKEL FP 1 Hnsdpsw Agxrofx Ahuog With 3-axis active digital readout Heidenhain TNC 123 Year of manufacture: 1994 Travel: X 300 mm, Y 160 mm, Z 340 mm Spindle speed range: 40 – 2000 rpm Comes with the following accessories: Fixed angle table, 600 mm x 250 mm clamping surface Movable vertical milling head Extendable quill Infinitely variable feed via potentiometer 1 machine vice 1 tailstock with counter bearing 1 long milling arbor Ø 22 mm, Ø 16 mm, Ø 27 mm Various tool holders S 22 x 2 Z axis bellows 1 chip guard Machine lamp Automatic central lubrication pump Coolant system Operating manual THE MACHINE IS IN EXCELLENT CONDITION! THE MACHINE COMES FROM A TRAINING WORKSHOP!

Condition: reconditioned (used), feed length X-axis: 300 mm, feed length Y-axis: 160 mm, feed length Z-axis: 340 mm, Updated Machineseeker description (with travel distances) Deckel FP1 Aktiv – 3 axes – partially overhauled – ready for immediate use Offered for sale is a Deckel FP1 Aktiv in technically inspected and partially overhauled condition. The machine has been professionally refurbished and is in a reliable, operational state. Ideally suited for workshops, toolmaking, training, as well as single part and small batch production. This is not an unchecked used machine but a technically overhauled tool machine with a clearly defined scope of performance and a predictable delivery time. Technical data and features Travel distances: X-axis approx. 300 mm Y-axis approx. 160 mm Z-axis approx. 340 mm 3 axes with Aktiv control and digital readout Stepless feed on all 3 axes Coolant system Brake motor Fixed angle table New LED work lamp New leveling feet Technical documentation in PDF format Scope of refurbishment Workshop tested and partially overhauled Technical inspection of all functions Repair or replacement of defective components Complete basic cleaning Readjustment of all existing adjustment options Renewal of all lubricants Hnsdpex Tdy Isfx Ahueg Replacement of selected standard and various wear parts New paint finish in RAL 7035 / 7016 The conscious decision for a partial overhaul provides an optimal compromise between operational reliability, cost-effectiveness, and availability. A complete overhaul of the guideways was not carried out, as there was no technical necessity for this. Scope of delivery Machine loaded free of charge Delivery time approx. 12 weeks

Condition: excellent (used), functionality: fully functional, Deckel FP1 milling machine. Very good condition. Fully functional. Hnjdjxgdr Iopfx Ahusg

Condition: reconditioned (used), Year of construction: 1990, Universal Tool Milling Machine Make: DECKEL Model: FP 1 Aktiv Year of manufacture: 1990 – workshop-inspected Machine no.: 2102-5866 Milling head type: 2171 Milling head no.: 4613 Geometric inspection with test report Accessories: Hedpex S Edlefx Ahujng - 3-axis active digital readout HEIDENHAIN TNC 113 with active function in X, Y, and Z axes - Universal table 590 x 250 mm (T-slot: 12 mm) - Vertical milling head SK 40 with pull stud thread S 20 x 2 - Without coolant system; can be retrofitted if required - Centralized lubrication, electric - Operating manual Used as seen, sold without warranty The machine is technically in the condition of its year of manufacture.

Condition: good (used), Electric motor, three-phase motor, brake motor Hnodpfx Aheul H Dwjueg -Manufacturer: Siemens, electric motor type 1LC3113-4BB23 Z from milling machine Deckel FP4L -Power: 4.0 kW -Speed: 1435 rpm -Design: B14 -Protection class: IP 44 -Brake: multi-disc brake type EK5dB24 -Dimensions: 575/270/H225mm -Weight: 64 kg

Condition: used, Year of construction: 1976, x-travel 350 mm y-travel 150 mm z-travel 340 mm table surface area 600 x 210 mm spindle taper SK 40 spindle turning speed range 40 - 2000 U/min feeds 5 - 500 mm/min rapid traverse 1,2 m/min Hjdpjwwwr Eefx Ahueng total power requirement 1,9 kW weight of the machine ca. 0,7 t - machine out of teaching shop - Accessories: solid table, vertical head with quill retraction, DRO on 3 axis HEIDENHAIN, various tool fixtures, various collets, original DECKEL tool cabinet

Condition: excellent (used), functionality: fully functional, travel distance X-axis: 300 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 340 mm, spindle speed (max.): 2,000 rpm, spindle speed (min.): 40 rpm, rotational speed (max.): 2,000 rpm, rotational speed (min.): 40 rpm, 2-axis active digital display (Heidenhain) Spindle mount: SK40 (S20x2) Travel paths: X 300 / Y 160 / Z 340mm Speed: 40 - 2000 rpm. (2 gear levels) Feed continuously adjustable The machine is in a well-maintained condition and can be inspected on site, with power on. Includes extensive accessories. - Machine vice Hedpfxjvnr Hyj Ahuong - Operating instructions / electrical circuit diagram / spare parts list - Collet set (S20x2) including SK40 collet insert - Other accessories on request.

Condition: good (used), 1 used universal tool milling machine make Deckel type FP 1 year 82 Technical data: x-travel: 300 mm y-travel: 160 mm z-travel: 340 mm Spindle holder SK 40 Table size: 600x210 mm Spindle speeds: 40-2000 rpm Hsdjrn I Rzopfx Ahueng Machine weight approx.: 1 t Space requirement approx.: 1.6x1.3x1.8 m

Condition: ready for operation (used), Year of construction: 1972, Deckel FP1 tool milling machine, swiveling angular table, MK 4 spindle taper. Accessories: tailstock support, various collets. The machine is in operational condition and can be demonstrated under power by arrangement. Hedpsx Nclnsfx Ahuong

Condition: good (used), DECKEL Tool Milling Machine FP 1 No. 2101 with HEIDENHAIN 3-axis digital readout Travel: X/Y/Z: 300 x 160 x 340 mm Manual adjustment of milling head arm: 100 mm Expansion of working area to: 300 x 260 mm Spindle speeds, vertical/horizontal: 40 – 2,000 rpm Gear stages: 16 Spindle taper: SK 40 Tool holder: S20 x 2 (Deckel standard) Quill travel: 60 mm Feed X/Z axis: 5 – 500 mm/min Feed adjustment: stepless Hnjdpfjxyc Tksx Ahusg Rapid traverse X/Z axis: 1,200 mm/min Feed Y axis: manual Fixed angle table: 600 x 210 mm Tilting vertical head: +/- 90 degrees Weight: 710 kg Dimensions: approx. 1,250 x 1,200 x 1,850 mm Technical data subject to change! Features: - For horizontal machining, the milling head is swiveled 90 degrees and pushed to the rear. - 3-axis precision digital readout HEIDENHAIN - Stepless feed on X/Z axis - The machine was partially overhauled by a specialist company a few years ago. Equipment: - 3-axis digital readout HEIDENHAIN - Micro coolant spray system - Fixed angle table - Chip tray - Machine lamp - Machine feet Further accessories available on request! Condition: Good to very good, from a training workshop Available from March 2026

Condition: excellent (used), functionality: fully functional, travel distance X-axis: 300 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 340 mm, spindle speed (max.): 2,000 rpm, spindle speed (min.): 40 rpm, rotational speed (max.): 2,000 rpm, rotational speed (min.): 40 rpm, 3-axis active digital display (Heidenhain TNC113) Spindle mount: SK40 (S20x2) Travel paths: X 300 / Y 160 / Z 340mm Speed: 40 - 2000 rpm. (2 gear levels) Feed continuously adjustable Hnedpsvnrz Rofx Ahusg The machine is in a well-maintained condition and can be inspected on site, with power on. Includes extensive accessories. - Machine vice - Operating instructions / electrical circuit diagram / spare parts list - Collet set (S20x2) including SK40 collet insert - Other accessories on request.

Condition: excellent (used), DECKEL Universal Milling Machine FP 1 No. 2101 with HEIDENHAIN 2-axis Digital Readout Travel Paths: X/Y/Z: 300 x 160 x 340 mm Manual Adjustment Milling Head Arm: 100 mm Extension of Working Area to: 300 x 260 mm Spindle Speed Vertical/Horizontal: 40 – 2,000 rpm Gear Steps: 16 Spindle Taper: SK 40 Tool Fixture: S20 x 2 (Deckel Standard) Quill Travel: 60 mm Feed X/Z Axis: 5 – 500 mm/min Feed Control: stepless Rapid Traverse X/Z Axis: 1200 mm/min Feed Y Axis: manual Fixed Angle Table: 600 x 210 mm Tilting Vertical Head: +/- 90 degrees Weight: 710 kg Dimensions: approx. 1250 x 1200 x 1850 mm Technical data not binding! Features: For horizontal machining, the milling head is swivelled 90 degrees and slid to the rear. 2-axis precision digital readout HEIDENHAIN POSITIP VRZ 719 Hnsdpfx Ahoxyc N Esusg Infinitely variable feed on X/Z axis The machine underwent partial overhaul by a specialized company a few years ago. Equipment: 2-axis HEIDENHAIN digital readout Fixed angle table Chip tray Machine lamp Machine feet Further accessories on request! Condition: good to very good from training workshop Available from March 2026
